Telechips TCC898x (Alligator) 64-bit ARM SoC is Designed for High-end 4K Set-Top Boxes

Telechips processors were often found in consumer devices such as Android tablets, mini PCs and TV Sticks a few years ago, but it’s been a while since I have seen a devices based on Telechips. So after seeing an automotive SoC from the company, I decided to visit the company website to check if they were still designing processors for the consumer market, and found TCC898x quad core Cortex A53 processor for “Smart Stick, IP-Client and STB with 4K 60fps decoding” with some interesting features. Telechips TCC898x SoC specifications: CPU- Quad core Cortex A53 processor with NEON, TrustZone, 32KB/32KB L1 cache and 512KB L2 cache MCU – Cortex-M4 micro-controller GPU 2D – Vivante GC420 composition processing core for 4K user interfaces 3D – ARM Mali-400MP2 VPU – Multi-format VPU and 4K VPU with HEVC and VP9 support Memory I/F – DDR3/4 Storage I/F – NAND controller (60-bit ECC), SD/eMMC controller […]

April 25, 2014 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

How to Root Mele X1000 (Telechips TCC8935)

Yesterday, I’ve explained to how update firmware on Telechips TCC8935 Android TV boxes, Mele X1000 more exactly. Today I’ll show how to root the device. The method uses Vroot, a Windows-only tool, that appears to be popular recently, as it is the same tool that’s used to root Amlogic S802 based devices. Let’s get started in a Windows PC or virtual machine: Download and install Vroot Start Mele X1000, and go to Settings->Android Settings, then in Developer options, enable USB debugging Connect a micro USB to USB cable between Mele X1000 and your Windows PC Start Vroot,. It should detect your device, download and install drivers and a daemion. Check root access in your device, and a Windows in your default language may pop up in Mele X1000. Accept. You should now see “Mele X1000 is connected. No root permissions” in Vroot, click on the green Root button to start […]

April 24, 2014April 25, 2014 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

How to Update Firmware on Mele X1000 (Telechips TCC8935)

Mele X1000 is a Android Blu-Ray Navigation media player powered by Telechips TCC8935 dual cortex Cortex A9 SoC. I’ve already reviewed the device, and I had received an updated firmware a short while, after my review. I won’t do a full test again, but I’ll just document how to perform a firmware update on Mele X1000, and the method should be similar with other Telechips TCC893x devices. This method requires a computer running Windows 2000, XP, Vista or 7. I’m not sure if it supports Windows 8.x. I’ve tried the method in VirtualBox running Windows 7 guest OS, and a netbook running Windows XP. In theory, it should also work in VirtualBox, but my computer running Ubuntu 14.04 failed to recognize the required USB connection. Let’s start by downloading MeLE_X1000_V4_00.20140305.19.zip, the latest firmware for Mele X1000 with the following Changelog: Solved bug: X1000 crashes when loading Hebrew subtitle for the movie. […]

March 27, 2014March 27, 2014 by Jean-Luc Aufranc (CNXSoft) - 19 Comments

Review of Mele X1000 Blu-Ray Android TV Box (Telechips TCC8935)

Mele X1000 is an Android media player based on Telechips TCC8935 dual core Cortex A9 that is said to support Blu-ray video playback. You can refer to Mele X1000 specs for more technical details, as well as my previous Mele X1000 Unboxing post for pictures of the device, as well as the PCB. Today I’ll review Mele X1000, by showing off the user interface, and going through the different settings, test video playback including a Blu-ray ISO, wi-fi performance, and report whether all other features such as Bluetooth, USB mass storage, USB webcam, etc… work as expected. First Boot, Settings and First Impressions This media player comes with an infrared remote and corresponding AAA batteries, but during most the tests I’ve actually switched to Mele F10 RF remote (not included) as it’s just more convenient to navigate menus, and I’ve also test an Android Remote app compatible with the device, […]

February 12, 2014 by Jean-Luc Aufranc (CNXSoft) - 21 Comments

Telechips TCC892X/TCC893X Android 4.2.2 SDK Leaked

I’ve been informed that an Android 4.2.2 SDK for Telechips TCC892x and the newer TCC893x (TCC8930, TCC8933, TCC8935) dual core SoCs has been leaked on the Internet. The file (v13.03_r1-tcc-android-4.2.2.tar.bz2) is a 2.7GB tarball, and appears to be a full SDK. You can download the file here if you are interested. After extraction, there’s 6.7 GB of data in the following directories: 40M ./libcore 5.8M ./docs 31M ./ndk 5.0M ./gdk 1.2G ./frameworks 324K ./pdk 95M ./development 18M ./bionic 544M ./kernel 228M ./device 106M ./hardware 24M ./bootable 295M ./packages 55M ./sdk 151M ./cts 2.4G ./prebuilts 1.7G ./external 40M ./dalvik 9.1M ./system 108K ./libnativehelper 6.9M ./build 104K ./abi 47M ./vendor The linux kernel is based on Linux 3.1.10, and there are a few config files to choose from with configs forh HDMI TV dongles, micro PCs, STBs, and evaluation boards for TCC8930, TCC8935, TCC8920 and TCC8925.

