Arm/Intel Windows systems-on-module come with modular eMMC or/and RAM modules

am335x system-on-module replaceable emmc & ram

It’s been a long time since I’ve written about a Windows CE (WinCE) compatible module,  but apparently, those are still being developed with China-based UNERON offering eSOM335x Windows CE system-on-module based on Texas Instruments AM335x Arm Cortex-A8 processor, and eSOM3735z Windows 10 module equipped with an Intel Atom Z3735G processor. What’s even more intriguing is that the company relies on replaceable & upgradable eMMC flash and RAM modules for the Arm SoM, and while the 1GB RAM is soldered on the Intel module, it’s still possible to upgrade the eMMC flash that way. We’ve seen eMMC modules on several single board computers in the past including ODROID-C4  or Renegade SBC, but I think it’s the first time I see this option on a system-on-module. UNERON eSOM335x AM335x system-on-module Specifications: SoC – Texas Instrumentx Sitara AM3358BZCZA100 Arm Cortex-A8 up to 1GHz with PowerVR SGX530 3D GPU (optional AM3359, AM3354, or AM3352) […]

Zoom i.MX 8M Mini Development Kit supports power usage monitoring

Beacon EmbeddedWorks iMX8M Som & Devkit

NXP i.MX 8M Mini 14nm Cortex-A53/M4 processor has been around for a couple of years, and several SoM-based development kits are available including Variscite Symphony starter kit, HummingBoard Ripple SBC, or congatec conga-SEVAL007010 evaluation board. Beacon EmbeddedWorks’ Zoom i.MX 8M mini development kit is based on the company’s i.MX 8M Nano System on Module (SOM) and offers features not found on most other devkits or single board computers such as power usage monitoring and control through their Wattson power measurement application. Zoom i.MX 8M mini development kit key features & specifications: System-on-Module SoC – NXP i.MX 8M Mini processor with up to four Arm Cortex-A53 cores @ up to 1.8 GHz, an Arm Cortex-M4 real-time core at up to 400 MHz, Vivante 3D & 2D GPU’s System Memory – Up to 8GB of 32-bit wide LPDDR4 memory Storage – eMMC flash, QSPI NOR flash Networking Gigabit Ethernet PHY Wireless module […]

ICOP VEX2-6415 SBC runs DOS, QNX, Linux, Windows on Vortex86EX2 “Dual OS” x86 processor

ICOP VEX2-6415 SBC

DM&P Vortex86EX2 is a dual-core x86 processor that supports legacy ISA and PCI interfaces, and designed in a way that makes it capable of running two OS independently, easy with its own BIOS, without the need for virtualization, nor a hypervisor. At the time, we also covered the Vortex86EX2 evaluation board from the company, but the first commercial product that has come to my attention is ICOP VEX2-6415 Vortex86EX2 SBC designed for automation and IoT, and which the company says support “Windows Embedded Compact 7, Windows Embedded Compact 6, various of (sic) Linux distribution, QNX, and even the legacy but still popular DOS”. ICOP VEX2-6415 SBC specifications: CPU – DM&P Vortex86EX2 dual-core processor with Master core @ 600MHz max with build-in FPU L1/L2 Cache for user interface Slave core @ 400MHz max with build-in FPU, L1 Cache for real-time control System Memory – 512MB/1GB DDR3 Storage – 4GB eMMC flash […]

DM&P Vortex86EX2 Dual Core Processor Targets Dual OS Systems, Support ISA & PCI Interfaces

Vortex86EX2 Block Diagram

Most people will probably think about Intel and AMD when asked about x86 processors, at least those who understand the question… But there are also other companies such as Zhaoxin (based on VIA Technologies designs) and DM&P. Last time I wrote about the latter was in 2015 with the introduction of DM&P Vortex86DX3 dual-core x86 SoC for embedded systems and the corresponding evaluation board. The company is still making new x86 processors, and I’ve just been information the company unveiled  Vortex86EX2 dual-core processor last year with master and slave cores suitable for running two operating systems at the same time without the need for virtualization, nor hypervisor. The new processor still supports ISA & PCI interfaces for legacy expansion cards and targets real-time industrial or automation applications. DM&P Vortex86EX2 specifications: Processor Cores Master @ 600MHz max with Build-in FPU L1/L2 Cache for user interface Slave @ 400MHz max with Build-in […]

