Qualcomm IPQ8074 Embedded Board Offers 802.11ax WiFI 6 12×12 MIMO DBDC Connectivity

Qualcomm IPQ8074 802.11ax WiFi 6 SoC was first unveiled in 2017 and designed for high-end routers, gateways, and access points supporting up 12×12 MIMO configuration (8×8 5GHz + 4×4 2.4 GHz) using Dual-Band Dual Concurrency (DBDC). I was just informed about a Qualcomm IPQ8074 embedded board going under the names DR8074A or HK01 depending on the company promoting it, respectively Wallys Communication and Compex. Qualcomm IPQ8074 embedded board (AP.HK01) specifications: SoC – Qualcomm Atheros IPQ8074A quad-core Arm Cortex A53 processor 2.2GHz CPU System Memory – 1GB (2x 512MB) DDR3L RAM (Option for up to 4GB) Storage – 8GB eMMC flash, 32MB NOR Flash, 256MB NAND flash, 1x micro SD Card socket Connectivity Wired 5x Gigabit Ethernet (1GbE) RJ45 ports 1x 10Gigabit Ethernet (10GbE) RJ45 port 1x SFP+ Port WiFi On-board 4×4 2.4GHz MU-MIMO 802.11b/g/n/ax WiFi 6 up to 1147Mbps On-board 2x(4×4) or 8×8 5GHz MU-MIMO 802.11a/n/ac/ax WiFI 6 up to 4804Mbps 12x U.FL connectors Cellular – M.2 B-key socket with […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

Linux 5.7 Released – Main Changes, Arm, MIPS and RISC-V Architectures

OK… I’m a bit late on that one. Linus Torvalds released Linux 5.7 last week: So we had a fairly calm last week, with nothing really screaming “let’s delay one more rc”. Knock wood – let’s hope we don’t have anything silly lurking this time, like the last-minute wifi regression we had in 5.6.. But embarrassing regressions last time notwithstanding, it all looks fine. And most of the discussion I’ve seen the last week or two has been about upcoming features, so the merge window is now open  and I’ll start processing pull requests tomorrow as usual. But in the meantime, please give this a whirl. We’ve got a lot of changes in 5.7 as usual (all the stats look normal – but “normal” for us obviously pretty big and means “almost 14 thousand non-merge commits all over, from close to two thousand developers”), So the appended shortlog is only the small stuff that came in this last week since […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

Linux Powered Industrial IoT Gateway Offers WiFi 6, Bluetooth 5.1, 4G LTE Connectivity

Compulab IOT-GATE-IMX8 is a Debian Linux powered fanless Industrial IoT gateway powered by NXP i.MX 8M Mini processor and specially designed for industrial control and monitoring with optional support for WiFI 6 (802.11ax), Bluetooth 5.1, 4G LTE, and GNSS connectivity. The gateway is equipped with up to 4GB RAM and 128GB eMMC flash, takes variable DC input from 8V to 36V, and operates in a wide temperature range of -40C to 80°C with the company providing a 5-year warranty and 15-year availability. Compulab IOT-GATE-IMX8 specifications: SoC – NXP i.MX8M Mini quad-core Arm Cortex-A53 processor @ 1.8GHz with Arm Cortex-M4 real-time core, Vivante 3G and 2D GPU System Memory – 1GB – 4GB LPDDR4 Storage – 4GB – 64GB eMMC flash (soldered on-board), plus secondary storage with optional 16GB – 64GB eMMC flash module Networking & Wireless Connectivity Gigabit Ethernet port, RJ45 connector Fast Ethernet port, RJ45 connector Optional 802.11ax WiFi 6 and Bluetooth 5.1 BLE via Intel WiFi 6 AX200 […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

$31 Honor Router 3 WiFi 6+ Router Supports 3000 Mbps Data Rates

I wrote about the “Most Affordable WiFi 6 Router Yet“, namely Xiaomi Mi Router AX1800, just two days ago, as it sells for around $60 on Aliexpress and 329 CNY ($46) in China. But the Xiaomi router did not hold the top spot for long, as Honor Router 3 WiFi 6 AX3000 router was just launched for 219 CNY (about $31 US) in China. Honor Router 3 (aka Honor XD20) specifications: SoC – Huawei Gigahome W650 dual-core Cortex-A53 processor @ 1.2GHz. Note: Huawei announcement about the processor shows a quad-core Cortex-A53 @ 1.4 GHz, so there may be a dual-core version too? System Memory – 128MB RAM Storage – 128MB flash Networking Wireless 802.11ax/ac/n/a 2×2 & 802.11ax/n/b/g 2×2 MU-MIMO WiFi 6 Transfer Rate – Up to 2976Mbps with 574 Mbps max @ 2.4GHz, 2402 Mbps max @ 5GHz Antennas – 4x 5dBi external antennas Wired – 4x Gigabit Ethernet ports with WAN/LAN adaptation Security – Wi-Fi access authorization, Wi-Fi anti […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

