New WiFi Naming Scheme: 802.11n Becomes WiFi 4, 802.11ac WiFi 5, 802.11ax WiFi 6

Orange Pi Development Boards

Terminology used by engineers may be confusing for end-users, so for example in the TV market 720p becomes “HD Ready”, 1080p “Full HD”, and 4K may be referred to “Ultra HD”. A few years ago, I tried to buy a 1080p TV, and the seller was really confused at first saying they only had “HD Ready” or “Full HD” televisions. Two terms I had personally never heard of myself, but eventually we managed to understand each other…

Up to now the official IEEE name for different WiFi standards like 802.11n, 802.11ac, or the new 802.11ax may have been a little confusing to consumers. So the WiFi alliance has decided to launch a new scheme naming scheme.

WiFi-6

We’ll soon have to refer to 802.11n routers as WiFi 4 routers, AC routers as WiFi 5 routers, and it will probably be less confusing for 802.11ax routers since I expect them to be sold as WiFi 6 routers once they become more broadly available.

WiFi 6 IconThe new naming convention may have impact the WiFi signal strength icon shown in your computer, mobile device, or other WiFi enable devices with a display,  as a number may be added to indicate a WiFi 6, 5 or 4 connection has been established. This is optional, but I suspect many companies will implement this since it’s not such a big change to the code.

You’ll find more details including guidelines for the naming convention and visuals in WiFi Alliance website.

16
Leave a Reply

avatar
5 Comment threads
11 Thread replies
1 Followers

Most reacted comment
Hottest comment thread
10 Comment authors
AdrianBobjs0x0cnxsoftDavid Willmore Recent comment authors
  Subscribe
newest oldest most voted
Notify of
Diego
Guest
Diego

Wow!
So that means wifi 6 is better than wifi 5? Why can’t I have wifi 7? And can I add up a wifi 4 and 5 capable router to wifi 9?

Many questions…

Schmurtz
Guest
Schmurtz

These questions are the same with the old bad naming…

Schmurtz
Guest
Schmurtz

Good idea !
So much bad naming !
Usb C instead of usb 4, xbox one instead of xbox 3, geforce RTC instead of geforce 11 and the top : intel Intel NUC DC53427HYE instead of nuc3i5

KopiJahe
Guest
KopiJahe

USB C is a connector type (like USB A/B, mini A/B and micro A/B) that support USB 2.0, 3.0, 3.1 and 3.2.

USB 3.1 and 3.2 is the one with stupid naming scheme, where half of them is basically a rebrand from older versions.

tkaiser
Guest
tkaiser

> USB C is a connector type (like USB A/B, mini A/B and micro A/B) that support USB 2.0, 3.0, 3.1 and 3.2

Nope, USB-C is a standard developed roughly at the same time as USB 3.1. It supports various USB speed modes (the slow modes on the Hi-Speed/USB2 data lines, SuperSpeed or SuperSpeed+ on the respective SSTX/SSRX differential pairs), an Audio Adapter Accessory Mode for analog audio and optional Alternate Modes for a bunch of different protocols (DisplayPort, Thunderbolt, HDMI, …). USB-C compliant cables AFAIK need to be compliant to USB 3.1 specs even if they only provide Hi-Speed data connections and no Alternate Modes.

> USB 3.1 and 3.2 is the one with stupid naming scheme

These are protocol/specification revisions. It’s not the problem of these revisions that ‘the market’ and end users don’t use the appropriate names. That would be SuperSpeed and SuperSpeed+ if it’s about speed classes.

schmurtz
Guest
schmurtz

The conclusion is that USB C is a shitty name 😀 (and I don’t talk about the mess with the protocols supported or not by USB C)

tkaiser
Guest
tkaiser

> The conclusion is that USB C is a shitty name

I don’t think so. Prior to USB-C we had a bunch of different [Mini]|Micro] A and B connectors and respective [Mini]|Micro] A/B cables . USB-C solves a lot of problems with the old connector and cable types.

IMO the only real problem is USB-C gear not specifications compliant (those USB-C cables that can set your laptop on fire)

And a totally different problem is that ‘the market’ used wrong names from the beginning to describe ‘speed classes’. It’s not USB2 but Hi-Speed, it’s not USB3 but SuperSpeed and it’s not ‘USB3.1 Gen2 or USB3.2’ but SuperSpeed+. But it’s understandable given the ‘evolution’ of those speed names:

In the beginning when nobody used USB we had ‘Low Speed’ and ‘Full Speed’ (1.5 vs. 12 Mbit/s). Then when USB became interesting with protocol rev 2.0 the new 480 MBit/s mode was called Hi-Speed. Do consumers want ‘High’ or ‘Full’ Speed? The latter for sure so it was not that much of a surprise that from then on the protocol revision (2.0) was used to signal increased transfer speeds.

Anyway: USB-C is neither a new protocol revision nor a new speed class. It’s just the first USB connector standard that’s not too braindead (thank you Apple for sending truckloads of engineers to USB Implementor Forum’s technical committees for USB-C and USB PD back then)

js0x0
Guest
js0x0

To be fair, the problem was that the USB 2.0 spec included all those extra connectors you mentioned. It also included USB-on-the-go.
So you could correctly say that it was a USB 2.0 physical/electrical interface (especially if the port is OTG), even if the PHY/transceiver don’t support High-Speed. Crazy, but technically correct.
Splitting out the connector and power specification into USB-C is definitely an improvement on that scheme. Any confusion is mostly the IF’s fault anyway.

tkaiser
Guest
tkaiser

Anyway. In my opinion USB-C is not a good example for bad naming since It simply deals with connector/cables and tries to improve on the A/B mess we had before (with a plethora of different A and B connectors, ‘illegal’ A/A cables existing in the wild since simply needed, USB cables with power wires so tiny that everything above 500mA resulted in a massive voltage drop and so on).

If an USB spec tries to overcome the USB A/B connector/cable mess how should it not be called USB-C? It’s a different problem that end users don’t understand USB protocol/spec revisions and believe a new connector/cable spec would be the result of an incremented USB protocol revision.

And as already mentioned: IMO the real problem is now USB-C gear sold not being compliant to USB-C specs and therefore exposing USB-C connected devices to severe risks or resulting in underpowered devices (that’s what we see soon or already with USB-C equipped development boards)

tkaiser
Guest
tkaiser

> that’s what we see soon or already with USB-C equipped development boards

Just wrote a quick review of some of those affected boards not available yet (NanoPi NEO4): https://github.com/ThomasKaiser/Knowledge/blob/master/Quick%20Review%20of%20NanoPi%20NEO4/README.md

Adrian
Guest
Adrian

Nope, KopiJahe is correct. USB-C is a connector system.

USB-C does not necessarily implement USB 3.1, USB Power Delivery, or Alternate Mode.

Tesla
Guest
Tesla

I’v always called them ‘B’, ‘G’ or ‘N’ when needed. Not that it matter much.

schmurtz
Guest
schmurtz

When you’ ll be old there will be A,B,G,N,AC,AX,RX,TG,JG,RZ,PO,NU,YTKTR,GHT,WWA,GHT instead of 1,2,3,4….
So it can matter for the consumer 😉

David Willmore
Guest
David Willmore

I feel there must be an xkcd commic about this…

Bob
Guest
Bob

I prefer my own naming conventions i’ve been using. WIFI green, WIFI Cordruoy and WIFI monkey emoji
