July 8, 2014July 8, 2014 by Jean-Luc Aufranc (CNXSoft) - 23 Comments

HiMedia Q5 Quad Core is an Android TV Box based on HiSilicon Hi3798C SoC with SATA, USB 3.0, 4K Support

HiMedia has been releasing and manufacturing Android TV boxes with SATA interfaces based on Hilison processors including Q5 (single core) and Q5II (dual core) for a couple of years. The company is about to release another one with the same enclosure, based on a new Hilicon Hi3798C quad core SoC, that they’ve aptly named “Q5 Quad Core”. HiMedia Q5 Quad Core specifications: SoC – HiSilicon Hi3798C quad core ARM Cortex A9 @ 1.5GHz + ARM Mali-450MP6 Octa core GPU. System Memory – 2 GB DDR3 Storage – 8GB eMMC Flash, SATA connector, and MMC/SD 2-in1 card reader Connectivity – 10/100/1000M Ethernet, and 802.11 b/g/n/ Wi-Fi with external antenna Video Out – HDMI 1.4 up to 4K30 and composite Audio Output – HDMI, L/R stereo (RCA), and optical & coaxial S/PDIF Video Codecs – MPEG1/2/4 up to 4K30, H.264/AVC up to 4K30, H.265 up to 4K30, VC-1, REALVIDEO 8/9/10 up to […]

July 7, 2014May 29, 2017 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

VidOn.me AV200 Android TV Box Review

After providing some pictures of VidOn.me AV200 media player, and its PCBA, it’s now time for a review. I’ll start by giving my first impressions, and checking out the system settigns and user’s interface, go through my library of video test files, and cover most hardware features. As usual, I’ll also test Wi-Fi performance, but I’ve now added more tests including Ethernet performance, and USB hard drive support and performance with NTFS, FAT32, EXT-4, and BTRFS partitions. First Boot, Settings and First Impressions The device comes with an IR remote control with lots of buttons, including shortcuts, D-Pad control, digit keys and trick modes (play/pause, fast forward and rewind, next and previous), but the two required AAA batteries were not included, and I did not have spare batteries, so I did not use the remote control, which looks pretty OK for XBMC, and just control the device with my Mele […]

July 7, 2014November 23, 2014 by Jean-Luc Aufranc (CNXSoft) - 36 Comments

Microsoft is Giving Away Intel Galileo Arduino Compatible Boards to Developers

Microsoft has already launched several initiatives to reach the maker movement and app developers with .NET Gadgeteer supported by platform like Bambino 200, as well as Intel Shark Cove development board for Windows development. The company has now launched a website called windowsondevices.com where they currently have a signup page for developers to send a kit based on Intel Galileo, an Arduino compatible board powered by Intel Quark processor. There’s currently very little information on the software and documentation part of the development kit, but there are links to Visual Studio Express, Windows Embedded’s Internet of Things page, and a link to Maker Faire, so it gives what the kit will be for. Apparently they’ll send the kit to selected candidate whether “you are an experienced Windows developer looking to jump into the Internet of Things or you are new to Windows development and want to build the next big […]

July 6, 2014September 12, 2014 by Jean-Luc Aufranc (CNXSoft) - 12 Comments

Inforce Computing IFC6540 Pico-ITX Board Features Qualcomm Snapdragon 805, High Speed Interfaces

Inforce Computing has been working the successor of their IF6410 development board based on Snapdragon S4 Pro SoC with IFC6540, another tiny board for Linux and Android, yet with interesting features such as 802.11ac, SATA III, USB 3.0 host and device connectors, and powered by the latest Snapdragon 805 quad core krait processor. IFC6540 specifications: SoC- Qualcomm Snapdragon 805 APQ8084 Quad core Krait 450 @ 2.5GHz with 2MB L2 cache, Adreno 420 GPU with OpenGL ES 2.0 and 3.0, OpenCL, and RenderScript support. System Memory – 2 GB LPDDR3 Storage – 4GB eMMC 4.5 (eMMC 5.0 also supported), 1 micro SD slot, and 1x SATA 3 interface Connectivity 802.11ac WiFi /ac (2.4 GHz/5 GH) + Bluetooth 4.1 via QCA6174 10/100/1000 Mbps Ethernet via AR8151 GPS via QCA1530 + GPS antenna connector Video and Audio Interfaces 1 x HDMI (Type D) Dual MIPI-DSI and Touch Screen 3.5mm headphone and Line In […]

