Compulab’s Miniature “Bend & Fold” UCM-iMX7 System-on-Module Could Fit into a Watch

Many companies are still releasing NXP – soon to be Qualcomm – i.MX 6/7 system-on-modules, but I don’t cover all of them, since we have already many to choose from. But Compulab’s latest UCM-iMX7 SoM differentiates itself by it size, using the company’s “Ultra-compact Multilevel Module” (UCMM) technology, to pack NXP i.MX7 processor, 2GB RAM, 64 GB eMMC flash, and a wireless module into a 30 x 27 x 8 mm volume that could potentially fit into something as small as a watch. The picture above clearly shows how UCMM technology works with the module comprised of two rigid PCBs and one flexible layer routing signals between the two allowing to bend and fold the rigid parts together to form a vertical stack. The principle could be extended to more PCBs and flexible layers, sof for example you could have four PCBs with three flexible layers in future / custom designs. The rest of the specifications of UCM-iMX7 module are […]

Compulab IOT-GATE-iMX7 is an NXP i.MX7 IoT Gateway for Industrial Applications

CompuLab has introduced IOT-GATE-iMX7 compact fanless IoT gateway and industrial controller built around the company’s CL-SOM-iMX7 system-on-module, and offering Ethernet, WiFi, Bluetooth, 3G and Zigbee connectivity.Compulab IOT-GATE-iMX7 gateway specifications: SoC –  NXP i.MX 7 dual ARM Cortex-A7 processor @ up to 1GHz with ARM Cortex-M4 core @ 200Mhz, 2D graphics engine System Memory – Up to 2GB DDR3L-1066 Storage – Up to 32GB on-board eMMC + micro-SD socket Connectivity Dual Gigabit Ethernet Dual band WiFi 802.11 a/b/g/n Bluetooth 4.1 BLE Optional 3G cellular module via mini PCie socket Optional ZigBee NXP JN5168 module Display – DVI up to 1920×1080 using a HDMI connector Audio – 3.5mm jacks for stereo line out, stereo line in USB – 4x USB2.0 host ports, type-A connectors Serial – 1x RS485 / RS422 port, RJ11 connector; 1x RS232 port, ultra-mini serial connector; 1x serial console via UART-to-USB bridge, micro-USB connector Expansion mini-PCIe socket, full-size embedded I/O header with up to 1x UART, 1x SPI, 1x […]

Mintbox Mini Pro Linux mini PC Gets AMD A10 Micro-6700T Processor, 8GB RAM, and 120 GB Storage for $395

Minitbox Mini is a low power mini PC based on Compulab Fitlet-i computer powered by AMD A4 Micro-6400T “Mullins” processor and running Linux Mint that was launched in 2015. There’s now an upgraded model – Mintbox Mini Pro – with a more powerful AMD A10 Micro-6700T, more RAM and storage with 8GB DDR3 and a 120 GB SSD, and faster and better networking thanks to 802.11ac WiFI, and dual Gigabit Ethernet. Mintbox Mini Pro specifications: SoC – AMD A10 Micro-6700T 64 bit quad-core processor up to 1.2 GHz / 2.2 GHz (Boost frequency) with Radeon R6 Graphics (4.5W TDP) System Memory – 8 GB DDR3L-1333 SDRAM (SODIMM module) Storage –  120GB mSATA (SATA 3.0) SSD, and micro-SD slot (SDXC support, rate 25 MB/s) Video Output – Dual HDMI 1.4a up to 1920×[email protected]; support two independent displays Audio I/O Output – HDMI, digital S/PDIF 7.1+2 channels output, 3.5 mm stereo audio jack Input – Digital S/PDIF input, 3.5mm audio microphone jack Codec […]

Compulab Fitlet-RM is a Rugged Wide Temperature Fanless mini PC based on AMD A10 Micro-6700T Processor

Among the many Intel Cherry Trail and Braswell mini PCs, it’s nice to see an alternative with AMD processor, and after their Fitlet-H and Fitlet-iA10 mini PCs powered by AMD A10 Micro-6700T quad core processor, Compulab is back with two rugged models based on the processor, and supporting a wide temperature range, with namely Fitlet-RM-iA10 and Fitlet-RM-XA10 LAN mini PCs. Fitlet-RM specifications: SoC – AMD A10 Micro-6700T 64 bit quad-core  processor up to 2.2 GHz with AMD Radeon R6 Graphics (4.5 W TDP) System Memory – Up to 8 GB DDR3-1333 (1x SODIMM) Storage – mSATA up to 1 TB (SATA 3.0 6 Gbps); micro SD/SDXC slot up to 25 MB/s Display – 2x HDMI 1.4a ports Audio – S/PDIF 7.1+2 channels in/out + stereo line-out/line-in/mic + HDMI audio Connectivity Fitlet-RM-XA10 LAN – 4x Gigabit Ethernet ports (Intel I211), 802.11 b/g/n WiFi Fitlet-RM-iA10 – 2x Gigabit Ethernet ports, 802.11 b/g/n/ac WiFi (Dual band Intel 7260HMW module) + Bluetooth 4.0; support […]

