November 29, 2017November 29, 2017 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Acme CM3-Home is a Raspberry Pi 3 Compatible Board Designed for Home Automation

Raspberry Pi CM3 & CM3L modules are used in so many devices it’s hard to keep up. From NEC digital signage displays, to industrial touch panels, and IoT gateways, the Broadcom BCM2837 based system-on-module are found in more and more products and solutions, and number of announcements seems to have increased over the last few months. The latest product to leverage Raspberry Pi CM3L SoM is made by Italy based Acme Systems, and designed for home automation. CM3-HOME comes with opt0-isolated inputs compatible with KNX and DALI buses, various connectivity options (Ethernet, WiFi, Bluetooth, 868MHz ISM radio…), and other expansion port. Two edition of the boards are available: LITE and FULL, with the former suitable for most home automation project, and the latter adding support for some commercial lighting systems and energy harvesting Radio ISM nodes. Acme CM3-Home specifications: 200-pin SODIMM Module Slot compatible with Raspberry Pi CM3 / CM3L […]

August 18, 2017August 18, 2017 by Jean-Luc Aufranc (CNXSoft) - 16 Comments

$14 Orange Pi R1 Allwinner H2+ Board Comes with Two Ethernet Ports, 256 MB RAM

Shenzhen Xunlong has introduced the new Orange Pi R1 board with Allwinner H2+ quad core Cortex A7 processor that’s a bit different from their other models, as it includes two 10/100M Ethernet port, and should be suitable for intelligent controllers, or simple IoT gateways. Orange Pi R1 board specifications: SoC – Allwinner H2(+) quad core Cortex A7 processor @ 1.2 GHz with Mali-400MP2 GPU System Memory – 256 DDR RAM Storage – micro SD card slot, 16 MB SPI flash Connectivity – 2x 10/100M Ethernet (including on via RTL8152B USB to Ethernet) + 802.11 b/g/n WiFi (Realtek RTL8189ETV) with u.FL antenna connector and external antenna USB – 1x micro USB OTG port Expansion headers Unpopulated 26-pin “Raspberry Pi B+” header 13-pin header with headphone, 2x USB 2.0, TV out, microphone and IR receiver signals Debugging – 3-pin header for serial console Power Supply – 5V via micro USB port Dimensions […]

January 31, 2017January 31, 2017 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

FOSDEM 2017 Open Source Meeting Schedule

FOSDEM (Free and Open Source Software Developers’ European Meeting) is a 2-day free event for software developers to meet, share ideas and collaborate that happens on the first week-end of February, meaning it will take place on February 4 & 5, 2017 this year. FOSDEM 2017 will features 608 speakers, 653 events, and 54 tracks, with 6 main tracks namely: Architectures, Building, Cloud, Documentation, Miscellaneous, and Security & Encryption. I won’t be there, but it’s always interesting to look at the schedule, and I made my own virtual schedule focusing especially on talks from “Embedded, mobile and automotive” and “Internet of Things” devrooms. Saturday 4, 2017 11:00 – 11:25 – Does your coffee machine speaks Bocce; Teach your IoT thing to speak Modbus and it will not stop talking, by Yaacov Zamir There are many IoT dashboards out on the web, most will require network connection to a server far […]

December 16, 2016 by Jean-Luc Aufranc (CNXSoft) - 10 Comments

Kunbus RevolutionPi RevPi Core Raspberry Pi based Industrial Computer Sells with Digital I/O Modules and Fieldbus Gateways

Kunbus, a German company specialized in industrial network solution, has decided to design an industrial system based on Raspberry Pi Computer module supporting variable power supply, a wide temperature range, DIN rail mounting, etc, as well as corresponding digital I/O modules and fieldbus gateways. RevolutionPI RevPi Core specifications: SoC – Broadcom BCM2835 ARM11 processor @ 700 MHz System Memory – 512 MB Storage – 4GB flash Video Output – Micro HDMI port Connectivity – 10/100M Ethernet port USB – 2x USB 2.0 host ports, 1x micro USB port Misc – RTC, 3x status LEDs (2 programmable) Power Supply – 10.7 V to 28.8 V; polarity protection; 4 kV / 8 kV ESD protection & EMI passed (according to EN61131-2 and IEC 61000-6-2), surge and burst tests passed Power Consumption – Max: 10 Watts including 2 x 450 mA USB load; typ.: 4 watts. Dimensions – 96 x 22.5 x 110.5 […]