July 5, 2014May 29, 2017 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

Unboxing of VidOn.me AV200 Android Blu-Ray Box

I had only reviewed on device based on AllWinner A31 before, namely CS868 mini PC which turned out to be disappointing. And recently I’ve reviewed quite of few Amlogic and Rockchip TV boxes, so I’m happy to get a change and try again with another AllWinner A31 based device thanks to VidOn.me AV200 Android Blu-ray Box. I’ll start by listing hardware specifications and showing pictures of the device and the board today, and I’ll write a complete review in a few days. VidOn.me AV200 Specifications AV200 is an Android TV box with a metallic enclosure very similar to the one used for Mele X1000 Android Blu-ray box, and with the following specifications: SoC – AllWinner A31 quad core Cortex-A7 @ 1.3GHz with PowerVR SGX544MP2 GPU System Memory – 2GB DDR3 Storage: 8GB + SD/SDHC card reader Video Output – HDMI Audio Output – HDMI, optical S/PDIF, and 3.5mm headphone jack […]

July 5, 2014 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

MK813 Quad Core Android TV Box with a 2MP Camera Sells for $47

Prices for Android TV boxes based on Rockchip RK3188 are getting ridiculously low, probably because some people are getting rid off stocks. After MK918 that sells for about $50 , MK813 is another quad core Android media player with 1 to 2 GB RAM, 8GB flash, and a 2MP camera that you can buy for $46.80 on Aliexpress (1GB RAM) from a seller with decent feedback, and that includes shipping. The 2GB RAM version sells for $51.32. MK813 Specifications (also known as KD812): SoC – Rockchip RK3188 quad Cortex-A9 CPU @ 1.6 GHz + Mali-400 MP4 GPU System Memory – 1 or 2 GB DDR3 SDRAM Storage – 8GB NAND Flash + Micro SD slot (Up to 32GB) Connectivity – WiFi 802.11 b/g/n with external antenna, Bluetooth 2.1 Video & Audio Output – HDMI + AV output jack USB – 2x USB host ports + 1x micro USB OTG + […]

July 4, 2014 by Jean-Luc Aufranc (CNXSoft) - 8 Comments

Forlinx OK335xS-II is a Low Cost Linux and Wince Industrial Board Powered by TI Sitara AM335x Processor

Forlinx Embedded, a company based in Baoding, Hebei, China specializing in embedded systems design and manufacturing, has recently launched OK335xS-II single board computer powered by Texas Instruments AM335x SoC which they claim to be “the cheapest industrial Cortex-A8 board in history” as it sells for as low as 298 RMB or about $48. OK335xS-II board is comprised of a baseboard and a CPU module soldered to the carrier board with the following specifications: SoC – Texas Instruments AM335X ARM Cortex-A8 processor @ 800MHz with PowerVR SGX530 GPU System Memory – 128M DDR3 + micro SD slot Storage – 256MB SLC NAND Flash Display I/F – LCD interface with support for LCD to LVDS and LCD to VGA, and resistive touchscreen interface Connectivity – 1x 100M Ethernet USB – 1x USB 2.0 host, 1x mini USB 2.0 device Serial – 5x serial port (1x debug interface, 4x TTL port) Expansions headers […]

July 3, 2014 by Jean-Luc Aufranc (CNXSoft) - 8 Comments

How to Use an Android TV Box as a Wi-Fi Access Point

Today, I’ve come across another potential use case for Android TV boxes with Wi-Fi and Ethernet. Let’s say you are in a room with Ethernet, but there’s no Wi-Fi signal or the signal is too weak, and want to use your smartphone to connect to the Internet via Wi-Fi. If you don’t have one of these small (openWRT) Wi-Fi router with you, but instead brought an Android mini PC, you can configure the “Portable Hotspot” function to transform it into a secure Wi-Fi access point. Assuming you’ve connect an Ethernet cable, and powered the device, first make sure Ethernet is enabled\, and Wi-Fi is disabled in the Settings menu. To click on Settings->More.. in the Wireless & Networks section, and select “Tethering & portable hotspot” or simply “Portable hotspot” depending on your firmware. In the next menu, click on Portable Wi-Fi hotspot to enabled it, then “Set up Wi-Fi Hospot” […]
