December 15, 2016December 15, 2016 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Quectel SC20 Smart LTE Modules with WiFi, BLE and GPS Run Android 5.1

Google may just have released Android Things operating systems for IoT applications, but its big brother – Android – has already gotten into some other IoT systems such as Quectel SC20 module powered by a Qualcomm processor and supporting LTE, WiFi, Bluetooth LE, and GNSS functions. Quectel SC20 comes in different flavors to cater for various markets, but all module share most of the same specifications: SoC – Unnamed Qualcomm processor System Memory – TBD Storage – 8GB flash Cellular Connectivity – FDD LTE, TDD LTE, TD-SCDMA, EVDO/DCMA, WCDMA, and GSM; antenna: MIMO 2×2, supports Rx-diversity Other Wireless Connectivity WiFi – 2.4GHz 802.11b/g/n (SC20-CE/-W); Dual band 802.11a/b/g/n/ac (SC20-E/-A/-AU/-J) Bluetooth 2.1+EDR/3.0/4.1 LE GNSS – GPS, GLONASS, and BeiDou Interfaces LCD – 4x lanes MIPI-DSI, 1.5Gbps each, HD (720p) @ 60fps Camera – MIPI-CSI, up to 1.5Gbps per lane, supports two cameras 2-lane MIPI_CSI for rear camera, up to 8MP 1-lane MIPI_CSI […]

December 8, 2016December 9, 2016 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

STMicro SensorTile is a Tiny STM32 Module with Bluetooth 4.1 LE and Four Sensor Chips

STMicroelectronics SensorTile is a 13.5 x 13.5mm sensor board based on STM32L4 ARM Cortex-M4 microcontroller, a MEMS accelerometer, gyroscope, magnetometer, pressure sensor, a MEMS microphone, as well as a 2.4Ghz radio chip for Bluetooth 4.1 Low Energy connectivity for wearables, smart home, and IoT projects. SensorTile hardware specifications: MCU – STMicro STM32L476 ARM Cortex-M4 microcontroller@ up to 80 MHz with 128 KB RAM, 1MB flash Connectivity – Bluetooth 4.1 Smart/LE via BlueNRG-MS network processor with integrated 2.4GHz radio compliant with Sensors LSM6DSM 3D accelerometer + 3D gyroscope LSM303AGR 3D Magnetometer + 3D accelerometer LPS22HB pressure sensor/barometer MP34DT04 digital MEMS microphone I/Os – 2x 9 half holes with access to UART, SPI, SAI (Serial Audio Interface), I2C, DFSDM, USB, OTG, ADC, and GPIOs signals Debugging – SWD interface (multiplexed with GPIOs) Power Supply Range – 2V to 5.5 V Dimensions – 13.5 x 13.5 mm Software development can be done through […]

November 25, 2016 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Sevenhugs Smart Remote is a Universal Direction Aware WiFi, Bluetooth and IR Remote Control (Crowdfunding)

You may have all sort of remote control devices around your home from the traditional IR remote control for your TV, air conditioner, audio system etc.., as well remote control apps for WiFi or Bluetooth objects such as smart light bulbs or water pumps running on your smartphone. Sevenhugs Smart Remote promises to replace them all, and all you have to do is to point the remote control to your devices, or setup virtual actions to your door or window to order a Uber drive or check the weather. Sevenhugs Smart Remote specifications: MCU – ARM Cortex-M4 @ 200 MHz System Memory – 32 MB RAM LCD – 3.43″ touch screen IPS display; Dragontrail damage ans scratch resistant cover glass, anti-fingerprint & anti-glare Wireless Connectivity – IR transceiver, 802.11 b/g/n WiFi and Bluetooth 4.1 LE connectivity USB – USB C port for charging Sensors – Indoor positioning sensor, accelerometer, gyroscope, […]

October 29, 2016October 29, 2016 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

ESP32 Updates – ESP32-S Module Replaces ESP3212, ESP32 DevBoards for Sale, Arduino & NodeMCU Support

There have been some developments with regards to Espressif ESP32 in the last month since my post about upcoming ESP32 development boards. First ESP3212 module is no more, and has been replaced with ESP32-S module with about the same features, but it’s not pin-to-pin compatible, so the new module won’t work with older breakout boards made for ESP3212. ESP32-S is now out of stock on Seeed Studio, but you’ll find it on IC Station, Banggood, and others shops. One good news is that it’s now easier to buy – or at least pre-order – ESP32 development boards, although stock may still be an issue, as the platform is very popular. If you live in the US, you can now backorder “Sparkfun ESP32 Thing” for $19.95. ESP32 board can be powered by either a micro USB power supply or a LiPo battery, and exposes close to 30 I/O pins. ESP32 developer […]

