The 5 best Intel & AMD single board computers for makers

Best Intel AMD single board computers for makers

A few weeks ago, we wrote a list of what we consider to be the top 5 most powerful Arm SBC’s and development kits, and this time around we’ll cover x86 SBC’s powered by Intel or AMD processors. But this time around, instead of focusing on the most powerful x86 single board computers which would lead to unaffordable, industrial Xeon SBC’s, we’ll be looking into the 5 best boards designed for makers. That means affordable pricing, I/O headers, and community support. The list is in no particular order. Rock Pi X – x86 on the cheap If you ever wanted the cheapest possible x86 board, Atomic Pi SBC $35 price tag was hard to beat, but it was only cheap because it was sourced from a failed robotics project, and not very convenient to use. But now in 2021, the cheapest x86 SBC that can run Windows is clearly Rock […]

UDOO BOLT GEAR AMD Ryzen Embedded V1605B Mini PC with Arduino Subsystem Launched for $399

UDOO BOLT GEAR

UDOO BOLT was one of the first AMD Ryzen Embedded V1000 SBC‘s ever announced with a choice of Ryzen Embedded V1202B or V1605B dual-core/quad-core processor, and a Microchip ATmega32U4 MCU for real-time I/Os and Arduino compatibility. The company has now launched UDOO BOLT GEAR mini PC based on UDOO BOLT V8 SBC at a promotional price of $399 excluding taxes and shipping. [Update:  code VOLUMIOGEAR might work to get a €60 discount] UDOO BOLT GEAR specification: SoC – AMD Ryzen Embedded V1605B quad-core/eight-thread processor @ 2.0GHz (3.6GHz boost) with Radeon Vega 8 graphics with support for Directx 12, OpenCL, OpenGL, Vulkan, H.265 Decode & Encode (8-bit), Vp9 Decode; TDP: 12W to 25W System Memory – 2x DDR4 dual-channel 64-bit SO-DIMM sockets With ECC for up to 32GB RAM @ 2400 Mt/s Storage M.2 Socket Key B 2260 for SATA SSD (also features PCI-e x2) M.2 Socket Key M 2280 for […]

UDOO X86 II SBC Combines Intel Braswell SoC with Microchip ATMega32U4 “Arduino” MCU

UDOO x86 II

UDOO X86 development board was first introduced in a crowdfunding campaign in 2016 with a quad-core Intel Braswell processor coupled with an Arduino 101 compatible Intel Curie module for real-time I/O processing. Early July of next year (2019) the Intel processor and module seems to be going so well and have a bright future together with UDOO X86 board and accessories becoming broadly available. But life can be cruel at times, and Intel announced their plan to discontinue Intel Curie and other IoT projects just a few weeks later with the last shipment scheduled for July 2018. SECO, the company behind UDOO, could only order so much stock of Intel Curie module, so they had to design an alternative, and here we are with UDOO X86 II SBC offering many of the same features but replacing Intel Curie module by a Microchip ATmega32U4 MCU compatible with Arduino Leonardo.   Two […]

Close Up Photos of UDOO Bolt Ryzen Embedded V1000 Development Board

UDOO-Bolt-Board-Top

The first AMD Ryzen Embedded V1000 development board – UDOO Bolt  – was  launched on Kickstarter last week, but for whatever reasons, the company did not provide close up photos of the board. But luckily for us, TLS – regular reader & commenter, and occasional contributor for CNX Software – is now at Computex 2018 and spent some time at UDOO’s booth where he took time to take some photos and share with us. The top view of the board shows the two SO-DIMM slots and Ryzen Embedded processor, as well as an better looks at the ports and headers around the boards. The board should support up to 4 displays via its two HDMI 2.0a ports, and two USB type C ports with DP alternate mode. While, AMD Ryzen Embedded V1000 SoCs support 10 GbE, UDOO selected TRXCOM TRJG19901DNL Gigabit Ethernet jack, probably to keep costs under control. The bottom […]

UDOO BOLT AMD Ryzen Embedded V1000 SBC Goes for $229 and Up (Crowdfunding)

