Tiger Canyon Porcoolpine fanless Tiger Lake NUC announced for $679 and up

Fanless Tiger Lake NUC

Simply NUC “Tiger Canyon Porcoolpine” is a fanless Intel NUC offered with a choice of Tiger Lake UP3 processors, notably Core i3-1115G4, Core i5-1135G7, and Core i7-1165G7, and equivalent vPro parts when available. The mini PC comes with up to 64GB DDR4, NVMe & SATA storage, a Thunderbolt 4 port, two HDMI 2.0b ports, 2.5 GbE networking, and optional Wi-Fi 6 and Bluetooth 5.1, as well as a DB9 serial port for industrial applications, for example, to connect a barcode scanner. Tiger Canyon Porcoolpine (NUC11TF) specifications: SoC (one or the other) Intel Core i3-1115G4 dual-core/quad-thread processor @ up to 3.0 / 4.1 GHz (Turbo) with 6MB L3 cache, 48EU Intel Xe graphics; 28W TDP Intel Core i5-1135G7 quad-core/octa-thread processor @ up to 2.4 / 4.2 GHz with 8MB L3 cache, 80EU Intel Xe graphics; 28W TDP Intel Core i5-1145G7 (vPro) quad-core/octa-thread processor @ up to 2.6 / 4.4 GHz with […]

ASRock Industrial announces Intel Elkhart Lake mini PCs and motherboards

Intel Atom x6000E Series, Celeron, and Pentium Elkhart Lake processors for IoT Edge applications were launched in September 2020, with many companies shortly introducing modules, single board computers, motherboards, and industrial, rugged mini PCs after the official announcement. ASRock Industrial took more time to announce their Elkhart Lake offerings, with three families of hardware platforms with NUC 6000 BOX Series and IBOX 6000 Series mini PCs, as well as NUC 6000 Motherboard series. We’ll have a look at the three families in detail below, mostly using information from products based on Celeron J6412, one of the more recent Elkhart Lake processors that was launched in Q1 2021. ASRock NUC 6000 Motherboard Series Specifications: SoC (one or the other) Intel Celeron J6412 quad-core processor @ 2.0/2.6 GHz (Turbo) with 1.5MB cache, 16 EU Intel UHD Graphics; 10W TDP Intel Celeron N6210 dual-core processor @ 1.2/2.6 GHz (Turbo) with 1.5MB cache, 16 […]

Intel Atlas Canyon NUC to feature Jasper Lake J-Series processors (Leak)

Intel Atlas Canyon NUC

Intel Jasper Lake N-series low-power processor family was introduced as an update to the Gemini Lake family last January, and the first Jasper Lake mini PC’s have just started to show up with mass production scheduled in mid-May. But now, courtesy of FanlessTech, we have more information about Intel Atlas Canyon NUC that will be offered with a choice of three Jasper Lake processors, namely Pentium Silver J6005, Celeron J5105, and Celeron J4505, all of which are J-series, and have yet to be announced/listed on Intel Ark website. Intel NUC 11 Essential “Atlas Canyon” specifications: SoC NUC11ATKPE – Intel Celeron J4505 dual-core processor clocked at 2.0 GHz / 2.7 GHz (Burst) with Intel HD Graphics @ 750 MHz NUC11ATKC4 – Intel Celeron J5105 quad-core processor clocked at 2.0 GHz / 2.9 GHz with Intel HD Graphics @ 800 MHz NUC11ATKPE – Intel Pentium Silver J6005 quad-core processor clocked at 2.0 […]

Intel NUC M15 Laptop Kit serves as an Evo-qualified Tiger Lake laptop reference design

Intel NUC M15 Laptop Kit

Intel NUC mini PCs or mini Desktops have been around for over 8 years, but now Intel has just announced an NUC laptop kit. Wait… What? Yep, NUC just stands for “Next Unit of Computing”, so it can be any kind of computer, and the company’s latest NUC is Intel NUC M15 laptop kit (codenamed “Bishop County”) powered by an Intel 11th generation Tiger Lake processor. The NUC M15 laptop kit complies with Project Athena that aims for thin laptops with fast response times and long battery life and targets the whitebook market, so Intel customers can use it as a reference design meeting Intel Evo platform brand requirements. Intel NUC M15 laptop kit (LAPBC710 and LAPBC510) specifications: SoC LAPBC710 – Intel Core i7-1165G7 quad-core/octa-thread Tiger Lake processor @ up to 2.8 GHz (base) / 4.7 GHz (Turbo single-core) / 4.1 GHz (Turbo all-core) with 12M Cache, 96 EU Intel […]

