How-to Make Your Own 3D Printing Goo

Karl here…just want to do a little post about bed adhesion and what I have been doing for the past month. What spurred this is I saw a ton of videos on Magigoo a while back. It is a product that you wipe on your glass/mirror bed and 3D prints stick very well to it and once the bed cools the part pops off very easily. It is quite expensive and it got me to think about alternatives. I have used glue stick almost exclusively while printing on glass/mirror but a lot of time the prints stick too well and prints can get marred up removing with a tool.

It is quite easy to make. 1 cup water and 1 large 22g Elmers glue stick. I put both in water and let sit thinking it would dissolve on its own. After several hours I got impatient and put it in the microwave and heated it.(45 seconds I think). That did the trick and was only left with a few big clumps that I broke apart with my fingers to finish the dissolving.

To apply I just dip a paper towel in the solution and wipe on the bed. It leaves an extremely light layer of glue on the bed that PLA sticks very well to. When the bed cools the parts have very light adhesion to the bed. If the bed is hot it takes some force to get off.

I waited a month before posting to make sure the solution did not go rancid. It has no odor so far except smelling like the glue stick. I have tried to think of a printable applicator with a dense sponge that is more elegant than a paper towel but have not come up with anything. Anything that I come up with I believe would get clogged after time.  Hope this helps and happy printing.

Share this:

Support CNX Software! Donate via cryptocurrencies, become a Patron on Patreon, or purchase goods on Amazon or Aliexpress

ROCK 5 ITX RK3588 mini-ITX motherboard

Radxa ROCK 5C (Lite) SBC with Rockchip RK3588 / RK3582 SoC
Subscribe
Notify of
guest
The comment form collects your name, email and content to allow us keep track of the comments placed on the website. Please read and accept our website Terms and Privacy Policy to post a comment.
9 Comments
oldest
newest
xavier
xavier
6 years ago

Hi Karl,
Could you precise water quantity used because “1 cup of water” does not mean anything for me…
Thank you

willmore
willmore
6 years ago

Assuming you’re not intentionally trolling….
1 cup == 0.23658824 L

cnxsoft
Admin
6 years ago

I was not aware it was an official measure. It appears to be mostly used in the US according to Wikipedia.
“Cup” can be confusing, as it may also refer to an actual cup whose size may vary, although in that context it would be clear to people used to deal in “cups” as per the US meaning.

xavier
xavier
6 years ago

Thank you : It is precisely what I tried to expose.
In my kitchen I have diversity of cups and glasses of all sort with different capacities.
I encounter same problem with approximative recipes.
So, I am not trolling I just ask for precise information.

@willmore
are you so sure Karl is refering to your suggestion or he was talking about a random cup taken from its kitchen?
We must use terms that minimize risks of confusion otherwise it is unusable information.

Karl Johnson
Karl Johnson
6 years ago

Sorry…236 ml.

xavier
xavier
6 years ago

No problem Karl.
Thank you for your precision.
I learned something today. I did not know cup is a unit of volume.
Anyway, thank you to share with us your trick…

willmore
willmore
6 years ago

Optionally, you could use a PrintBite bed and skip all the crazy adhesion enhancing issues as well as the after print cleanup problems.

bob
bob
6 years ago

If you’re printing on glass with glue stick and your prints aren’t popping off it usually means your print bed isn’t warm enough, at least with PLA/ABS. The idea is to keep it at or slightly above the glass transition temp so that when it cools the action of it shrinking, ~2% for PLA, ~8% for ABS, that last bit pops it free. I don’t think PETG shrinks enough to automatically pop free. Keep in mind that the glass also acts as an insulator, the temperature you set the heat bed to is likely to result in glass that is… Read more »

Jeroen
Jeroen
6 years ago

Wood glue diluted with water also works pretty good, and pop’s off after cooling
