ARBOR ELIT-1060 compact, fanless Celeron N6210 terminal supports up to three 4K displays

Compact Intel Celeron N6210 fanless display terminal

ARBOR’s ELIT-1060 triple display terminal is a rugged fanless mini PC powered by an Intel Celeron N6210 dual-core Elkhart Lake processor with two HDMI 2.0 ports and one DisplayPort connector each supporting up to 4Kp60 resolution. The system comes with a 4GB DDR4 SO-DIMM, 32GB eMMC flash, two 2.5GbE Ethernet ports, an M.2 socket for wireless expansion, several USB 3.0/2.0 ports, and one RS232/422/485 serial port. While the company markets it for “high-intensity digital signage applications”, I could also see it being used in various other applications thanks to its networking capabilities and expansion ports. ARBOR ELIT-1060 specifications: SoC – Intel Celeron N6210 dual-core Elkhart Lake processor up to 2.6 GHz with Intel UHD graphics System Memory – 4GB DDR4 SO-DIMM memory expandable to up to 32GB RAM Storage 32GB eMMC flash M.2 M-key socket (2260/2280, PCIe Gen.3 x2/SATA interface) for an NVMe or SATA SSD Video Output 2x HDMI […]

Arbor M1016 10.1″ Medical-Grade Tablet Targets Infotainment & Kiosk Applications

Arbor M1016 Healthcare & Kiosk Tablet Arbor offers various products in the embedded systems field, automotive IoT and healthcare infotainment, as well as patient interfaces for hospitals. The M1016, a 10.1″ Healthcare Infotainment Terminal is a soon to be released alternative to the company’s HTab. Previous Articles for Arbor HTab healthcare bedside patient entertainment tablet and the IoT-800N Automotive Panel PC have both been reported on in previous articles about Arbor market entrants. The Basics and Kiosk Design The M1016 runs an Arm Cortex-A35 CPU @ 1.5GHz, that supports Android 8.1, and offers a variety of features for many of the different capabilities of patients under care. The design is based on a Kiosk model, with an a-la-carte menu arrangement. Access and Power Consumption The unit itself is fanless with low power requirements that lend themselves well to thin enclosure design and ease of use. The GPU is a Mali-G31 […]

ARBOR IoT-800N Android/Ubuntu Panel PC Targets Automotive Applications, Industrial Automation

Arbor IoT-800N

Rockchip PX30 is a low cost low power quad core Arm Cortex-A35 processor mostly designed for car infotainment systems. Last month, we also found the processor in ARBOR SOM-RP301 system-on-module designed for retails kiosks such as automated currency exchange machines, electronic restaurant menus, , ticketing kiosks, etc… ARBOR has now launched another Rockchip PX30 platform with their IoT-800N 8″ Panel PC running Android 8.1 or Ubuntu 16.04, and designed for automotive applications such as fleet management or driver fatigue monitoring thanks to interfaces like OBD-II, as well as industrial automation. ARBOR IoT-800N specifications: SoC – Rockchip PX30 Quad-core Arm Cortex-A35 processor System Memory – 2GB DDR4 memory soldered on board Storage – 16GB eMMC flash soldered on board, microSDHC/microSDXC/microSD card socket up to 128GB Display – 8” TFT LCD display with 1024 x 600 resolution, 5-point projected capacitive touchscreen Camera – 8MP front-facing MIPI CSI camera with auto-focus Audio – […]

ARBOR Introduces SOM-RP301 Rockchip PX30 SoM for Retail Kiosks

SOM-RP301 Rockchip PX30 SoM

Rockchip PX30 is a quad core Cortex-A35 processor with a dual VOP (Video Output Processor) in order to drive two independent displays, that has low power consumption, low thermal requirements, and that we previously found in some car infotainment systems. But the processor is also suitable for other applications, and ARBOR Technology recently launched SOM-RP301 system-on-module based on the PX30 processor, and specifically designed for fanless retail kiosks such as electronic restaurant menus, automated currency exchange machines, ticketing kiosks and more. SOM-RP301 system-on-module specifications: SoC – Rockchip PX30 quad core Cortex-A35 processor @ 1.5 GHz with Arm Mali-G31 MP2 GPU System Memory – 1GB LPDDR3 (Up to 4GB as option) Storage – 16 GB eMMC flash Connectivity – Fast Ethernet transceiver, 802.11 b/g/n/ac WiFi 5 + Bluetooth 4.0 module Edge Connector – SO-DIMM connector with Display – LVDS or MIPI DSI Camera – MIPI CSI RX interface with 8MP ISP […]

Gladius GT-500 Rugged Android Smartphone Features a Built-in Barcode Reader, LTE Connectivity

ARBOR technology has introduced Gladius GT-500 “5” Rugged Android Handheld Device” running Android 5.1 on MediaTek MT6735 quad core processor, with LTE connectivity, IP67 rated, and featuring a build-in 1D/2D barcode reader with physical trigger buttons. Gladius GT-500 smartphone specifications: SoC – Mediatek MT6735 quad core Cortex A53 processor @ 1.3 GHz with ARM Mali-T720 GPU System Memory – 2GB LPDDR2 Storage – 16GB eMMC flash + 1x micro SD slot up to 32GB Display – 5″ TFTP LCD; 1280×720 resolution; 5-point glove-friendly projector capacitive touch screen; 400 cd/m2 brightness Cellular Connectivity 2G GSM/GPRS/EDGE (Band 850 / 900 / 1800 / 1900) 3G WCDMA (Band 1,2,5,8) 3G CDMA2000 (BC0/BC1) 4G FDD+TDD (Band 1,3,5,7,8,20,38,39,40,41) 4G DRX (Band 1,3,5,7,8,20,38,39,40,41) SIM Sockets – 1 x micro-SIM (3FF) socket supporting 2G/3G/LTE; 1 x micro-SIM (3FF) socket supporting 2G only Other Connectivity – Wi-Fi 802.11a/b/g/n, Bluetooth 4.1 (BLE, HS compliant), NFC, and GPS/GNSS/Beidou Camera – […]

Arbor HTab Android Tablet Powered by TI OMAP 4470 Targets Hospital Patients

Texas Instruments exited the consumer market a couple of years ago, to focus on higher margins industrial, automotive and healthcare markets. While you won’t find any recent consumer tablets with a Texas Instruments processor, Arbor recently launched Htab, a “bedside turn-key solution combining healthcare and patient entertainment service” powered by Texas Instruments OMAP4470 dual core Cortex A9 processor, and featuring a 10″ touchscreen display with 1280x 800 resolution. Some of Arbor HTab hardware specifications: SoC – Texas Instruments OMAP 4470 dual core Cortex A9 processor @ 1.5 GHz System Memory – 1GB LPDDR2 Storage – 8GB eMMC Flash + micro SD slot storage (Max. 32GB) Display – 10.1” LCD at 1280×800 resolution with 10-point projected capacitive multi-touch POE connectivity option reduces installation costs Micro USB for external device connectivity 2.0MP Webcam RFID Tag Support – ISO15693, ISO14443A/B, Felica, Mifare, Tag-it, ST LRI 1K and ST M24LRXX Complies with EN60601-1 & […]