Intel NUC 9 Extreme “Ghost Canyon” Kit – NUC9i9QNX Review

NUC9i9QNX Review

I’ve previously written about Intel’s (relatively) new NUC 9 range of mini PCs and now I am following up with my experiences of having bought one. Whilst I’ll cover some performance metrics from both Windows and Ubuntu I’ll also discuss the benefits and drawbacks of using either OS together with a comparison of gaming, thermals, and power usage as well as a brief look at overclocking potential and implications together with highlighting the issues encountered. NUC9i9QNX Hardware Overview The model I purchased and will be reviewing here is the NUC9i9QNX from Intel’s Ghost Canyon lineup and is formally known as the Intel NUC 9 Extreme Kit – NUC9i9QNX. It contains a “Compute Element” with an i9-9980HK which is an eight-core 16-thread 2.40 GHz processor boosting to 5.00 GHz with Intel’s UHD Graphics 630. The full specifications of the NUC9i9QNX include: The NUC9i9QNX is sold as a kit which essentially means […]

19″ Rackmounts Support up to 12 Raspberry Pi SBCs

4x Raspberry Pi Rackmount

Last time, we wrote about myelectronics.nl we covered their Tesla Cybertruck Case for Intel NUCs which housed the mini PC into a mini CyberTruck looking enclosure. The company has now come up with new housing solutions specifically designed for Raspberry Pi 1/2/3/4 Model B/B+ boards. The 19″ rackmounts support one to twelve Raspberry Pi SBCs and can be used for Raspberry Pi clusters, video walls, and so on. The 4-board model fitted with four Raspberry Pi 4 boards caught my attention as it also offers an option to bring the HDMI outputs on the same side as USB and Ethernet port like in Argon One case but with more convenient full-sized HDMI ports. The other Raspberry Pi rackmount model allows you to insert up to 12 Raspberry Pi board in a vertical position with optional HDMI ports as shown above. That’s great for density, but you may have to take […]

Introducing the Intel NUC 9 Compute Elements, Mini PC Kits, and 3rd-Party Ecosystem

Intel NUC 9 Mini PC

Intel’s NUC mini PC range is familiar to anyone who has looked for a very small compact and functional PC. But they, and similarly sized mini PCs in general, have a notable limitation when compared to desktops and also many high-end laptops in that the graphics performance is somewhat restricted because it is typically provided by the processor’s integrated graphics. Whilst these integrated graphics are suitable for browsing, video playback, and the office style applications that the devices have been marketed towards, they are normally insufficient for gaming as only low framerates are obtainable. Intel initially tried to address this gaming shortfall through the introduction of the Intel Skull Canyon (NUC6i7KYK) NUC which came with a 6th-gen Skylake Core i7-6770HQ that included Iris Pro Graphics 580 and at the time with their 72 EUs (Executions Units) was Intel’s most powerful integrated GPU. Additionally, the Skull Canyon also featured a (USB-C) […]

Intel Austin Beach is a Modular, Fanless NUC Powered by Intel NUC Compute Elements

Intel Austin Beach NUC + Chandler Bay NUC Compute Element

Unveiled last May, Intel NUC Compute Element is a family of cards that should cost less than the failed Computer Cards, and easy to handle than your typical computer-on-module. The first Compute Elements showcased at Computex 2019 were powered by a 15-Watt Core U-series processor, and now various models will find their way into Intel Austin Beach fanless NUC with “Chandler Bay” NUC Compute Elements powered by Whiskey Lake processors. Intel Austin Beach specifications: Chandler Bay Compute Element (one or the other, all 15-W Whiskey Lake) BKCM8CCB4R – Intel Celeron 4305U 2-core/2-thread processor with 4GB LPDDR3, 64GB eMMC storage BKCM8PCB4R – Intel Pentium Gold 5405U 2-core/4-thread processor with 4GB LPDDR3, 64GB eMMC storage BKCM8i3CB4N – Intel Core i3-8145U 2-core/4-thread processor with 4GB LPDDR3 BKCM8i5CB8N – Intel Core i5-8265U 4-core/8-thread processor with 8GB LPDDR3 BKCM8v5CB8N – Intel Core i5-8365U 4-core/8-thread vPro processor with 8GB LPDDR3 BKCM8i7CB8N – Intel Core i7-8565U 4-core/8 […]
