We’ve seen a fair amount of Intel Elkhart Lake platforms including modules, 3.5-inch SBCs, Pico-ITX boards, and embedded mini PCs, but so far, I had not noticed any Elkhart Lake mini-ITX motherboard. Advantech AIMB-218 motherboard offers a choice of low-power Atom, Celeron and Pentium Elkhart Processor, and thanks to the larger form factor plenty of I/Os including four display interfaces (DP++/HDMI/eDP/LVDS) supporting up to three display, eight USB port, six serial COM port, and dual Gigabit Ethernet. Advantech AIMB-218 specifications: SoC (one or the other) – Intel Atom x6413E quad-core processor @ 1.50 GHz / 3.0 GHz (Turbo) with 16EU Intel UHD graphics; 9W TDP Intel Celeron N6211 dual-core processor @ 1.20 GHz / 3.0 GHz with 16EU Intel UHD graphics; 6.5W TDP Intel Celeron J6413 quad-core processor @ 1.80 GHz / 3.0 GHz with 16EU Intel UHD graphics; 10W TDP Intel Pentium J6426 (new part) quad-core 2.0 GHz / 3.0 GHz with 32EU Intel UHD Graphics; 10W TDP System […]
A highly reliable performance boost for the edge The new Intel Atom® x6000E Series, Intel Celeron®, and Pentium® N & J processors (code name Elkhart Lake) impress with twice the graphics speed of their predecessors and 50% more multi-thread performance on up to 4 cores. congatec is now making these processors available on the 2.5-inch Pico-ITX form factor, leveraging their industrial quality for the most reliable performance boost possible. With growing digitization and the IoT trend, even the smallest edge computers are expected to meet high-reliability requirements today. Start-ups, makers, and spin-offs from big industrial companies increasingly deploy them in massively distributed applications to implement their new business models and IoT-supported services. They all face a similar challenge: Their apps are approaching market-readiness but their hardware platforms, which often originate from the maker board scene, lack reliability since they were not designed for large series and harsh environments. Industrial edge computing designs, however, must provide highly reliable 24/7 service over […]
Since the launch of the Intel Elkhart Lake IoT Edge processor family, we’ve covered several COM Express modules based on the new low power SoCs including TQ Embedded TQMxE40C1/C2 and Congatec conga-MA7 & conga-TCA7. But despite the processor supporting 2.5GbE, all the computers-on-module we’ve covered so far would only offer Gigabit Ethernet connectivity. But Eurotech CPU-161-19 and CPU-161-20 COM Express Compact Type 6 modules support up to three 2.5 Gbps Ethernet interfaces using COM Express with proprietary expansions, and CPU-161-20 is the first module we’ve seen taking advantage of Intel Atom x6000FE parts with Functional Safety (FuSa) support making the module certifiable with SIL2 Safety Integrity Level (IEC 61508-2:2010) and/or Cat 3 PL=d (ISO 13849-1). As we may infer from the photos above and below, both modules share many of the same features, except for the added functional safety on CPU-161-20. CPU-161-19/20 specifications: SoC CPU-161-19 module Atom x6212RE dual-core processor @ 1.20GHz with 16EU 11th gen Intel UHD graphics @ 250 […]
Since the official launch of the Elkhart Lake processor family last month, we’ve covered a Pico-ITX SBC, a 3.5-inch SBC, and several CoM’s following SMARC, Q7, COM Express, and other system-on-module standards. So far, we had not found any Elkhart Lake mini PCs, but Vecow SPC-6000 fanless embedded PC powered by an Intel Atom x6425RE processor is one of the first such solutions offered from the market, and supports 2.5 Gbps Ethernet with TSN support. Vecow SPC-6000 specifications: SoC – Intel Atom x6425RE quad-core Elkhart Lake processor @ 1.90 GHz with 1.5MB cache, 32EU Intel UHD graphics; 12W TDP System Memory – Up to 32GB DDR4 3200MHz via a single SO-DIMM socket Storage – 1x M.2 Key M Socket (2280, PCIe x2), and 1x SATA III (6Gbps) Video Output DVI-I up to 3840 x 2160 @ 60Hz DisplayPort up to 4096 x 2160 @ 60Hz Audio Realtek ALC892, 5.1 Channel HD Audio codec 3.5mm Line-out jack Networking Gigabit Ethernet (LAN1) […]
