Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on DR6018-S is a more compact, cheaper WiFi 6 SBC with optional WiFi 6E

DR6018-S is a more compact, cheaper WiFi 6 SBC with optional WiFi 6E

Earlier this year we wrote about Wallys Communications DR6018-V2 WiFi 6 embedded router board based on Qualcomm IPQ6010 processor with M.2 sockets for optional 5G and WiFi 6E cards. The company has now launched a more compact, and cheaper board with DR6018-S SBC based on the same processor with 802.11ax WiFi 6 and 802.11 b/g/n/ac WiFi 5 support, plus an M.2 socket for people wanting to add WiFi 6E cards. DR6018-S board specifications: SoC – Qualcomm Atheros IPQ6010 quad-core Arm Cortex-A53 processor @ 1.8 GHz System Memory – 1GB (2x 512MB) DDR3L 16-bit interface with 32-bit memory bus design Storage – 256MB NAND Flash, 32MB NOR flash, optional SD card slot Networking Wired – 2x Gigabit Ethernet port including one with PoE support Wireless WiFi 2×2 2.4GHz MU-MIMO OFDMA 802.11b/g/n/ax WiFi 6, max 23dBm per chain 2×2 5GHz MU-MIMO OFDMA 802.11a/n/ac/ax WiFi 6, max 20dBm per chain 4x u.FL connectors 2.4 GHz data rate up to 573 Mbps 5 GHz […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on Qualcomm IPQ6000 embedded SBC offers dual Gigabit Ethernet and WiFi 6 connectivity

Qualcomm IPQ6000 embedded SBC offers dual Gigabit Ethernet and WiFi 6 connectivity

At the beginning of the month, we covered Mango-DVK development kit based on a  Qualcomm IPQ6000/IP6010 powered system-on-module enabling 2.5GbE and WiFi 6 connectivity. Wallys Communications contacted us earlier this week, about one of their new “802.11ax low-end product”, namely DR6000 SBC that happens to be based on Qualcomm IPQ6000 “CP03” reference design, and offers both WiFi 6 and dual Gigabit Ethernet connectivity in a round-shaped board. DR6000 / CP03 specifications: SoC – Qualcomm Atheros IPQ6000 quad-core Arm Cortex-A53 processor @ 1.2GHz processor System Memory –  512MB DDR3L Storage – 128MB Nand Flash, 16MB NOR flash Networking Wired – 2x Gigabit Ethernet RJ45 ports Wireless 2.4GHz 2×2 MU-MIMO OFDMA 802.11b/g/n/ax WiFi 6, up 573 Mbps, up to 20dBm per chain 5GHz 2×2 MU-MIMO OFDMA 802.11a/n/ac/ax WiFi 6, up to 1201 Mbps, up to 20dBm per chain 2x U.FL Connectors, diplexer allows dual band concurrent operation USB – 1x micro USB 2.0 port Serial – 12-pin header for serial interface Misc […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on NXP IW620 2×2 Wi-Fi 6 & Bluetooth 5.1 Chip Targets Gaming, Audio, Industrial and IoT Markets

NXP IW620 2×2 Wi-Fi 6 & Bluetooth 5.1 Chip Targets Gaming, Audio, Industrial and IoT Markets

