Digi ConnectCore MP25 SoM targets Edge AI and computer vision applications with STM32MP25 MPU

digi connectcore mp25 module

Digi International has announced its latest system-on-module (SoM), the Digi ConnectCore MP25 SoM, based on STM32MP25 MPU at Embedded World 2024 in Nuremberg, Germany. The Digi ConnectCore MP25 SoM is built upon STMicroelectronics’ STM32MP25 microprocessor. It supports artificial intelligence and machine learning functionality through an integrated neural processing unit (NPU) capable of 1.35 tera operations per second (TOPS) and an image signal processor (ISP). It is powered by two 64-bit Arm Cortex-A35 cores running at 1.5GHz, supported by a 32-bit Cortex-M33 core operating at 400MHz and a 32-bit Cortex-M0+core running at 200MHz. With its machine learning capabilities, support for time-sensitive networking, and versatile connectivity features, the ConnectCore MP25 module is suitable for edge AI, computer vision, and smart manufacturing applications in various sectors, including medical, energy, and transportation. Digi ConnectCore MP25 specifications: SoC – STMicroelectronics STM32MP257F CPU – 2x 64-bit Arm Cortex-A35 @ 1.5 GHz; MCU 1x Cortex-M33 @ 400 […]

Digi IX40 5G edge computing industrial IoT cellular gateway is designed for Industry 4.0 use cases

Digi IX40 5G industrial cellular IoT gateway

Digi IX40 is a 5G edge computing industrial IoT cellular router solution designed for Industry 4.0 use cases such as advanced robotics, predictive maintenance, asset monitoring, industrial automation, and smart manufacturing. The IIoT gateway is based on an NXP i.MX 8M Plus Arm processor running a custom Linux distribution, and besides 5G and 4G LTE cellular connectivity, offers gigabit Ethernet networking with 6 RJ45 and SFP ports, GNSS for geolocation and time, as well as digital and analog I/Os and an RS232/RS422/RS485 serial interface supporting Modbus. Digi IX40 specifications: SoC – NXP i.MX 8M Plus Arm Cortex-A53 processor @ 1.6 GHz with 2.3 TOPS NPU System Memory – 1GB RAM Storage – 8GB eMMC flash Wireless Cellular  IX40-05 5G NSA, 5G SA, 4G LTE-ADVANCED PRO CAT 19 5G NR bands – n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n38, n40, n41, […]

Digi ConnectCore MP13 SoM with STM32MP13 MPU embeds Wi-Fi 5 and Bluetooth 5.2 module

DigiConnect Core MP13

Digi International ConnectCore MP13 system-on-module (SoM) is powered by the just-announced STMicro STM32MP13 Cortex-A7 microprocessor and integrates a pre-certified WiFi 5 and Bluetooth 5.2 module for applications in the medical, smart energy, and industrial sectors. The module is also equipped with up to 1GB RAM and 1GB SLC NAND flash, and exposes I/Os through LGA pads and/or castellated holes with interfaces such as dual GbE, USB 2.0, I2S and SPDIF for audio, CAN FD, analog inputs, and more. Contrary to the company’s earlier Digi ConnectCore MP15 based on STM32MP15 MPU, the MP13 does not provide multimedia functions, display, and camera interfaces. Digi ConnectCore MP13 specifications: SoC – STMicro STM32MP13x single-core Arm Cortex-A7 processor @ 650 MHz (only STM32MP133C at this time) System Memory – Up to 1GB DDR3 Storage – Up to 1GB SLC NAND flash Wireless – Optional pre-certified Wi-Fi 5 802.11a/b/g/n/ac up to 433.3 Mbps and Bluetooth 5.2 […]

Digi IX30 is a cellular router for Industry 4.0, public safety, harsh environments

Digi IX30

Digi IX30 is a 4G LTE cellular router for industry 4.0 designed for distribution and automation, remote machines and sensor monitoring in industries such as oil and gas production, water utilities, smart cities, and outdoor signage. The Digi IX30 is a rugged device able to operate in harsh environments, and the US model supports FirstNet nationwide wireless broadband network dedicated to public safety in the event of an emergency (e.g. terrorist attack). The network is designed for first responders, city services, and infrastructure, as well as drilling and gas wells, Internet-connected irrigation systems, waste disposal, and septic tank services among others. A future version will also support the Anterix Band 8 (900 MHz) for critical infrastructure/mission-critical private LTE networks. Digi IX30 specifications: SoC, memory, storage – No information, except the processor is running Linux.  Connectivity Ethernet – 2x 10/100M Fast Ethernet ports Cellular options FirstNet capable LTE Advanced Cat 7 […]