kernel/arch/arm/configs$ ls tcc*
tcc8920st_defconfig          tcc8935st_dongle_single_defconfig
tcc8925st_dongle_defconfig   tcc8935st_upc_defconfig
tcc8925st_upc_defconfig      tcc8935st_upc_single_defconfig
tcc8925st_yj8925t_defconfig  tcc8935st_yj8935t_defconfig
tcc892x_defconfig            tcc8935st_yj8935t_single_defconfig
tcc8930st_defconfig          tcc893x_defconfig
tcc8930st_single_defconfig   tcc893x_single_defconfig
tcc8935st_dongle_defconfig

kernel/arch/arm/configs$ ls tcc*

tcc8920st_defconfig tcc8935st_dongle_single_defconfig

tcc8925st_dongle_defconfig tcc8935st_upc_defconfig

tcc8925st_upc_defconfig tcc8935st_upc_single_defconfig

tcc8925st_yj8925t_defconfig tcc8935st_yj8935t_defconfig

tcc892x_defconfig tcc8935st_yj8935t_single_defconfig

tcc8930st_defconfig tcc893x_defconfig

tcc8930st_single_defconfig tcc893x_single_defconfig

tcc8935st_dongle_defconfig

YJ8925T boards supports HDMI and […]

February 10, 2014 by Jean-Luc Aufranc (CNXSoft) - 34 Comments

$50 Hotach HTV003 Android Media Player is Powered by Telechips TCC8935 SoC

The last few months have been pretty quiet in terms of new Android mini PCs and media players, at least when it comes to new platforms. But finally there’s something new, as Telechips TCC893x based devices are starting to show up on the marketplace. The devices won’t beat performance records as the new Telechips SoC features a dual core Cortex A9 processor with a Mali-400MP2 GPU, but they’ll be very affordable. Hotach HTV003 is one of the first media player powered by Telechips TCC8935, and sells for $50 on Aliexpress. Hotach HTV003 specifications: SoC – Telechips TCC8935 with two ARM Cortex A9 cores up to 1GHz, one Cortex M3 core, and an ARM Mali-400MP2 GPU System Memory – 1GB DDR3 Storage – 4GB NAND Flash + micro SD card slot up to 32 GB Connectivity – Ethernet, 802.11 b/g/n Wi-Fi Video Output – HDMI Audio Ouput – HDMI USB – 2x […]

January 20, 2014 by Jean-Luc Aufranc (CNXSoft) - 24 Comments

Telechips TCC893x Dual Core ARM Cortex A9 + Cortex M3 SoCs: TCC8930, TCC8933, TCC8935

Sometimes last year, Telechips discreetly released a triple core SoC comprised of 2 ARM Cortex A9 cores and one Cortex M3 core for tablet, set-top boxes, media player and car AVN (Audio, Video & Navigation). A dual core release in 2013 may not be that interested, but the addition of a Cortex M3, and high performance interfaces such as Gigabit Ethernet and USB 3.0 may make it interesting. Let’s have a look. There’s very little information on Telechips TCC893x page, apart from the block diagram above and the following description: The TCC893x is a system-on-chip with powerful multimedia solution and high performance such as dual decoding. It is ideal for high-end multimedia devices such as Set top box, Media Box, Car AVN, and Tablet. TCC893x multimedia application processor based on Cortex-A9 Dual & M3 has multi-format hardware video accelerator optimized to reduce power consumption, high-performance 2D/3D graphic engine for rich […]

November 10, 2012November 11, 2012 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

$444 Smartbeam Android 4.0 Media Player & Projector Powered by Telechips TCC8925

Android is now everywhere, from the ubiquitous smartphones and tablets to cars, cameras, satellites (no kidding), light bulbs (seriously) and more. Today is the first time I’ve come across a full sized projector running Android. The “Smartbeam” is a 2000 lumens 1280×768 (native) projector powered by Telechips TCC8925 with 512 MB RAM and 4 GB Flash running Android 4.0.4 (ICS), so the performance should be very similar to CX-01 mini PC. Here are the specs of this new device: SoC – Telechips TCC8925 up to 833 MHz System Memory – 512 MB RAM Storage – 4 GB NAND Flash WiFi – 802.11 b/g/n Display – 5.8″ Single LCD Panel Display Technology (cnxsoft: But I can’t find any display on any of the pictures…) Projector: Projection Lens – Manual Lens Resolution: Native SGA (1280*768 Pixels), Support Resolution QGA (1920 x 1200) Brightness (Typical) – LED lamp 2000 lumens, more than 320Lux […]