Most Affordable WiFi 6 Router Yet: $60 Xiaomi Mi Router AX1800

[Update May 20, 2020: It did not last long, as Xiaomi Mi Router AX1800 is not the most affordable WiFi 6 router anymore with the launch of Honor Router 3 (XD20) AX3000 router for 219 RMB in China, or about $31 US] When Xiaomi AIoT router AX3600 launched in April for around $135, we noted that while it was the most affordable WiFi 6 router we’d seen so far, the other 802.11ax WiFi 6 routers had also come down in price significantly. But now the company has come up with a really inexpensive router: Xiaomi Mi Router AX1800 which I first discovered on Gearbest for just $67.50, but also available on Aliexpress for about $60 shipped. If you are in China, you should be able to get it for 329 RMB (around $46). Xiaomi Mi Router AX1800 specifications: SoC – Qualcomm IPQ6000 quad-core Arm Cortex-A53 @ 1.2GHz with single-core network accelerator @ 1.5 GHz, called NPU for Network Processing Unit? […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

WiFi 6 Embedded SBC Features Qualcomm IPQ6018 Processor, Gigabit & 2.5Gbps Ethernet Ports

Last year, we covered Dakota DR40x9 Wave-2 AC router board powered by Qualcomm IPQ4019 or IPQ4029 quad-core Cortex-A7 WiSoC, but there’s now a new Qualcomm based embedded SBC supporting WiFi 6. DR6018 (aka AP.CP01 or just CP01) is powered by Qualcomm IPQ6018 quad-core Cortex-A53 WiSoC with 802.11ax WiFi 6, six Ethernet ports including five Gigabit Ethernet, and one 2.5 GbE port, as well an M.2 expansion socket. Specifications: SoC – Qualcomm Atheros IPQ6018 quad-core Arm Cortex-A53 processor @ 1.8 GHz apparently part of Qualcomm Networking Pro 400 platform; 14nm FinFET process System Memory – 1GB (2x 512MB) DDR3L 16-bit interface with 32-bit memory bus design Storage – 256MB NAND Flash, 32MB NOR flash, SD card slot Networking Wired 5x Gigabit Ethernet ports 1x 2.5Gbps Ethernet port Wireless WiFi 2×2 2.4GHz MU-MIMO OFDMA 802.11b/g/n/ax WiFi 6, max 23dBm per chain 2×2 5GHz MU-MIMO OFDMA 802.11a/n/ac/ax WiFi 6, max 20dBm per chain 4x U.FL antenna connectors 2.4 GHz data rate up to […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

MediaTek Dimensity 1000+ 5G Mobile SoC Supports 144Hz FHD+ Displays, 5G UltraSave Technology, and More

MediaTek Dimensity 1000 5G processor for premium mobile devices was announced in Q4 2019 with eight Cortex-A77/A55 cores, an Arm Mali-G77 MC9, and APU 3.0 AI coprocessor. Since then, several companies have announced plans to launch Dimensity 1000 smartphones with products such as Astro Slide 5G Transformer. But while there aren’t any Dimensity 1000 phones available for sale just yet (AFAIK), MediaTek has already announced an updated version with Dimensity 1000+ (Dimensity 1000 Plus). The new version of the processor runs the CPU and GPU cores at the same frequencies, and the differences are instead in other specific features of the processor, as we’ve highlighted below. MediaTek Dimensity 1000+ specification: Processor 4x Arm Cortex-A77 @ 2.6GHz 4x Arm Cortex-A55 @ 2.0GHz DynamIQ heterogeneous multi-processing technology GPU – 9-core Arm Mali-G77 MC9 AI Coprocessor – APU 3.0 hexa-core AI accelerator with 2x big cores, 3x small cores, and 1x tiny core delivering up to 4.5 TOPS. Fully compliant with Android Neural […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

Rockchip RK3588 8K TV Box Triples as 5G & WiFi 6 Router, Home Automation Gateway

Rockchip RK3588 octa-core Cortex-A76/A55 processor was only expected in the second half of 2020 for IoT and vision/AI applications, but at least one company is working on a 3-in-1 product based on Rockchip high-end processor with a “5G AIoT 8K TV box” that also works as a 5G and WiFi 6, and with features such as Zigbee can also act as a home automation gateway. “5G AIoT Android TV Box” preliminary specifications: Main SoC – Rockchip 3588 octa-core processor with 4x Cortex-A76 and 4x Cortex-A55 cores in dynamIQ configuration, Arm “Natt” GPU (i.e. NOT Mali-G31 MP2), NPU 2.0, 8K H.265/AV1 video decoder, 4K video encoder System Memory – 4GB DDR4 Storage – 32GB eMMC flash, MicroSD card slot up to 64GB?! Video Output – HDMI 2.1 up to 8K resolutions Audio – SPDIF audio output, HDMI audio Connectivity 802.11 b/g/n/ac/ax WiFi 6 and Bluetooth 5.1 via Qualcomm QCA6391 WiSoC 1x Gigabit Ethernet port, 1x Fast Ethernet port connected to RK3588 […]
