Soap is a Touchscreen Enabled Router Supporting Gigabit Ethernet and Lots of Wireless Standards (Crowdfunding)

Soap is a strange creature, and I’m not convinced there are that many use cases for such hardware, but I find it interesting that the developers decided to pack a Freescale i.MX6 Solo/Dual or Quad SoC powered Android 4.4 tablet and a router supporting five Gigabit Etherner ports, as well as WiFI 802.11ac, Wi-0Fi 802.11 b/g/n,  Zigbee, Z-wave, Bluetooth 4.0 (BLE), Insteon RF, X10, 433Mhz, NFC, and infrared into one and only device which they call an “Intelligent Home Management Hub”.  It’s also complete with an HDMI output port so that you can use it as a media player. Let’s go through the specifications for the four version this little monster (Soap Solo, Soap Dual, Soap Quad, and Soap 8.4): SoC Soap Solo – Freescale i.MX6 Solo single ARM Cortex A9 @ 1 GHz with Vivante GC880 3D GPU Soap Dual – Freescale i.MX6 Dual dual ARM Cortex A9 @ […]

Texas Instruments Releases Zigbee Home Automation Gateway Reference Design Based on BeagleBone Black

Texas Instruments has recently release a complete Linux based Zigbee home automation gateway based on BeagleBone Black development and CC2531 Evaluation Module Kit hardware which you can purchase for about $100 in total, and including Z-STACK Ubuntu gateway installer, as well as Z-STACK Home, a ZigBee Home Automation (ZHA 1.2) compliant protocol stack for the company’s CC2530 and CC2538 SoCs. I won’t go into details about the BeagleBone Black as I have already covered it into details previously. However, the hardware has slightly changed since the initial release, as the 2GB eMMC has now been replaced by a 4GB eMMC, and price has been increased to about $55. CC2531 evaluation module kit is comprised of CC2531 USB Dongle which you can connect to the USB port of a PC, or in this case a BeagleBone Black, for 802.15.4 / ZigBee applications. TI also provides CC2531 USB Firmware Library on their site to let developers […]

DLink Introduces DSP-W215 Wi-Fi Smart Plug for iOS and Android

D-Link is entering the automation market with a Wi-Fi smart plug (Model DSP-W215) that configurable via WPS, allows you to control and monitor your electrical appliance via Android 4.0+ and iOS6+ mobile devices, and it even has an overheating protection mechanism that can apparently detect if the plug or the device itself overheats. Let’s go through the technical specifications: Wi-Fi – IEEE 802.11n (According to pictures found via FCC filings, the chipset is Atheros AR1311_AL1A) Misc – Power / Status LEDs, On/Off button Dimensions – 9 x 6.10 x 3.56 cm (3.54″ x 2.40″ x 1.40″) Weight – 125 g (4.41 ounces) Power Input – 100 to 125 V AC / 5W maximum power consumption Temperature Range – Operating: 0 to 40 °C, Storage: -20 to 65 °F Humidity – Operating: 10% to 90% non-condensing, Storage: 5% to 95% non-condensing Based on these specs, since it can only work between 100 […]

Kankun KK-SP3 is a $20 Wi-Fi Smart Socket for Android and iOS

I’ve already featured Broadlink SP1 and SP2 smart socket on this blog.  The former is a simple Wi-Fi smart socket for Android and iOS, and the later adds support for motion sensing and energy monitoring.  They cost respectively about $30 and $45 including shipping. I’ve discovered another cheaper option with Kankun KK-SP3 via DealExtreme ($23.75), but it can also be found on Aliexpress for as low as $19.99 including shipping. If you live in China, It’s available on Taobao for 99 RMB ($15.82). Here are the specs of this smart socket: Power Plug – Three flat-pin plug (Australia type) Wi-Fi – 802.11 b/g/n, 15 dbm. Texas Instruments Wi-Fi module (CC3000?) Input Voltage – 90~265V @ 50-60 Hz Output Current – 10A Maximum Power – 2200W Dimensions – 5.3 cm x 5.3 cm x 2.8 cm Temperature Range – -10 to 55°C Unless you live in Australia, China, Argentina, New Zealand, […]

