MYiR Introduces Z-Turn Lite Board Powered by Xilinx Zynq-7007S/Zynq-7010 SoC for $69 and Up

Xilinx launched a cost down version of their Zynq-7000 series with Zynq-7000S series SoC combining a single ARM Cortex A9 core with Artix FPGA fabric last year. We’ve already seen sub 100 Euros/Dollars board based on the new SoCs with ZynqBerry and MiniZed boards. MYiR Tech has now launched their own version, a cost-down version of their Z-Turn board, with Z-Turn Lite board featuring either the new cost-down Zynq-7007S or the “good old” Zynq-7010 SoC. Z-Turn Lite specifications: SoC Xilinx XC7Z007S-1CLG400C (Zynq-7007S) with a single ARM Cortex A9 core @ 667 MHz, Artix-7 FPGA fabric with with 23K logic cells, 14,400 LUTs, 66 DSP slices OR Xilinx XC7Z010-1CLG400C (Zynq-7010) with two ARM Cortex A9 cores @ 667 MHz, Artix-7 FPGA fabric with 28K logic cells, 17,600 LUTs, 80 DSP slices. System Memory – 512 MB DDR3 SDRAM (2 x 256MB, 32-bit) Storage – 4GB eMMC flash, 16MB QSPI flash, and […]

MYIR MYS-6ULX is a $25 Single Board Computer based on NXP i.MX 6ULL/6UL Processor for IoT and Industry 4.0

MYIR Tech has released MYS-6ULX single board computer based on  NXP i.MX 6ULL/6UL Cortex-A7 processor designed for either Industry 4.0 with MYS-6ULX-IND model, or the Internet of Things for MYS-6ULX-IOT. Both boards include 256MB DDR3 SDRAM, 256MB NAND flash, USB, USB, Ethernet, LCD interfaces and more, in a compact 70 x 55mm form factor. Both boards have very similar specifications. Features MYS-6ULX-IND MYS-6ULX-IOT SoC NXP i.MX 6UltraLite (MCIMX6G2CVM05AA) with an ARM Cortex A7 processor @ up to 696 MHz and 2D graphics accelerator NXP i.MX 6ULL (MCIMX6Y2DVM05AA) with an ARM Cortex A7 processor @ 528 MHz and 2D graphics accelerator DDR3 256MB (support up to 2GB) NAND Flash 256MB (support 512MB/1GB) eMMC DNP (Do Not Populate – Reserved design for optional 4GB flash) Ethernet 10/100Mbps USB 1x USB Host, 1x micro USB OTG Micro SD Card 1x Micro SD card slot Buttons 1x Reset Button, 1x User Button LED 1x Power Indicator, 2x […]

MYiR Tech MYC-JA5D2X System-on-Module is Powered by Microchip ATSAMA5D2 Cortex A5 Processor

MYIR Tech has released MYC-JA5D2X system-on-module powered by a Microchip Atmel SAMA5D2 ARM Cortex A5 processor with 256MB flash, and 256 MB DDR3. The module relies on a SO-DIMM edge connector to expose the camera interface, Ethernet, USB, camera, and other I/O signals. MYC-JA5D2X CPU module specifications: SoC – Atmel SAMA5D26 or SAMA5D27 ARM Cortex A5 processor @ up to 500 MHz with 128KB L2 cache System Memory – 256MB DDR3 SDRAM Storage – 256MB NAND flash, 4MB data flash, 64KB EEPROM Connectivity – On-board 10/100M Ethernet PHY 200-pin SO-DIMM edge connector with: 1x Ethernet 1x USB Host, 1x USB Device, 1x USB HSIC (HSIC is only for SAMA5D27) Up to 10x serial ports, up to 2 x CAN (only for SAMA5D27) Up to 7 x I2C, up to 7 x SPI Up to 2 x QSPI 12 x 12-bit ADC (enhanced resolution up to 14 bits) 4x PWM 1x […]

MYD-C437x-PRU Development Board Leverages TI Sitara AM437x Programmable Real-time Unit

MYIR Technologies launched MYC-C437x system-on-module based on TI Sitara AM437X processor, and the corresponding MYD-C437x development board at the end of 2015, but the latter did not make use of the processor’s PRU-ICSS (Programmable Real-Time Unit Subsystem and Industrial Communication SubSystem) block. The company has now released a new version of the baseboard called MYC-C437x-PRU which exposes I/Os pins to leverage the PRU-ICSS and enable implementation of protocols like EtherCAT and Profibus.MYD-C437x-PRU industrial development board specifications: System-on-Module – MYC-C437x module with SoC – Texas Instruments AM437x ARM Cortex A9 processor @ up to 1GHz with PowerVR  SGX530 GPU (AM4378/AM4379 only) System Memory – 256 or 512MB (default) DDR3 SDRAM Storage – 4GB eMMC Flash (reserved 256/512MB Nand Flash design), 16MB QSPI Flash (unpopulated by default), 32KB EEPROM Connectivity – Gigabit Ethernet PHY Storage – 1x micro SD slot Serial ports – 1x 3-wire RS232 debug serial port, 2x  5-wire RS232 serial […]