Compulab Unveils CL-SOM-iMX7 Freescale i.MX7 System-on-Module and SBC-iMX7 Single Board Computer

After a few years of speculations and developments about i.MX7 and i.MX8 processors, Freescale announced Freescale i.MX7 family this summer. The new processors are based on one or two Cortex A7 cores coupled with a Cortex-M4 MCU for real-time tasks, and are a low power alternative to Freescale i.MX6 processors. But so far I had only seen a few announcements such Toradex i.MX7 SoM or Freescale 96Boards, without any product actually shipping, and Compulab claims to the first to market with a Freescale i.MX7 system-on-module, namely their CL-SOM-iMX7 SoM which will ship in quantities in early January 2016. CL-SOM-iMX7 system-on-module specifications: SoC Freescale i.MX 7Solo single core Cortex-A7 @ 800MHz with NEON SIMD and VFPv4 + ARM Cortex-M4 @ 200Mhz Freescale i.MX 7Dual dual core Cortex-A7 @ 1GHz with NEON SIMD and VFPv4 + ARM Cortex-M4 @ 200Mhz System Memory – 256MB to 2GB DDR3L-1066 Storage – 128MB – 1GB SLC NAND flash, 4GB – 32GB eMMC flash Connectivity Up […]

Compulab Unveils CL-SOM-iMX6UL Freescale i.MX 6UltraLite System-On-Module and SBC-iMX6UL SBC

Compulab has launched a CL-SOM-iMX6UL system-on-module based on Freescale i.MX 6UltraLite ARM Cortex A7 processor with up to 1GB DDR3 and 32GB eMMC flash. The module can be coupled with SB-SOM-iMX6UL carrier board to form SBC-iMX6UL single board computer targeting industrial and embedded applications. CL-SOM-iMX6UL specifications: SoC – Freescale i.MX6 UltraLite Cortex-A7 processor @ 528MHz System Memory – Up to 1GB DDR3 Storage – Up to 32GB on-board eMMC, Up to 1GB on-board SLC NAND, SPI flash, I2C EEPROM Connectivity – Dual-band, dual-antenna 2×2 802.11a/b/g/n WiFi, Bluetooth 4.1 BLE (Ti WiLink 8), 10/100M Ethernet PHY (with optional bypass) Audio – WM8731 audio codec with stereo line-out, line-in, mic, S/PDIF input/output Other I/Os via 204-pin SODIMM edge connector Display Parallel 24-bit display interface up to 1366 x 768 Touchscreen 4/5/8-wire resistive touch-screen support Capacitive touch-screen support through SPI interface USB – 1x USB2.0 OTG + 4x USB2.0 host ports Up to 8x UART ports Up to 1x MMC/SD/SDIO interface Up to […]

Compulab fit-Uptime is a 12V mini UPS for Intel NUCs, fit-PCs, and More

Power failures can cause loss of data, or if you are unlucky even brick your devices, and for business users there may be a maintenance cost. UPS (Uninterruptible Power Supplies) prevent those issues by providing power when the mains fail, and while they are relatively inexpensive, they are quite bulky. That’s probably Compulab designed fit-Uptime a mini UPS taking 12 to 19V input and outputting 12V to keep mini PCs such as the company’s fit-PCs or Intel NUCs for a couple of hours. fit-Uptime specifications: Capacity – 18 watt hour Input: DC 12V to 19V Output on battery – DC 12V / 5A Output when powered – 12V to 19V (same as input) / 5A Battery – Lithium polymer built-in non-replaceable (good for up to three hours) Dimensions – 6.8 cm (l) x 8 cm (w) x 3.2 cm (h); Power jack: 5.5mm x 2.5mm barrel Weight – 240g The mini UPS works with Compulab fitlet, IPC1/2, fit-PC3/4, Intel NUC […]

Compulab Unveils Texas Instruments Sitara AM5718 / AM5728 SoM and Single Board Computer

After last week formal launch of Texas Instruments Sitara AM572x processor, and Beagleboard-X15 development board, Compulab has now introduced  CL-SOM-AM57x System-on-Module based on TI Sitara AM5718 or AM5728 SoC, as well as the corresponding SBC-AM57x single board computer.  Both target industrial automation and control systems, and network connectivity options also make them suitable for networking, communications and IoT applications. CL-SOM-AM57X module specifications: SoC – Texas Instruments Sitara AM5728  or AM5718 SoC with: Dual (AM5728) or single (AM5718) Cortex A15 processor @ up to 1.5 GHz Dual core PowerVR SGX544 3D GPU, Vivante GC320 2D GPU Two Cortex M4 cores @ 212 MHz Dual TMS320C66x DSP @ 700 MHz Video IVA-HD 1080p video sub-system Four 32-bit PRUs (Programmable Real-time Units) System Memory – 512MB to 4GB DDR3 Storage – 4 to 32GB on-board eMMC, 512MB to 1GB on-board SLC NAND Connectivity – On-board WiFi 802.11a/b/g/n + Bluetooth 4.1 BLE (TI WiLink 8), 2x Gigabit Ethernet PHY Audio – WM8731 audio codec […]