UDOO-BOLT

While Intel has been outing low cost and low power processors with less than 10W TDP over the years with their Bay Trail, Cherry Trail, Braswell, Apollo Lake, and now Gemini Lake processors, AMD has not really ventured into the low power space, and the latest announcements about 10-12W processors was for their Embedded G-Series J Family, which I have not seen in many products. More recently, the company introduced Ryzen Embedded V1000 family of processors with 4 to 8 Zen cores, 4K support, 10 GbE interface, and more with a TDP of 12 to 25W for Ryzen Embedded V1202B & V1605B dual / quad core processors. The latest x86 UDOO board – dubbed UDOO BOLT – will be one of the rare AMD development boards available on the market with pricing starting at $229. Two versions of the board will be available: UDOO BOLT v3 with Ryzen Embedded V1202B, […]

Circumference Datacentre-in-a-Box Features up to 32 Raspberry Pi 3 B+ Managed by a UDOO x86 Ultra Board (Crowdfunding)

We’ve previously seen several clusters made of Raspberry Pi boards with a 16 RPi Zero cluster prototype, or BitScope Blade with 40 Raspberry Pi boards. The latter now even offers solutions for up to 1,000 nodes in a 42U rack. Circumference offers an other option with either 8 or 32 Raspberry Pi 3 (B+) boards managed by UDOO x86 board acting as a dedicated front-end processor (FEP) that’s designed as a “Datacenter-in-a-Box”. Key features and specifications: Compute nodes – 8x or 32x Raspberry Pi 3 B+ boards for a total of 128x 64-bit 1.4 GHz cores max Backplane MCU – Microchip ATmega1280 8-bit AVR microcontroller Serial Comms – FTDI FT4232 quad-USB UART Switched Mode Power Supply Units (SMPSUs): 8x / 32x software controlled (one per compute node) 1x / 4x always-on (microcontroller) HW monitoring: 8x / 32x compute node energy 2x / 8x supply voltage 2x / 8x temperature Remote […]

ROCK64 and UDOO X86 Boards and Accessories are Now Available for Purchase

Pine64 ROCK64 is a development board powered by Rockchip RK3328 quad core processor, while UDOO X86 board is based on Intel Atom x5-E8000 or Celeron N3160 processor plus a Quark SE MCU. What do they have common? Not much, except both boards are now officially available for sale. Just a quick reminder of the specifications for ROCK64 board: SoC – Rockchip RK3328 quad core Cortex A53 processor with ARM Mali-450MP2 GPU System Memory – 1, 2, or 4 GB LPDDR3 Storage – eMMC flash module socket + micro SD card slot + 128 Mbit SPI flash Video & Audio Output – HDMI 2.0a up to 4K @ 60 Hz with HDR10 and HLG support, 3.5mm AV port (composite video + stereo audio) Video Codec – 4K VP9, H.265 and H.264, 1080p VC-1, MPEG-1/2/4, VP6/8 Connectivity – Gigabit Ethernet USB – 2x USB 2.0 ports, 1x USB 3.0 port Expansion Headers […]

UDOO BLU and BLU SENSE IoT Modules Integrate Bluetooth LE, Zigbee, and 6LOWPAN Connectivity

UDOO is known for their Linux boards based on NXP and Intel processors for makers and the education market such as UDOO NEO or UDOO x86, but the company has now developed UDOO BLU and BLU SENSE battery powered modules based on Texas Instruments CC2650 ARM Cortex M3 microcontroller, both with Bluetooth LE, Zigbee, and 6LOWPAN connectivity, and the SENSE model adds some extra sensors. UDOO BLU and BLU SENSE specifications: Wireless MCU – Texas Instruments CC2650 ARM Cortex M3 MCU @ 48 MHz with 128KB flash, 8KB SRAM with 2.4 GHz radio Connectivity – Bluetooth Low Energy (BLE), ZigBee, 6LoWPAN Sensors (BLU SENSE only) –  NXP FX0S8700CQ accelerometer & magnetometer sensor, NXP FXAS21002C gyroscope & temperature sensor Expansion 1x 5-pin sensors Snap-In I2C connector for UDOO Bricks 2x 10-pin headers with 8x Digital GPIOs, 6x ADCs, 1x I2C, 1x SPI, 1x UART Misc – 3x User Configurable LEDs (Red, […]