November 9, 2016 by Jean-Luc Aufranc (CNXSoft) - No Comments

Eurotech EDCK 4001 Everyware Device Cloud Development Kit Includes IoT Gateway, PLC and Demo Board

Eurotech has recently EDCK 4001 “Everyware Device Cloud Development Kit” for professionals who wish to experiment with and/or develop IoT/M2M applications. It includes the company’s ReliaGATE 10-11 IoT gateway powered by Texas Instruments Sitara AM3352 Cortex A8 processor, DirectLOGIC DL05 PLC, and a control/demo board with buttons, LEDs, and rotary encoder, as well as all necessary cables and accessories. ReliaGATE 10-11 gateway specifications: SoC – Texas Instruments AM3352 ARM Cortex A8 processor @ 800MHz Memory – 512MB DDR3 Storage – 4GB eMMC flash, user accessible micro SD Slot Connectivity – 2x 10/100Mbps, WiFi and Bluetooth, optional Cellular connectivity and GPS via ReliaCELL USB – 3x USB 2.0 host ports; noise and surge protected Serial – 2x RS-232/RS-485 (Surge protected, RS-485 termination and Fail-safe Resistors); 1x Serial Console TTL CAN – 2x CAN 2.0b bus with 5V/100mA power out Digital I/O – 2x Digital Input 5V (TTL), 1KV opto-isolated – 2x […]

March 21, 2016March 21, 2016 by Jean-Luc Aufranc (CNXSoft) - No Comments

Avnet Introduces Zynq Based MicroZed Industry 4.0 / IIoT Ethernet Kit

There’s a lot of buzz around IoT, and the industrial sector is also trying to build smarter factories using protocols or standards part of Industry 4.0 or Industrial IoT (IIoT) depending on the country or group you belong too. Avnet has just launched MicroZed Industry 4.0 Ethernet Kit (I4EK) based on Xilinx Zynq-7000 ARM & FPGA SoC to address this market with support for the most common industrial protocols such as EtherCAT, Powerlink, PROFINET RT/IRT, EtherNet/IP, and Modbus-TCP. The “brain” of the development board is MicroZed module powered by Zilinx Zynq-7020 dual core Cortex A9 processor with FPGA fabric, and coupled with 1GB RAM, 128 MB SQPI flash, a Gigabit Ethernet port, and various I/Os. The module is connected to MicroZed FMC Carrier board with the following features: 2x 100-pin board-to-board MicroHeaders Xilinx PC4 header for download/debug – Accesses PL JTAG 5x Digilent Pmod compatible interfaces 39 user I/O 1x […]

March 11, 2016 by Jean-Luc Aufranc (CNXSoft) - No Comments

Axiomtek ICO310 Din-rail Industrial IoT Gateway Supports Power over Ethernet (PoE)

Axiomtek ICO310 is a din-rail IIoT (Industrial IoT) embedded platform powered by Intel Celeron Braswell processors supporting up to 8GB RAM, PoE, and featuring two Gigabit LAN ports, RS-232/422/485 ports, USB 2.0 & USB 3.0 ports, one VGA port, and one DIO interface. It also support mSATA and SATA drives, and wireless module via mPCIe interfaces. Target applications include smart energy, smart factory automation, facility monitoring systems and more. Axiomtek ICO310 Specifications: SoC Intel Celeron N3060 dual core processor @ 1.6GHz / 2.48 GHz (Turbo) with Intel HD graphics 400 with 12EU @ 320/600 MHz OR Intel Celeron N3160 quad core processor @ 1.6GHz / 2.24 GHz (Turbo) with Intel HD graphics 400 with 12EU @ 320/640 MHz System Memory – 204-pin SO-DIMM DDR3L-1600 socket up to 8 GB Storage – 1 x mSATA, 1x SATA SSD (or HDD) Video Output – VGA Connectivity 2x 10/100/1000Mbps Ethernet, including 1x PoE PD […]
