GIGABYTE MZGLKAI is an Industrial Mini-ITX Motherboard Powered by an Intel Gemini Lake Processor

Last month, we got news of Gemini Lake motherboards by ASRock, and GIGABYTE. The former provided decent technical details about their boards, but the latter basically published a more-or-less useless press release about their upcoming J/N motherboards (e.g. J4005N D2P) with very few technical details. The company has now introduced MZGLKAI industrial mini-ITX motherboard featuring an Intel Celeron J4105 core Gemini Lake processor, dual Gigabit Ethernet, five SATA ports, plenty of COM ports, and more. GIGABYTE MZGLKAI (9MZGLKAINR-S) specifications: SoC – Intel Celeron J4105 quad core processor @ 1.50/2.5 GHz with 12EU Intel UHD Graphics 600 up to 750 MHz; 10W TDP System Memory – 2x DDR4 1.2V SO-DIMM slots up to 2400Mhz, 8GB max. Storage – 5x SATA III 6Gbps including 4x via Marvell 88SE9230, 1x from J4105 with SATA DOM support; 3x SATA power connectors Video Output / Display I/F HDMI 2.0a port up to 3840×2160 @ 60 Hz […]

GIGABYTE SynQuacer 96Boards Enterprise Platform is Powered by SocioNext SC2A11 24-core ARMv8 SoC

GIGABYTE, Socionext and Linaro have partnered to design a software development platform compliant with 96Boards Enterprise specifications, with GIGABYTE taking care of manufacturing the hardware based on Socionext SC2A11 processor, while Linaro will provide support via 96Boards community. GIGABYTE SynQuacer platform preliminary specifications (based on photos and SC2A11 specifications): SoC – Socionext SynQuacer SC2A11 24x ARM Cortex-A53 MPCore cores @ up to 1GHz, with 32KB/32KB I/D L1 cache, 256 KB L2 cache, and 4MB L3 cache (5W power consumption) System Memory – 4x DIMM slots for 64-bit DDR4-2133Mbps with ECC up to 64GB Storage – 32GB Samsung KLMBG2JENB-B041 eMMC 5.1 flash + 2x SATA interfaces Connectivity – 2x Gigabit Ethernet (RJ45) with IPSec Network Offload Engine USB – 2x USB 3.0 ports on motherboard (via Renesas D720201), 4x USB ports on front panel via expansion board Audio – 1x microphone input, 1x speaker output on front panel Expansion – 1x PCie […]

GIGABYTE MA10-ST0 Server Motherboard is Powered by Intel Atom C3958 “Denverton” 16-Core SoC

Last year, we wrote about Intel Atom C3000 series processor for micro-servers with the post also including some details about MA10-ST0 motherboard. GIGABYTE has finally launched the mini-ITX board with an unannounced Atom C3958 16-core Denverton processor. GIGABYTE MA10-ST0 server board specifications: Processor –  Intel Atom C3958 16-core processor @ up to  2.0GHz with 16MB L2 cache (31W TDP) System Memory – 4x DDR4 slots for dual channels memory @ 1866/2133/2400 MHz with up to 128GB ECC R-DIMM, up to 64GB for ECC/non-ECC UDIMM Storage 32GB eMMC flash 4x Mini-SAS up to 16 x SATA 6Gb/s ports 2x Mini-SAS ports are shared with PCIe x8 slot Connectivity 2x 10Gb/s SFP+ LAN ports 2x 1Gb/s LAN ports (Intel I210-AT) 1x 10/100/1000 management LAN Video – VGA port up to 1920×[email protected] 32bpp; Aspeed AST2400 chipset with 2D Video Graphic Adapter with PCIe bus interface USB – 2x USB 2.0 ports Expansion Slots […]

GIGABYTE GA-SBCAP3350 Celeron N3350 Single Computer Computer Offers Upgradeable Memory and Storage

The other day I wrote about MeLE PCG35 Apo mini PC which comes with soldered RAM and eMMC flash, and one person commented about having a model with more than 4GB RAM, but I explained it would  not be cost-effective to add more RAM for low cost Windows 10 mini PCs since they would not qualify for Microsoft discount, and it would significantly add to the price. So Microsoft has a big impact on this market segment, and even if you’re going to run Ubuntu or other Linux distributions, those requirements indirectly affect your choice of hardware.  One solution is to buy barebone mini PC, or at least with upgradeable RAM and storage, but there aren’t that many with an Apollo Lake processor. Intel NUC6CAYS NUC or GIGABYTE GB-BPCE-3350 are options, and on the Chinese side, you could consider Voyo V1 VMac Mini. AFAIK, none of those options are fanless, […]