NXP has announced the IW62X WiFi 6 & Bluetooth 5.1 family of chips designed for high-end gaming, audio, industrial and IoT markets. The family currently consists of IW620 and IW620S parts with respectively PCIe and SDIO host interfaces. Both chips integrate dual-band Power Amplifiers (PAs), Low Noise Amplifiers (LNAs), and switches in order to reduce the board-level BOM (Bill of Materials). IW62X key features and specifications: Wi-Fi 6 (802.11ax) 2×2 Wi-Fi 6 DB (802.11ax) 1024 QAM, 80MHz Peak Throughput: 1.2 Gbps Improved wideband noise & MU-MIMO performance Advanced active channel scanning 802.11s, EasyMesh 802.11mc Bluetooth & Bluetooth Low Energy 5.1 BLE 2Mbps + Long Range BLE direction finding with Angle of Arrival (AoA) and Angle of Departure (AoD) BLE Mesh Antenna support 2×2 5G 1×1 2.4G + BT Multimode energy-efficient support (TWT, Micro AP, TX Power Control, Wi-Fi Direct, BT5.1) Host Interfaces IW620 – PCIe 1.0 IW620S – SDIO 3.0 UART for Bluetooth only I2S/PCM audio Power Supply Integrated PMIC […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on Mango-DVK OpenWrt Devkit Features 2.5GbE, WiFi 6 SoM powered by Qualcomm IPQ6000/IP6010 SoC

Mango-DVK OpenWrt Devkit Features 2.5GbE, WiFi 6 SoM powered by Qualcomm IPQ6000/IP6010 SoC

We’ve been covering some 802.11ax WiFI 6 embedded networking boards from Wallys Communications and Compex in the last few months, but 8devices has now entered the fray with Qualcomm IPQ6000/IPQ6010 powered Mango WiFi 6 system-in-module available in commercial or industrial temperature range, as well as as a development kit based on the module. Mango SoM supports dual-band 2×2 MiMo 802.11ax and multi-Gigabit Ethernet connectivity, features up to 2GB RAM, 256MB NAND flash, and runs OpenWrt Linux with target applications including routers, gateways, and access points. Mango SoM Specifications: SoC (one or the other) Qualcomm IPQ6000 quad-core Cortex-A53 processor @ up to 1.2 GHz with hardware NAT engine, HW crypto Qualcomm IPQ6010 quad-core Cortex-A53 processor @ up to 1.8 GHz with hardware NAT engine, HW crypto System Memory – 512MB DDR3L 512MB (up to 2GB) Storage – 32MB NOR FLASH, up to 256MB NAND flash Networking Wireless 2.4GHz 802.11 b/g/n/ac/ax WiFi 6 2×2 MU-MIMO, explicit beamforming; 22dBm; up to 573.5 Mbps […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on WPQ873 Wireless Embedded SBC is Powered by Qualcomm IPQ8072A WiFi 6 SoC, Supports 5G Modules

WPQ873 Wireless Embedded SBC is Powered by Qualcomm IPQ8072A WiFi 6 SoC, Supports 5G Modules

We very recently wrote about DR6018 V2 Embedded WiFi 6 router board powered by Qualcomm IPQ6010 quad-core Cortex-A53 processor @ 1.8 GHz and supporting optional WiFi 6E and 5G IoT M.2 cards. If you are after a solution that supports WiFi 6 (802.11ax) and 5G, but with a bit more processing power and faster WiFi 6 speeds, Compex WPQ873 wireless embedded SBC may be an interesting option thanks to Qualcomm IPQ8072A quad-core Cortex-A53 processor clocked at up to 2.2 GHz, with integrated support for WiFi 6 up to 2475Mbps, and an M.2 socket for an optional 5G card. Compex WPQ873 specifications: SoC – Qualcomm Atheros IPQ8072A quad-core ARM 64 bit A53 @2.2GHz part of Qualcomm Networking Pro 600 Platform System Memory – 1x 512MB, DDR4 16-bit interface Storage – 256MB NAND flash, 8MB NOR flash Networking and Wireless Connectivity Ethernet 3x Gigabit Ethernet (RJ45) ports 1x 2.5 Gbps Ethernet port WiFi On-board 4×4 2.4GHz MU-MIMO OFDMA 802.11b/g/n/ax, up to 1182 […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on DeskMini X35G Ice Lake Mini PC Coming in October for $400 and up (Crowdfunding)

DeskMini X35G Ice Lake Mini PC Coming in October for $400 and up (Crowdfunding)