October 28, 2016October 31, 2016 by Jean-Luc Aufranc (CNXSoft) - 12 Comments

NanoPi S2 Quad Core ARM Linux Board Comes with WiFi & BT Connectivity, HDMI, LVDS, and LCD Interfaces

FriendlyARM has released a bunch of Allwinner based NanoPi Allwinner boards recently, but they also have some Samsung/Nexcell S5P ARM Cortex A9 boards in their portfolio, and the latest is NanoPi S2 with Samsung S5P4418 quad core processor, three display interfaces, a camera interface, wireless connectivity through WiFi and Bluetooth 4.0, a 40-pin “Raspberry Pi” header, and more. NanoPi S2 specifications: SoC – Samsung/Nexcell S5P4418 quad core Cortex A9 processor @ 400 MHz to 1.4 GHz with Mali-400MP GPU System Memory – 1 GB DDR3 Storage – 8GB eMMC flash + micro SD slot Video Output / Display I/F – micro HDMI port up to 1080p60, 24-pin LCD RGB interface, 24-pin LVDS interface Audio – 3.5mm audio jack, micro HDMI Camera – 24-pin DVP camera interface Connectivity – 802.11 b/g/n WiFi + Bluetooth 4.0 classic & LE (AP6212 module); IPEX/u.FL antenna connector USB – 1x USB 2.0 Host, 1x micro […]

October 27, 2016March 23, 2018 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

Samsung Introduces $5 ARTIK 0 and $50 ARTIK 7 Smart IoT Module Families

Samsung unveiled ARTIK 1, 3 and 5 boards for the Internet of Things in 2015, and started to sell them, together with development with WiFi, BLE and Zigbee connectivity earlier this year. The Korean company has now announced two new family with ARTIK 0 modules powered by an ARM Cortex-M MCU and destined to be used in HVAC, lighting, industrial sensors, personal health monitoring and more, as well as ARTIK 7 family powered by an Octa-core Cortex A53 processor, and targeting IoT gateways. ARTIK 0 Family ARTIK 0 family is now comprised for ARTIK 020 with Bluetooth, and ARTIK 030 for applications requiring Thread and/or Zigbee. Beside the different radios, both modules share the same key features: MCU – ARM Cortex-M4 up to 40 MHz with Floating Point Unit, 256KB flash, 32 KB SRAM, advanced hardware cryptographic engine with support for AES-128/-256, ECC, SHA-1, SHA-256, and a Random Number Generator […]

October 24, 2016October 25, 2016 by Jean-Luc Aufranc (CNXSoft) - 28 Comments

Beelink GT1 TV Box Review – Part 2: Android Marshmallow Firmware

I’ve previously reviewed other Amlogic S912 TV boxes such as M12N MXQ Plus or Qintaix Q912, but Beelink GT1 has the advantage of being quite cheaper at $56 and up, but still come with many of the same features as more expensive devices. I’ve already posted pictures, and checked out the hardware design in the first part of Beelink GT1 review, so in the second part I’ll report my experience with Android, including video and audio capabilities, hardware features testing, and some benchmarks. First Boot, OTA Firmware Update, Settings, and First Impressions The device comes with two USB ports only, so I connected a USB hard drive to one of the port, and a USB hub to the other with the RF dongles for MINIX NEO A2 Lite air mouse and Tronsmart Mars G01 gamepad, as well as a USB keyboard to take screenshots. I completed the setup by adding […]

October 12, 2016October 12, 2016 by Jean-Luc Aufranc (CNXSoft) - 24 Comments

CHIP Pro is a $16 WiFi and Bluetooth 4.2 System-on-Module Powered by a $6 GR8 ARM Cortex A8 SIP

Next Thing CHIP board and corresponding PocketCHIP portable Linux computer have been relatively popular due to their inexpensive price for the feature set, as for $9, you’d get an Allwinner R8 ARM Cortex A8 processor, 512MB flash, 4GB NAND flash, WiFi & Bluetooth connectivity, and plenty of I/Os, which made it very attractive for IoT applications compared to other cheap boards such as Raspberry Pi Zero and Orange Pi One. The first board was mostly designed for hobbyists, but company has now designed a new lower profile system-on-module called CHIP Pro based on Next Thing GR8 SIP combining Allwinner R8 SoC with 256MB DDR3 RAM that can be used for easy integration into your own hardware project. While the original CHIP board exposed full USB ports and interface for video signal, the new CHIP Pro is specifically designed for IoT with the following specs: SIP – Allwinner R8 ARM Cortex […]
