HawkEye I is a Compact & Lightweight COFDM / DVB-T Video Transmitter with Up to 10 km Range

Shenzhen Falco-Tech Corp has designed a small COFDM transmitter mostly useful for drones, unless you want to make you own very local TV station, that can transmit video from an HDMI camera such as GoPro Hero 4, and compatible with any DVB-T TV tuners as it sends the video unencrypted. HawkEye I DVB-T transmitter specifications: Transmission – COFDM technology Channel bandwidth –  6/7/8MHz (optional) Frequency –  200MHz-2400Mhz (optional) Forward coding – 1/2,2/3,3/4,5/6,7/8 Guard interval – 1/32,1/16,1/8,1/4 Range – Up to 1.5km to 10km SMA antenna connector Video Input – CVBS or HDMI Video Codec – H.264/H.265 encoding with hardware acceleration Resolution – SD/D1/720P/1080p Framerate – 25/30/60 fps Power Supply – 12V via 2-pin terminal Dimensions – 84 x 25 x 90mm (Aluminum case) Weight – 143 grams Operating Temperature Range – -20~60 degrees Celsius There’s no word about power consumption, so it’s unclear how it would impact fly time. I’m […]

Embedded Linux Conference 2016 and OpenIoT Summit 2016 Schedule

The Embedded Linux Conference 2016 and the OpenIoT summit 2016 will take place on April 4 – 6, 2016 in San Diego, California, and over 800 attended will meet including kernel & system developers, userspace developers, and product vendors. The Linux Foundation has recently published the schedule, so I’ve had a look at some of the talks, and designed my own virtual schedule to find out more the current development focus although I won’t attend. Monday April 4 10:40am – 11:30am – Linux Connectivity for IoT by Marcel Holtmann, Intel OTC There are many connectivity solutions that available for IoT. For example Bluetooth Low Energy, 802.15.4, Zigbee, OIC, Thread and others. This presentation will provide and overview of the existing technology and upcoming standard and how they tie into the Linux kernel and its ecosystem. 11:40 – 12:30 – BoF: kernelci.org: A Million Kernel Boots and Counting by Kevin Hilman, […]

Loon Copter is a Drone that Flies, Floats and Dives Underwater

Most drones simply fly, while some robots can dive underwater, but Loon Copter, a project by Oakland University’s Embedded Systems Research Laboratory, can fly, float on the water, and dive underwater just like a duck, hence its name. I could not find much technical details about the drone, but since I discovered it via Atmel on Google+, I assume some soon-to-be Microchip AVR MCUs might be involved. It flies like any quadcopter, then it can land on water and move sideways with the blades rotating in the air. The submerged mode is interesting. The drone fills itself with water until the blades are under water, and then rotates 90 degrees to roam in the water. Once it’s done it ejects the water to get back to the surface. The drone is also equipped with camera and sensors to explore its surroundings. Some potential applications include underwater survey of corals or […]

BeagleBone Blue Board is Designed for Robots and UAVs

Beagleboard.org organization already tried to go Blue with BeagleBone BlueSteel-Basic that was supposed to a the single board computer to be used by OEM to integrate into their design instead of BeagleBone Black development board. For some unknown reasons this never happened, but they’ve now reused the color to introduce BeagleBone Blue board designed for robotics and UAVs. BeagleBone Blue specifications: SoC – Texas Instruments Sitara AM3358 Cortex A8 @ 1 GHz + PowerVR SGX530 GPU System Memory – 512 MB DDR3 Storage – 4 GB 8-bit on-board flash storage Connectivity – 802.11 b/g/n, Bluetooth 4.0 LE USB – USB 2.0 client and host Motor Control – 8x 6V servo out, 4x DC motor out, 4x quad enc in Sensors – 9 axis IMU, barometer “Easy connect Interfaces” – GPS, DSM2 radio, UARTs, SPI, I2C, analog, buttons, LEDs Power / Battery – 2-cell LiPo support with balancing, 6-16V charger input […]

Fleye is a Safe, Robust and Developer Friendly Drone Powered by NXP i.MX6 Processor (Crowdfunding)

In most cases, it’s a pretty bad idea to touch a drone while it’s flying, as you could potentially hurt yourself and others with the blades, so a startup based in Belgium has decided to design a safe drone with the blades hidden under a shell surrounded by protective grids, and with features such as obstacles avoidance. The design also makes the drone sturdier, and less prone to breakage should it fall or hit obstacles. The drone, dubbed Fleye, is based on NXP i.MX6 dual core processor, runs a Linux OS built with the Yocto Project, and the company also plans to provide APIs, and mobile SDKs to allow the developer community to experiment with the drone, and/or create mobile apps. Main hardware features of Fleye drone: SoC – Freescale NXP i.MX6 dual or quad core ARM Cortex A9 processor @ 800 MHz with Vivante GPU System Memory – 512 […]

Manifold mini PC Powered by Nvidia Tegra K1 Processor is Designed for Drones

DJI is known for their high-end drones such as Phantom 3 quadcopter, but the company has now launched Manifold mini PC powered by Nvidia Tegra K1 quad core Cortex A15 processor and running Ubuntu 14.04 in order to allow developers run their own applications performing complex computing tasks and advanced image processing “on the fly”. DJI Manifold specifications: SoC – Nvidia Tegra K1 quad core Cortex-A15 processor @ up to 2.2 GHz with 192-core Kepler GPU System Memory – 2GB DDR3L Storage – 16GB eMMC 4.51 flash, micro SD slot Video Output – mini HDMI port Audio I/O – mini HDMI, combo audio jack for microphone and headphone Connectivity – Gigabit Ethernet port USB – 2x USB 3.0 ports, 2x USB 2.0 host ports, 1x micro USB port (supports Force Recovery mode and Host mode) ,  and a non-standard USB 2.0 interface with the drone. Camera – Camera In and […]

Embedded Linux Conference 2015 Schedule – IoT, Cars, and Drones

Embedded Linux Conference 2015 will take place in San Jose, California, on March 23 – 25, 2015, and will focus on Drones, Things and Automobiles. The schedule has been published, and whether you’ll attend or not, it’s always interested to have a look at what will be talked about to have a peak into the future of Embedded Linux, or simply keep abreast with the progress in the field. So as usual, I’ve gone through the schedule, and made my own virtual program with talks that I find interesting. Monday 23rd 9:00 – 9:30 – Driving standards and Open Source to Grow the Internet of Things by Mark Skarpness, Director of Systems Engineering at Intel Billions of devices are beginning to come online, and many of these devices, large and small, are running open source software.  To fuel this innovation, it’s more important than ever for these devices to use […]

DroneShield – Raspberry Pi Powered Drone Detector

In case you are wary of having drones, such as RC helicopters, quadrotors…, flying around your house and invading your privacy, DroneShield can help you detect consumers’ drones by using a Raspberry Pi, a microphone and FFTW library, a C library for computing the discrete Fourier transform. The device will capture the audio with the microphone, analyze the noise spectrum of the drone flying around, and search for an entry in a signature database, and if a match is found the device will then send an email or SMS to inform you of the “invader”. There are complex challenges to overcome, or limitations, with this method, as any background noise will affect the detection, and drone emitting little noise or flying at high altitude won’t be detected. Spectrum analyses should however help avoid false positives such as a loanmowers and leafblowers as those emit a different kind of noise.They also […]
