3.5-inch Atom x6000E embedded SBC features 3x GbE, 2x SATA, 6x USB, and more

3.5-inch Atom x6000E SBC

Several Elkhart Lake SBC’s integrate two Ethernet ports including Avalue ECM-EHL 3.5-inch SBC or Congatec Conga-PA7 Pico-ITX board with the former equipped with 2.5GbE  and GbE ports, and the latter two GbE ports. But if your industrial project requires more Ethernet ports, iBase IB836 3.5-inch Atom x6000E embedded SBC offers three Gigabit Ethernet RJ45 ports, as well as two SATA ports, six USB interfaces, plus various display options, as well as M.2 and mPCIe expansion sockets. iBase IB836 specifications: Elkhart Lake SoC (one of the other) Intel Atom x6425E quad-core processor @ 1.8GHz/3.0GHz, with 1.5MB cache, Intel UHD graphics; 12W TDP Intel Atom x6413E quad-core processor @ 1.5GHz/3.0GHz, with 1.5MB cache, Intel UHD graphics; 9W TDP Intel Atom x6211E dual-core processor @ 1.2GHz/3.0GHz, with 1.5MB cache, Intel UHD graphics; 6W TDP System Memory – Up to 32GB via DDR4-3200 SO-DIMM, with IBECC support Storage – 2x SATA ports, 1x mSATA socket (multiplexed with one SATA port), SPI flash for AMI […]

IBASE Outs Fanless Embedded Systems with AMD Ryzen V1605B, V1202B, R1606G, or R1505G SoC

AMD Ryzen Fanless Embedded Systems

Taiwan based IBASE Technology has launched the ASB200-918 series fanless embedded systems based on the company’s IB918 AMD Ryzen Embedded SBC which we covered last year, runs Windows or Linux distributions, and supports up to 4K displays. ASB200-918-series rugged computers are powered by AMD Ryzen Embedded V1605B/V1202B or R1606G/R1505G processors with 16GB ECC memory, a 64GB SSD,  various I/Os including two HDMI 2.0a output for industrial control, factory, kiosks, and other space-constrained applications. ASB200-918 key features and specifications: SBC – IBASE IB918 3.5-inch single board computer with AMD Ryzen Embedded V1000/R1000-series SoC (V1605B, V1202B, R1606G, or R1505G) System Memory – 2x 8GB DDR4-2666 SO-DIMM, upgradable to up to 32GB RAM, ECC supported Storage – 64 GB TLC 2.5-inch SSD (default), optional M.2 NVMe SSD Video Output – 2x HDMI 2.0a ports up to 4Kp60 resolution Audio – 3.5mm audio jack for Line-out, Line-in, and MIC-in Networking 2x Gigabit Ethernet via Intel Gigabit transceiver Optional WiFi/Bluetooth via M.2 socket 2x antenna […]

AMD Ryzen Embedded SBC Supports 4x 4K Displays Ready for Linux and Windows

The Release of the IB918 SBC The IBASE Technology Inc has released its IB918 3.5″ disk sized SBC, based on the AMD Ryzen V1000 or R1000 SoC with several different options for the base chip system. The new computers can support Windows or Ubuntu and offer several different core options. The Basics The board supports 4 simultaneous 4K displays through 2 HDMI ports, eDP and LVDS, as well as 2x GbE 2.0  and storage options include a SATA III port, and an M.2 NVMe socket.  The supports offer a choice in which SoC can be loaded, either the Ryzen Embedded R1000 SoC or the already marketed and more powerful V1000 which supports both Ubuntu and Windows. Background and other AMD Ryzen Embedded SBC’s AMD Ryzen Embedded R1000 Series SoC’s UDOO BOLT AMD Ryzen Embedded Sapphire FS-FP5R 5×5 Motherboard with the embedded AMD Ryzen R1606G or R1505G processor onboard. IBASE MI988 with the AMD Ryzen Embedded V1000 SoC Mini ITX Motherboard […]

IBase IBR210 i.MX 8M SBC Targets Multi-Display Digital Signage

The latest release from IBase is a single board computer that seems to be designed for the mass business markets, especially in signage. The IBR210 is a 3.5-inch (147 x 102 mm) low-power multimedia SBC based on the NPX ARM Cortex-A53/Cortex-M4 i.MX 8M processor that comes in either a dual or quad-core running in the 1.3 GHz to 1.5 GHz frequency range.  The unit was announced on August 1, 2019, but as of yet there is no pricing information. The GPU is a Vivante GC7000Lite/GC7000VLX, and an integrated Cortex-M4F real-time core, in the i.MX8M. Although for the i.MX8M Mini is a faster and newer SoC, the i.MX8M supports 4K video and HDR. The system runs Android 9 or Yocto v2.5 Linux, with up to 3GB soldered LPDDR4 and up to 64GB eMMC. The video output supports 4K via HDMI 2.0, while there are 2 USB 3.0 ports. The board supports a wide range of environments with a standard operating range […]