Digi ConnectCore 8M Mini SOM and Mini Development Kit for Industrial IoT Applications

Digi ConnectCore 8M Mini SOM

Digi International has announced the Digi ConnectCore 8M Mini System-on-Module (SOM) which is an addition to its ConnectCore family modules. We saw the Android application development kit featuring earlier Digi Wireless modules based Freescale i.MX51 (ConnectCore Wi-i.MX51) and i.MX53 (ConnectCore Wi-i.MX53) in early 2012. The new Digi ConnectCore 8M Mini comes with a built-in Video Processing Unit specialising in vision use cases. The Digi ConnectCore 8M Mini SOM is an industrial i.MX 8M Mini quad-core system-on-module that comes with Arm Cortex-A53 cores, one Cortex-M4 core, and the Cortex-M0-based Digi Microcontroller Assist. This enables optimal power consumption while simultaneous maintenance of highly efficient performance. Main benefits of Digi Connect Core 8M Mini SOM Digi SMTplus form factor (40 x 45 mm) for flexibility and reliability while designing. Power management with both hardware and software support for low-power designs. Display and camera capabilities with graphics and video hardware acceleration make it suitable […]

Digi IX15 IoT Gateway & Cellular Router features a Zigbee & BLE XBee module

Digi IX15 IoT Router Cellular Gateway

Digi International has just announced the Digi IX15 IoT gateway and cellular router with Ethernet and 4G LTE connectivity as well as support for Zigbee, Bluetooth 5.0, 2.4 GHz proprietary via an XBee module. The IoT gateway complies with Class 1 Division 2 (C1D2) certification for environments with flammable vapors or gases, as found in industries such as oil and gas, water/wastewater, energy, and agriculture. It is also programmable through a Python API to enable customers’ specific requirements. Digi IX15 IoT Gateway & Cellular Router specifications: Connectivity 10/100M Ethernet RJ45 port 4G LTE Cat 4 cellular connectivity Supported bands 4G – B1, B2, B3, B4, B5, B7, B8, B12, B13, B18, B19, B20, B25, B26, B28, B38, B39, B40, B41 3G: B1, B2, B4, B5, B6, B8, B19 2G EDGE / GPRS: 850 / 900 / 1800 / 1900 MHz Antenna connector – 50 Ω SMA (center pin: female) 2x […]

Digi Introduces XBeeX3 IoT Modules with New Micro Form Factor, RF and Cellular IoT Connectivity

Digi International has just announced the Digi XBee3 series of RF modules and cellular IoT modules. The modules will be available in the existing Digi XBee SMT amd through-hole form factor, as well as a new micro form factor (19×13 mm) that’s about a third of the size of the original XBee RF module. The RF modules will first come with ZigBee 3.0 and IEEE 802.15 support, but Bluetooth LE will be available through a firmware update later on, and WiFi and DigiMesh version will be brought to markets too. The first cellular module supports LTE Cat.1, but the company will eventually launch NB-IoT and eMTC (LTE Cat M) versions for Europe and the US respectively. Some of the shared key capabilities listed by the company: Over-the-air (OTA) changes to devices in the field for bug fixes and new features Dynamically reconfigurable, based upon situation Establish business rules to aggregate, store, […]

Digi Launches XBee-PRO 900HP RF Module With a Range of Up to 45 Km

Digi International has recently announced the XBee-PRO 900HP RF embedded module based on ADF7023 transceiver and Energy Micro Cortex-M3 EFM32G230 MCU @ 28 MHz. The company claims the module supports a line-of-sight range of up to 45 km with a high-gain antenna and data rates of up to 200 Kbps.45 km is not quite enough to communicate in space (100 km), but that’s still a pretty good range. Indoor / urban range is up to 600m. Here are the hardware specifications of XBee-PRO 900HP module: Processors – ADF7023 transceiver and Cortex-M3 EFM32G230 @ 28 MHz Frequency Band – 902 to 928 MHz, software selectable channel mask for interference immunity Antenna Options – Wire, U.FL and RPSMSA RF Data Rate – 10 Kbps or 200 Kbps Indoor/Urban Range – Up to 2000 ft (610 m) Outdoor/ Line-Of-Sight Range – Up to 9 miles (14 km) w/ dipole antenna; Up to 28 […]