GIGABYTE GA-J3455N-D3H Apollo Lake Mini-ITX Motherboard Comes with 2x Gigabit Ethernet Interfaces, 4x SATA Ports

GIGABYTE has introduced an update to Bay Trail based GA-J1900-D3V and Braswell based GA-N3150N-D3V motherboards with the launch of GIGABYTE GA-J3455N-D3H mini-ITX motherboard powered by an Intel Celeron J3455 Apollo Lake processor, and equipped with two Gigabit Ethernet ports, four SATA interfaces, and support for up to 16GB RAM. GA-J3455N-D3H specifications: SoC – Intel Celeron J3455 quad core processor @ 1.50 / 2.3 GHz with 12EU Intel HD Graphics 500, 2 MB Cache; 10W TDP System Memory – 2x DDR3L SO-DIMM sockets supporting up to 16 GB RAM; Dual channel; DDR3L 1866/1600/1333 MHz non-ECC memory modules supported Storage 2x SATA 6Gb/s connectors (SATA3 0 & 1) via SoC, 2x SATA 6Gb/s connectors (SATA3 2 & 3) via ASMedia ASM1061 chip 1x 64 Mbit flash for licensed AMI UEFI BIOS with PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 Video Output 1x D-Sub port (VGA) supporting a maximum […]

GIGABYTE BRIX IoT Apollo Lake Fanless mini PC is Designed for the Internet of Things, Digital Signage, Thin Clients

GIGABYTE has unveiled BRIX IoT mini PC powered by either Intel Celeron N3450 or Pentium N4200 processor both part of Intel’s Apollo Lake family, and as the name implied the devices target Internet of Things applications. GIGABYTE BRIX IoT specifications: SoC (one or the other) Intel Celeron  N3450 quad core processor @ up to 2.2GHz with Intel HD graphics 500 (6W TDP) Intel Pentium N4200 quad core processor @ up to 2.5GHz with Intel HD graphics 505 (6W TDP) System Memory – 2x SO-DIMM DDR3L slots @ 1333/1600/1866 MHz up to 8GB Storage – 1x M.2 slot, 1x micro SD slot, optional 32 or 64GB eMMC flash Connectivity Dual Gigabit Ethernet via Realtek RTL8111HS Intel Dual band Wireless-AC 3165 module with two SMA antenna connectors 3G via mini PCIe slot and SIM card slot with one SMA antenna connector Video Output – Dual HDMI 1.4b up to 3840×2160 @ 30 […]

GIGABYTE EL-30 Apollo Lake Fanless IoT Gateway Powered by Intel Pentium N4200 to Launch in Q2 2017

GIGABYTE will soon introduce their EL-30 “Intel Apollo Lake IoT Gateway Solution” powered by a quad core Intel Pentium N4200 with 32GB storage, dual Gigabit Ethernet ports, dual HDMI ports, WiFi and Bluetooth connectivity, as well as a mini PCIe slot for 3G module or mSATA storage, and an optional Zigbee module. GIGABYTE EL-30 specifications: SoC – Intel Pentium processor N4200 with 4 cores, 4 threads @ 1.10 – 2.50 GHz with 2MB L2 cache, 18EU Intel HD Graphics 505 (6W TDP) System Memory – 2x SO-DIMM slots for DDR3L 1600/1866MHz memory up to 8GB Storage -32GB eMMC flash + 1x SD card slot + optional mSATA module Video Output – 2x HDMI 1.4b ports up to 3840×[email protected] Hz Audio – Via HDMI ports, 3.5mm audio jack (headphone + mic), Realtek ALC255 audio codec Connectivity 2x GbE LAN ports (Realtek RTL8111HS) Pre-installed WiFi + Bluetooth module in half-size mini PCIe […]

Intel Atom C3000 “Denverton” Processor Targets Low Power Servers

[Update: Some pictures have been removed due to some NDA issues] Intel Atom “Avoton” server processors are the equivalent of Bay Trail processor for mini PCs, laptops and tablets, and with the upcoming release of Apollo Lake processors, Intel has a matching family codenamed “Denverton” that will be used in servers and NAS. Information about the new processors is scarce, but Anandtech spotted an early motherboard prototype last month at Computex. MA10-ST0 motherboard main specifications: SoC – Intel Atom C3000 “Denverton” processor with 4 to 16 cores @ 1.8 GHz; QKP2 code; 14nm process System Memory – 4x RDIMM/UDIMM slots for DDR4 @ 2400 MHz Storage – 4x SATA 3.0 breakout ports supporting up to 16 drives (8x shared with PCIe slot); 32GB eMMC flash Video Output – VGA Connectivity – 2x 10GbE SFP+ ports; 2x Gigabit Ethernet RJ45 ports (via Intel I210); 1x extra RJ45 port (for management?) USB […]