iBASE Introduces MI988 Ryzen Embedded V1000 Mini-ITX Motherboard

iBase MI988 Mini ITX Motherboard

iBASE has recently announced the MI988 Mini-ITX motherboard based on the latest AMD Ryzen Embedded V1000 processor family. The motherboard is equipped with two DDR4-2666 SO-DIMM slots that support up to 32GB ECC memory, M.2 NVMEe storage (NVMe), two Gigabit Ethernet ports, and various display options. iBASE MI988 motherboard specifications: SoC – AMD Ryzen Embedded V1000 processor with AMD Radeon Vega GPU System Memory – 2x DDR4-2666 SO-DIMM, supports ECC, up to 32GB Storage – 1x M.2 SSD (NVMe), 2x SATA III Display Interfaces 1x HDMI 2.0a, 1x DisplayPort 1.4 1x eDP or 1x 24-bit dual channel LVDS Audio – Built-in HD audio w/ALC662 codec for 5.1 channel; 3x 3.5mm audio jacks Connectivity – 2x RJ45 Gigabit Ethernet connectors via 2x Intel I211AT USB – 2x USB 3.1 Gen2 (10Gbps) on board, 2x USB 3.1 Gen1 (5Gbps) on board Serial – 2x RS232/422/485 (Jumperless selection), 4x RS232 Expansion Slots 1x PCI-E(x8), 1x Mini PCI-E, 1x M.2 (M-key, type:2230) 8x Digital […]

IBASE AGS100/AGS102 Smart IoT Gateway Targets Industrial Control and Factory Automation

IBASE has introduced AGS100 and AGS102 intelligent IoT gateways powered by an Intel Apollo Lake processor, and specifically geared towards industrial control and factory automation applications. AGS100 can be powered by Intel Atom processor E3950/ E3930 with extended operating temperature (-40°C to 70°C), Intel Pentium N4200, and Celeron N3350 processors (-20°C to 60°C), while AGS102 adds support for two RS232 ports and more GPIOs. Specifications: SoC – Intel Atom E3950/E3930 or Pentium N4200/ Celeron N3350 processor System Memory – 1x 4GB DDR3L-1866 SO-DIMM, up to  8GB Storage – 1x mSATA socket (Mini-PCI-E), 1x 2242 M.2 B-Key socket for mSATA SSD Rear Panel External I/O 1x DVI-I + 1x DisplayPort connector 4x USB 3.0 ports 2x RJ45 Gigabit Ethernet port 3x LED indicators (HDD, WLAN, WWAN) 1x power button with green LED 1x 3-pins DC-in terminal block type for 9-36V DC input 1x Antenna hole for WLAN module AGS102 only – 2x RS232 ports for COM3/COM4, 1x 4-in & 4-out GPIO […]

AMD Launches AMD Embedded R-Series APU Platform

AMD has launched their AMD Embedded R-Series accelerated processing unit (APU) platform designed for mid- to high-end graphics-intensive applications such as digital signage, casino gaming, point-of-sale systems and kiosks, as well as parallel processing applications such as medical imaging and security/surveillance thanks to OpenCL and DirectCompute support. The AMD Embedded R-Series APU combines the “Piledriver” CPU architecture with an AMD Radeon 7000 Series GPU. There are 8 AMD R-Series APUs, 4 in PGA package and 4 in BGA package: R-464L – Quad Core APU @ 2.3/3.2 GHz with Radeon HD 7660G. TDP: 35W (PGA) R-460H – Quad Core APU @ 1.9/2.8 GHz with Radeon HD 7640G. TDP: 35W (PGA) R-272F – Dual Core APU @ 2.7/3.2 GHz with Radeon HD 7520G. TDP: 35W (PGA) R-268D – Dual Core APU @ 3.0/2.5 GHz with Radeon HD 7420G. TDP: 35W (PGA) R-460L – Quad Core APU @ 2.0/2.8 GHz with Radeon HD 7620G. TDP: 25W (BGA) R-452-L – Quad Core APU @ 1.6/2.4 […]

AMD G-Series based iBase SI-08 Digital Signage

Ibase announced the SI-08, a digital signage player with an AMD G-Series processor and a DVI output. The device features a 1.6GHz dual-core T56N processor, up to 2GB of RAM and 1TB of disk storage, gigabit Ethernet,  a serial port, 2 USB port, an audio jack (in or out) as well as a Mini PCI slot for optional Wi-Fi or Bluetooth. Here are the specifications and features of the iBase SI-08 digital signage player: System Mainboard EB900-16-SI CPU Type AMD G-Series Dual-Core APU (Accelerated Processing Unit): T56N=1.65GHz @ 18W TDP CPU Package 413-BGA Chipset AMD A55M Controller Hub Memory DDR3-1333, up to 4GB Graphics ATi Radeon HD6320 series graphics processing system integrated in APU • DirectX 11 • Direct Compute 11 • Open GL 4.0 • OpenCL 1.1 • UVD3 Hardware Video Decoder – MPEG2, MPEG4, H.264, VC-1, WMV9 • Hybrid-DVI connector supporting CRT, DVI, or HDMI devices LAN 1x Realtek RTL8111C PCI-E Gigabit LAN controller Expansion Slots 1x mPCIe(x1) […]