Habey HIO Project ARM Board and HIO Wallpad PoE Automation Panel (Crowdfunding)

Habey has recently unveiled HIO Project, a $100 ARM Linux board designed for rapid prototyping powered by Freescale i.MX6 dual lite or quad, and shortly after, the company launched a Kickstarter project for HIO Wallpad, an in-wall Power-over-Ethernet touch controller for home or office automation embedding HIO Project boards. HIO Project Boards HIO Main Board (HIO-EMB-1200) specifications: Soc – Freescale i.MX6 Dual Lite or Quad ARM Cortex A9 processor @ 1 GHz + Vivante GPU System Memory – 1GB DDR3 Storage – 4G iNAND flash, 1x micro SD socket Video Output – 1x HDMI Audio – 1x on-board audio codec with 1W Amplifier built-in to I/O expansion headers Connectivity – 1x GbE PHY to I/O expansion headers Expansion Connectors: 1x PCIe PHY to I/O expansion headers 8x 50-pin 1.27mm pitch female header for I/Os: 24bit Parallel Display Port, dual channel 24bit LVDS, MIPI DSI up to 24bit, MIPI CSI up […]

BroadLink SP2 Wi-Fi Smart Socket for iOS and Android Adds Support for Energy Monitoring, Motion Sensing

Broadlink SP1, a low cost Wi-Fi smart socket released last year,  allows you to control your electric appliance with your mobile device running iOS or Android. You could turn it on or off, set timers, and so on. An updated model is now available, Broadlink SP2, that adds energy monitoring to the features found in the previous model, to track your historic and live power consumption on your smartphone or tablet, as well as a motion sensor to automatically turn off the lights, for instance, if you are away (Auto Home / Auto Away feature). The hardware specifications are very similar to SP1 except it’s using a case made of polycarbonate plastic instead of ABS, and the device is a bit bigger: Material – PC Wi-Fi – 802.11 b/g/n Power Plug – Three flat-pin plug (Australia type) Voltage – 100~265V @ 50-60 Hz Output Current – 10A Output Power – […]

Webee Boss is Both an Android TV Box and an Home Automation Gateway (Crowdfunding)

Lots of Android TV Boxes and HDMI dongles have hit the market last year, and low cost home automation systems have been launched, or are in development, such as Ninja Sphere. Webee Boss combines both to make your TV and your Home smart, as part of the Webee home automation platform, also composed of “Bees” (Smart Plug, Smart Lamp Holder, Smart Host, Presence Tag, Open/Closed sensors, etc…), Hive m3 development board, and an Android app. Webee Boss specifications: SoC – ARM Cortex A9 Microprocessor @ 800MHz System Memory – 1 GB RAM Storage – 2 GB NAND Flash, micro SD card slot up to 32GB Connectivity 10/100M Ethernet 802.11 b/g/n WiFi IEEE 802.15.4 – ZigBee. Mesh networking. Home Automation profile. Z-Wave. Mesh networking. Home Automation standards compatible in most countries. Wireless Range – Outdoor: 45 to 90 meters, Indoor 45 – 60 meters Video Output – HDMI 1.3 (up to […]

Smart Power Strip Controls and Monitors your Electric Appliances with Android or iOS Devices (Crowdfunding)

Broadlink SP1 and Plugaway are smart sockets controlled by your mobile device(s) via Wi-Fi, but they only support one appliance at a time. Smart Power Strip will fix that thanks to 4 sockets with independent power consumption meters that are controlled via Wi-Fi by Android or iOS devices. The power strip is comprised of 4 independent relays, 2 USB ports, a 120V or 230V circuit breaker, and a dual 2.4 GHz module for Wi-Fi and Home Automation (MESH) technology. It supports 100-250V AC, with a maximum of 15 Amps. The smart power strip will be available for US, EU, UK, and AU standards. That’s about all we know about the hardware. The mobile app will allow you to turn on/off devices manually, monitor each appliance’s power consumption individually, set timers, and monitor which device is on/off. As long as you have Internet access, the smart power strip can be accessed […]
