June 21, 2023June 21, 2023 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

WLKATA Robotics Haro380 is a high precision industrial 6-Axis mini robotic arm (Crowdfunding)

WLKATA Robotics’ Haro380 is a high-precision industrial 6-axis mini robotic arm that can carry a payload of up to 500 grams and designed for education, engineering projects, and light manufacturing. We’ve covered some desktop robotic arms in the past such as the myCobot 280 Pi, but the HARO380 goes a step further with 0.05mm repeatability, a 6-axis harmonic reducer, and zero backlash. It is an upgraded version of the company’s entry-level Mirobot robotic arm introduced in 2019. Haro380 specifications and key features: Control board Unnamed MCU Base interface – RS485, DC power, expansion interface, USB interface I/Os – 2x digital inputs, 2x digital outputs Emergency switch Supply voltage – 24V DC Temperature Range – 5 to 40°C Humidity – 20 to 75% RH non-condensing 6-axis harmonic reducer Magnetic end effectors Repeatability – +/- 0.05 mm Max payload – 500 grams Reach – 380 mm Control interfaces – USB to serial, […]

April 6, 2023 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Queclink WR300FG – A 5G industrial router with GbE, Wi-Fi 6, GNSS, RS232 and RS485 interfaces

Queclink Wireless Solutions WR300FG is a dual SIM 5G industrial router with five Gigabit Ethernet ports, WiFi 6, GNSS, RS232 and RS485 interfaces designed for factory automation, smart energy infrastructure, and Internet of Vehicles (IoV). TheWR300FG is based on a Qualcomm IPQ8072 quad-core Arm Cortex-A53 networking processor running OpenWrt, supports both 5G SA/NSA modes, backward-compatibility with 4G/3G, and its dual SIM features enabled automatic switchover for interrupted 5G connectivity. WR300FG specifications: SoC – Qualcomm IPQ8072 quad-core Arm Cortex-A53 @ 2.2 GHz part of Qualcomm Networking Pro 1200 Platform System Memory – TBD Storage – 1GB flash (described as “hard disk” in the press release!) Connectivity Cellular 5G SA, 5G NSA, 4G LTE, 3G UMTS Operating bands 5G NR – n1/n2/n3/n5/n7/n8/n12/n20/n28/n38/n40/n41/n48/n66/n71/n77/n78/n79LTE-FDD: B1/B3/B5/B7/B8/B18/B19/B20/B26/B28/B32 LTE-TDD: B34/B38/39/B40/B41/B42/B43 WCDMA: B1/B2/B4/B5/B6/B8/B19 2G GSM: 850/900/1800/1900 MHz Data rates 5G SA: DL 2.1Gbps; UL 900Mbps 5G NSA: DL 2.5Gbps; UL 650Mbps LTE-FDD: Max 150Mbps (DL)/Max 50Mbps (UL) […]

March 6, 2023 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Elfin-EW11 is a compact WiFi to RS485 unit with Modbus TCP support

Elfin EW11/EW11A is a small WiFi to RS485 unit with Modbus TCP/IP support that works either in the 5 to 18V DC (EW11) or the 5 to 36V DC (EW11A) input range. The WiFi to RS485 adapter is offered with either an internal or external WiFi antenna, the RS485 interface is exposed through an RJ45 port, and an RJ45 to terminal block cable is usually included, as well as a DIN Rail mount. Elfin EW11/EW11A specifications: MCU (I’m not sure which one is used, and the specs depend on where you look..) Unnamed Arm Cortex-M3 microcontroller @ 96 MHz with 2MB flash, 128KB SRAM (on the product page) OR Unnamed microcontroller @ up to 160MHz with 2MB flash, 352KB SRAM (on Aliexpress) Networking Wireless – 2.4 GHz WiFi 4 with up to WPA2PSK security, station, AP, or station+AP modes; internal or external WiFi antenna depending on the model. Wired – […]

January 20, 2023January 20, 2023 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

LILYGO T-RSC3 ESP32-C3 board features isolated RS232 & RS485 interfaces, 5 to 24V DC input

LILYGO T-RSC3 is a relatively compact ESP32-C3 board with WiFi 4 and Bluetooth LE 5.0 connectivity, support for RS232 and RS485 communication protocols through a DB9 connector and a terminal connector respectively, and a wide 5V to 24V DC power input. LILYGO had already made an ESP32 board with CAN Bus and RS485 interfaces called the T-CAN485, but without any isolation. The new T-RSC3 offers both RS232 and RS485 interfaces, but no CAN Bus, protected by isolated transceiver modules that should make it safer to use in industrial environments. LILYGO T-RSC3 board specifications: Wireless module – Espressif Systems ESP32-C3-MINI-1U module with ESP32-C3 RISC-V microcontroller @ 160 MHz with 400 KB SRAM, 2.4 GHz WiFi 4, Bluetooth 5.0 LE & Mesh, 4MB flash, and a u.FL antenna connector Industrial control interfaces RS232 via DB9 connector, RSM232MT5V isolated transceiver with 3000V isolation, 4.75~5.25V input, 5V/50mA output, baud rate from 1200 to 256,000 […]

October 21, 2022October 25, 2022 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