German technology company TQ Embedded has unveiled the TQMxE40 computer-on-module families based on the Intel Atom x6000E series, as well as Intel Pentium and Celeron N and J “Elkhart Lake” processors that comply with COM Express Mini, COM Express Compact, and SMARC computer-on-module standards. The company’s TQMxE40M, TQMxE40S, and TQMxE40C1/C2 embedded modules are offered with all twelve Intel Elkhart Lake processors, up to 64GB RAM, and a -40°C to +85°C industrial temperature range. The computers-on-module are especially suited to industrial automation, medical technology, measurement technology, robotics as well as transport and logistics applications. TQMxE40M COM Express Mini Module Specifications: SoC – Intel Atom x6000E Series or Intel Pentium and Celeron N and J Series part of Elkhart Lake family with 4.5 W to 12 W TDP System Memory – 4, 8, 16 GB LPDDR4/4x with IBECC (In-band EEC) Storage – 8 to 256 GB eMMC flash, 32kbit EEPROM COM Express Mini Type 10 board-to-board connectors: Storage – 2x SATA 3.0 […]
Yesterday, Intel introduced the Atom x6000E series together with some Celeron/Pentium processors part of the new Elkhart Lake processor family designed for embedded and IoT applications. We’ve already covered Congatec’s upcoming Elkhart Lake Pico-ITX SBC and CPU modules, but we should expect more related news in the coming days and weeks, and Avalue Technology has just introduced ECM-EHL 3.5-inch SBC powered by Elkhart Lake Embedded SoCs that offers wide voltage input, and industrial temperature range. Avalue ECM-EHL specifications: SoC – Intel Pentium/Celeron/Atom x6000E Elkhart Lake SoC with Intel UHDS Graphics – 4.5 to 12W TDP System Memory – Single 260-pin DDR4 SODIMM socket for up to 32GB DDR4 3200MTs SDRAM (“Factory ECC” supported) Storage 1x M.2 Key-B 2242 socket 1x SATA III connector 256Mbit SPI flash for AMI BIOS Video Output HDMI 2.0b up to 4096×2160 @ 60Hz DP 1.4a up to 4096×2160 @ 60Hz eDP1.3 up to 4096×2160 @ 60Hz 1x LVDS connector Triple independent display support Audio Realtek […]
We’ve been expecting Intel Elkhart Lake processors for more than a year, and the company has now officially announced the “IoT-enhanced processors” with a new Atom x6000E Series, as well as some Celeron and Pentium N/J parts. Last year, we thought Elkhart Lake would succeed Gemini lake, but the new 11th generation 10nm processors may not be found in many consumer devices, as they target IoT edge applications with additional artificial intelligence (AI), security, functional safety, and real-time capabilities. The company has announced a total of 12 Elkhart Lake processors with all but one featuring 10th Generation Intel UHD Graphics and divided into eight Atom x6000E series processors. and four Celeron/Pentium parts Intel further explains Elkhart Lake IoT edge processors deliver up to two times better 3D graphics compared to Pentium J4205 Apollo Lake processor, come with Intel Programmable Services Engine real-time offload engine with support for out-of-band and in-band remote device management, integrated 2.5GbE time-sensitive networking, and enhanced I/O […]
We first found out about Tremont microarchitecture in April 2018 in some Intel documents and Linux mainline source showing it was likely meant to be Goldmont Plus successor. Last year, Intel formally announced Tremont architecture providing some of the details with a block diagram and key features. But this morning, we were informed by email of a new revision of the x86/x64 Software Optimization Manual (PDF) with even further details about Tremont architecture. If you want to know all the details, jump to 4.1 Tremont Architecture section of the document, but here are some of the highlights / improvements over Golmond Plus microarchitecture: Enhanced branch prediction unit. Increased capacity with improved path-based conditional and indirect prediction. New committed Return Stack Buffer. Clustered 6-wide out-of-order front-end fetch and decode pipeline. Banked ICache with dual 16B reads. Two 3-wide decode clusters enabling up to 6 instructions per cycle. Deeper back-end out-of-order windows. Dedicated integer and vector integer/floating-point store data ports. 33% increase […]