Minnow Server is a Secure Web Server for Microcontrollers

Minnow Server Secure Websocket

Many embedded systems have a limited amount of memory, which would normally run programs with smaller footprints than on desktops or servers. For example, nginx and Apache2 are the common web servers, but on hardware with limited memory, smaller footprint web servers may be required, so that’s why I wrote a list of web servers for embedded systems running Linux/uClinux many years ago. But now, even platforms based on microcontrollers often need to run web server usually for configuration. We’ve already shown how to use Arduino to serve a simple web page and did the same in Getting Started with NodeMCU Board Powered by ESP8266 WiSoC but using Lua programming language instead. It may be more convenient to run a proper web server however, as it’s easier to change the interface, and we previously covered MicroWebSrv lightweight web server that works on platforms running MicroPython such as Pycom boards. Real Time […]

Forlinx OK335xD Industrial Single Board Computer Supports Android, Linux and WinCE

Forlinx, an embedded systems design and manufacturing company based in Hebei province in China, has announced OK335xD industrial (temperature) single board computer powered by Texas Instruments Sitara AM335X processor, and which appears to be a high-end version of their OK335xS-II SBC with more ports. Potential applications include communication devices, medical equipment, automotive computers, control panels, data acquisition devices, industrial control, industrial automation equipment, and more. OK335xD single board computer is composed of a CPU module (FET335xD), and a baseboard simply called “OK335xD Base Board”. Listed specifications for FET335xD computer-on-module: SoC – Texas Instruments Sitara AM3354 Cortex A8 processor @ 800MHz with PowerVR SGX530 GPU System Memory – 512MB DDR3 Storage – 256MB SLC NAND Flash Interfaces available via CoM connector: 1x USB 2.0 Host; 1x USB2.0 OTG Ethernet Dual Gigabit Ethernet 3x MMC 3x I2C, 2x SPI, 6x UART / IrDA Various GPIO pins 8x ADC 2x CAN LCD Interface […]

Forlinx OK335xS-II is a Low Cost Linux and Wince Industrial Board Powered by TI Sitara AM335x Processor

Forlinx Embedded, a company based in Baoding, Hebei, China specializing in embedded systems design and manufacturing, has recently launched OK335xS-II single board computer powered by Texas Instruments AM335x SoC which they claim to be “the cheapest industrial Cortex-A8 board in history” as it sells for as low as 298 RMB or about $48. OK335xS-II board is comprised of a baseboard and a CPU module soldered to the carrier board with the following specifications: SoC – Texas Instruments AM335X ARM Cortex-A8 processor @ 800MHz with PowerVR SGX530 GPU System Memory – 128M DDR3 + micro SD slot Storage – 256MB SLC NAND Flash Display I/F – LCD interface with support for LCD to LVDS and LCD to VGA, and resistive touchscreen interface Connectivity – 1x 100M Ethernet USB – 1x USB 2.0 host, 1x mini USB 2.0 device Serial – 5x serial port (1x debug interface, 4x TTL port) Expansions headers […]

Toradex Colibri VF50/VF61 SoMs Powered by Freescale Vybrid SoCs Sell for as Low as 19 Euros

Toradex Colibri VF50 and Colibri VF61 are system-on-modules respectively powered by Freescale Vyrbrid VF5xx Cortex A5 SoC and Vybrid VF6xx dual core Cortex A5/M4 SoC, which are part of the company’s Colibri ARM computer on modules. Toradex Colibri VF50/VF61 specifications: Processor VF50 – Freescale Vybrid VF5xx (MVF50NN151CMK40) ARM Cortex-A5 @ 400MH, 1.5MB SRAM VF61 – Freescale Vybrid VF6xx (MVF61NS151CMK50) ARM Cortex-A5 @ 500MHz, Cortex-M4 @ 167MHz, 1.0MB SRAM, and multiple hardware accelerated security features listed below. System Memory VF50 – 128MB DDR3 (16-bit, no ECC), or 64MB DDR3 with ECC (8-bit, ECC) VF61 – 256MB DDR3 (16-bit, no ECC), or 128MB DDR3 (8-bit, ECC) Storage VF50 – 128MB NAND flash VF61 – 1GB NAND flash Interfaces via the 200-pin SO-DIMM edge connector (X1): LCD RGB (24-bit), up to 1024 x 768 4-wire or 5-wire resistive touch Audio – I/O (VF61 only), SPDIF In and Out, I2S/AC97 compatibl Ehanced Serial Audio […]