WisGate Connect Raspberry Pi CM4 gateway supports 2.5GbE, WiFi 6, BLE, LoRaWAN, 4G, 5G, and more

RAKwireless has just introduced the WisGate Connect gateway based on Raspberry Pi CM4 system-on-module with support for Gigabit and 2.5Gbps Ethernet plus various optional wireless connectivity option that can be added through Mini PCIe or M.2 sockets as well as expansion through WisBlock IO connectors. Wireless options include LoRaWAN, 4G LTE, 5G, WiFi 6, Zigbee, WiFi HaLoW, and more, while WisBlock modules enable features such as methane sensor, motor current sensor, temperature sensor, pressure control, and valve control among many others. WisGate Connect (RAK7391) specifications: SoM – Raspberry Pi CM4 with Broadcom BCM2711 quad-core Cortex-A72 processor @ 1.5GHz, 1 to 8Gb DDR4, optional 8 to 32GB eMMC flash, optional WiFi 5 and Bluetooth 5.0 LE Storage – MicroSD card socket for CM4 Lite modules only Video Output – HDMI 2.0 up to 4Kp60, 22-pin MIPI DSI connector Camera I/F – 2x 22-pin MIPI CSI connectors Networking Wired – Gigabit Ethernet […]

March 31, 2022March 31, 2022 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Kontron Pi-Tron CM4 mini PC leverages Raspberry Pi Compute Module 4 for industrial applications

Kontron Pi-Tron CM4 is a single-board computer and mini PC based on the Raspberry Pi Compute Module with a Broadcom BCM2711 quad-core Cortex-A72 processor, up to 8GB RAM, up to 32GB eMMC flash, HDMI video output, two Ethernet ports, optional WiFi and Bluetooth connectivity, and an M.2 slot for AI or wireless expansion. Designed for industrial applications, the Pi-Tron CM4 is also equipped with RS232, RS485/CAN FD bus, and GPIO terminal blocks, supports 24V input voltage, and is optionally sold as AL Pi-Tron CM4 in a housing suited for challenging environments. Kontron Pi-Tron CM4 specifications: SoM – Raspberry Pi Compute Module 4 (CM4) with Broadcom BCM2711 quad-core Cortex-A72 processor @1.5 GHz, VideoCore VI GPU, H.265 (HEVC) up to 4Kp60 decode, 1080p30 encode, up to 8GB LPDDR4, up to 32GB eMMC flash Storage – MicroSD card socket (only for Raspberry Pi CM4 Lite module) Display I/F HDMI 2.0 up to 4Kp60 […]

February 5, 2022February 5, 2022 by Jean-Luc Aufranc (CNXSoft) - No Comments

Lantronix G520 cellular gateways target industrial communication, cybersecurity, and transportation

Lantronix G520-series 4G LTE Cat 4 and 5G cellular gateways are designed to address challenges in Industry 4.0, security, and transportation markets with three/four separate gateways all based on an unnamed ARM926EJ-S-based CPU running at 600 MHz that’s most likely Microchip SAM9X60 processor introduced in 2020. All gateways are from the same base with variation for specific markets: G526 Industrial Gateway with LTE Cat 4 Ethernet, Serial, I/O, Fieldbus conversion, and other industrial protocols G527/G528 Security Gateway with LTE Cat 13 or 5G, built-in cryptographic secure element and PSE-PoE G528 Transportation Gateway (coming soon) with LTE Cat 4, GNSS, accelerometer, CAN Bus reading, and other tracking features Lantronix G520-series specifications: SoC – ARM926EJ-S-based processor running at 600 MHz with 32 KB instruction cache and 32KB data cache System Memory – 256MB DDR2 SDRAM Storage – 8MB SPI flash for OS, 256MB parallel NAND flash, MicroSD slot, or USB flash drive […]

June 29, 2021June 29, 2021 by Jean-Luc Aufranc (CNXSoft) - No Comments

M5Stack Atom DTU LoRaWAN Kit also supports WiFi, RS485, Modbus communication

ESP32 WiFI, Bluetooth, LoRaWAN, and RS485 kit

M5Stack is known for its ESP32 based building blocks for the IoT with WiFi & Bluetooth wireless connectivity, I/O headers, and block-specific features like a tiny color display, a speaker, a touchscreen display, a camera, and more. The company’s latest product is the M5Stack Atom DTU LoRaWAN Kit based on ESP32 ATOM Lite, as well as ASR Micro ASR6501 LoRa module (SX1302 based) and one RS485 header that allows for industrial communication notably with the Modbus protocol. M5Stack Atom DTU LoRaWAN Kit specifications: Wireless connectivity M5Stack ATOM Lite with ESP32 WiFi 4 and Bluetooth 4.2/5.x dual-core SoC ASR ASR6501 LoRa chip Operating frequency – 868MHz or 915 MHz Transmit power – Up to +21dBm RX sensitivity – Up to -137dBm (SF=12/BW=125KHz) Serial communication – UART 115200bps (AT command) via ESP32 Antenna – SMA antenna connector Power consumption @ 3.3V (from ASR6501 datasheet) Tx @ +21dBm – 106 mA Rx – […]