MINISFORUM is a Hong Kong-based company specialized in mini PC, and we recently covered their Gemini Lake-based MINISFORUM S40 PC Stick, but to differentiate themselves in a field with some many Gemini Lake mini PC, the company is preparing to launch DeskMini X35G mini PC based on a more powerful Intel Core i3-1005G1 “Ice Lake” processor that offers features such as Thunderbold 3 40 Gbps USB-C port and support for Intel Optane Memory. DeskMini X35G specifications: SoC – Intel Core i3-1005G1 dual-core/quad-thread Ice Lake processor @ 1.2GHz / 3.4GHz (Turbo) with 4 MB Intel Smart Cache, Intel UHD graphics @ 300 to 900 MHz; 15W TDP System Memory – 16GB DDR4-3200MHz (soldered) Storage M.2 2280 NVMe SSD (PCIe 3.0 4X) with support for Intel Optane memory 2.5 inch SATA3.0 HDD or SSD Support 1×M.2 2280 SATA SSD Support MicroSD card slot Video Output HDMI 2.0 up to 4Kp60Hz DisplayPort up to 4Kp60 DisplayPort Alt Mode via Thunderbolt 3/USB-C connector up […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on DR6018 V2 Embedded WiFi 6 Router Board Adds Support for WiFi 6E and 5G IoT M.2 Cards

DR6018 V2 Embedded WiFi 6 Router Board Adds Support for WiFi 6E and 5G IoT M.2 Cards

A few months ago we covered DR6018 (aka CP01) WiFi 6 Embedded SBC powered by Qualcomm IPQ6018 processor and offering six Ethernet ports including five Gigabit interfaces and one 2.5 Gbps Ethernet port. Wallys Communications has now informed CNX Software they had a new version of the board called DR6018 V2 with a more compact form factor, support for PoE, as well as optional WiFi 6E and 5G IoT M.2 modules. DR6018 V2 board specifications: SoC – Qualcomm Atheros IPQ6010 quad-core Arm Cortex-A53 processor @ 1.8 GHz System Memory – 1GB (2x 512MB) DDR3L 16-bit interface with 32-bit memory bus design Storage – 256MB NAND Flash, 32MB NOR flash, SD card slot Networking Wired 3x Gigabit Ethernet ports (one less compared to DR6018) 1x Gigabit Ethernet port with PoE support 1x 2.5Gbps Ethernet port Wireless WiFi 2×2 2.4GHz MU-MIMO OFDMA 802.11b/g/n/ax WiFi 6, max 23dBm per chain 2×2 5GHz MU-MIMO OFDMA 802.11a/n/ac/ax WiFi 6, max 20dBm per chain 4x MMCX […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on MediaTek T750 5G Chipset to Power Fixed Wireless Access Routers and 5G Mobile Hotspots

MediaTek T750 5G Chipset to Power Fixed Wireless Access Routers and 5G Mobile Hotspots

Most of the 5G modem we covered are designed for mobile devices, but 5G technology also brings opportunities for fixed wireless access routers (FWA routers) potentially replacing fixed broadband modem routers, as well as for 5G mobile hotspots to add coverage in areas without reliable cellular signal. Those are the two markets targetted by the just-announced 7nm MediaTek T750 quad-core Arm processor with support for sub-6GHz frequencies aiming to affordable broadband connectivity to areas with limited DSL, cable, or fiber services, or on the contrary adding wireless services in suburban, rural, and less developed areas. Mediatek T750 5G SoC highlights: Processor – Quad-core Arm Cortex-A55 CPU GPU / Display – Embedded GPU and display driver to support up to 720p displays Cellular Networking 5G NR FR1 modem with sub-6GHz frequencies support and two-component carrier aggregation (2CC CA) for extended coverage Standalone and non-standalone (SA/NSA) modes supported 5CC LTE carrier aggregation LAN Connectivity 2x  2.5Gbps SGMII interfaces for wired Ethernet networks […]