MYIR Tech Latest SoM and Development Board Feature Xilinx Zynq-7015 ARM + FPGA SoC with 4 High Speed Transceivers

MYIR Tech launched the low cost Z-Turn board powered by Xilinx Zynq-7010/7020 ARM+FPGA SoC last year, and the company has now introduced a new system-on-module powered by Xilinx Zynq-7015 SoC as well as a corresponding development kit. MYC-C7Z015 CPU Module specifications: SoC – Xilinx XC7Z015-1CLG485C (Zynq-7015) dual core ARM Cortex-A9 processor @ 667 MHz (up to 866MHz) with Artix-7 class FPGA subsystem with 74K logic cells, 46,200 LUTs, 160 DSP slices, 4x high-speed SerDes transceivers up to 6.25 Gbps, 4x four PCIe Gen2 hardened, integrated IP blocks System Memory – 1GB DDR3 SDRAM Storage – 4GB eMMC flash, 32MB QSPI Flash (16MB optional) Connectivity – 1x Ethernet PHY, 1x USB PHY I/Os and peripherals via 2x 140-pin board-to-board connectors: 1x Gigabit Ethernet 1x USB OTG 2.0 Up to 2x serial ports, up to 2x I2C, up to 2x CAN BUS, 1x SPI 1x independent differential ADC, 16-channel ADC 1x SDIO […]

MYiR Tech Introduces Atmel SAMA5D4 CPU Module and Development Board

MYiR Tech has launched a new development board – MYD-JA5D4X – featuring their Atmel SAMA5D4 Cortex A5 system-on-module called MYC-JAD5D4X with 512MB DDR2, 512MB Flash, and various ports such as Fast Ethernet, RS485, LCD panel interface, USB connectors and so on. Target applications include control panel/HMI, fitness equipment, smart grid infrastructure, communications gateways, and imaging terminals among others. Let’s start wit the MYC-JAD5D4X CPU module specifications: SoC – Atmel SAMA5D42 or SAMA5D44 ARM Cortex-A5 processor @ up to 600MHz (945DMIPS) with NEON and FPU, 720p hardware video decoder (SAMA5D44 only) System Memory–  512MB (2x 256MB) DDR2 SDRAM Storage – 512MB NAND Flash, 4MB Data Flash, 64KB EEPROM Connectivity – On-board Ethernet PHY I/Os via 200-pin SO-DIMM edge connector 2 x Ethernet 3 x USB2.0 Host 8 x Serial ports 4 x TWI,  3 x SPI 5 x 12-bit ADC 1 x SMD 4 x 4-bit SDIO 1 x LCD 1 x ISI 7 […]

MYIR Tech Introduces TI Sitara Cortex A9 MYC-C437X SoM and MYD-C437X Development Board

MYIR Tech previously launched Ricoboard, a low cost single board computer powered by Texas Instruments AM4379 ARM Cortex A9 processor. The company has now introduced a system-on-module based on Sitara AM437x processors, as well as a corresponding carrier board for industrial applications. MYIR Tech MYC-C437x Sitara AM437x System-on-Module MYC-C437x SoM specifications: SoC – Texas Instruments AM437x single core ARM Cortex A9 processor @ up to 1GHz (AM4376, AM4377, AM4378, AM4379) with PowerVR  SGX530 GPU (for AM4378/AM4379) System Memory – 512MB DDR3 (256MB optional) Storage – 4GB eMMC Flash (reserved 256/512MB Nand Flash design), 16MB QSPI Flash (unpopulated by default), 32KB EEPROM Connectivity – Gigabit Ethernet PHY Peripherals and signals via 2x 100-pin board to board connectors (0.8mm pitch): 2x Gigabit Ethernet 2x USB 6x Serial ports, 2 x CAN 2x I2C, 2 x SPI 14x ADC (8 channels from ADC1 and 6 channels from ADC0) 3x SDIO 2x Camera interfaces JTAG […]

MYiR Tech Announces Low Cost Rico and Z-turn Boards Powered by TI AM437x and Xilinx Zynq-7010 SoCs

Shenzhen based MYIR Tech has just launched two new single board computers with Rico board featuring Texas Instruments Sitara AM437x ARM Cortex A9 industrial processor, and Z-Turn board based on Xilinx Zynq-7010 ARM Cortex A9 + FPGA SoC. Both boards sell for $99 in single quantity. Rico Board Specifications: SoC – Texas Instruments AM4379 single core ARM Cortex A9 processor @ 1.0GHz with PowerVR SGX530 GPU, and 4x PRU @ 200 MHz. Other AM437x on request. System Memory – 512MB DDR3 (Options: 256MB or 1GB) Storage – 4GB eMMC, 256 or 512 MB NAND flash (reserved), 16MB QSPI flash, 32KB EEPROM, and micro SD slot Video Output – HDMI and LCD interfaces (LCD connector located on bottom of the board). Connectivity  – 10/100/1000 Mbps Ethernet USB – 1x mini USB 2.0 device port, 1x USB 2.0 host post Camera – 2x 30-pin camera interface Debugging – 1x debug serial port, […]
