ECS GLKD-HTI is a “Half mini-ITX” motherboard with Gemini Lake processor

half mini-itx motherboard

If you’ve never heard about a “half mini-ITX” motherboard, that’s normal, as I don’t think it’s actually a thing. At least until now, as ECS GLKD-HTI is an Intel Gemini Lake motherboard that’s half the size of a standard mini-ITX motherboard. The board still comes with the usual HDMI, DisplayPort, USB and Ethernet ports, as well as a SODIMM slot for DDR4-2133 memory, an M.2 socket for 2280 SATA SSDs, as well as a SATA 3.0 port. ECS GLKD-HTI “half mini-ITX” motherboard specifications: SoC – Choice of Intel Gemini Lake processors with Intel UHD 600 graphics System Memory – 1x DDR4 SO-DIMM socket for up to 8GB DDR4 2133 non-ECC memory Storage 1x M.2 slot for SSD for 2280 single side SATA SSD 1x SATA 3.0 6Gbps connector 128 MB SPI Flash for AMI BIOS / UEFI Video Output – HDMI 1.4a up to 1920×1200 1x LVDS connector Audio 2x […]

ECS Unveils LIVA Q1L Mini PC with Dual Gigabit Ethernet, LIVA Q1D with HDMI & DisplayPort

LIVA Q1D

ECS introduces one of the smallest Intel mini PCs with LIVA Q Apollo Lake mini PC in 2017, followed by LIVA Q2 Gemini Lake micro PC the following year both just 70x70x31~33mm in size. Ian reviewed LIVA Q2 Micro PC with Windows 10 and Ubuntu 18.10 last year, and he was impressed with the performance considering the form factor, with the mini PC being perfectly suitable for browsing the web, home or office use, or as a digital signage solution. ECS has now updated its original LIVA Q model with the same processor options, but with LIVA Q1L offering two Gigabit Ethernet ports and one HDMI output, while LIVA Q1D comes with two video outputs (HDMI and DisplayPort) and a single Ethernet port. ECS LIVA Q1L/Q1D specifications: SoC (one or the other) Intel Apollo Lake Pentium N4200 quad-core processor @ 1.1 / 2.5 GHz with 18EU Intel HD graphics; 6W […]

LIVA Q2 Review – ECS Micro PC Tested with Windows 10 and Ubuntu 18.10

ECS LIVA Q2 Teardown

ECS (Elitegroup Computer Systems) is a Taiwanese company that has been offering mini PCs for several years now. Last year they announced their ‘pocket-sized’ model the LIVA Q. Originally featuring Apollo Lake SoCs it has now been upgraded and renamed as the LIVA Q2 and offers a choice of Gemini Lake SoCs. The distinguishing feature of the LIVA Q series however is the form-factor. Compared with Intel Compute ‘stick’ PCs and Intel NUC ‘mini’ PCs the LIVA Q2 is a ‘micro’ PC. This micro PC is like a minimalist mini PC that includes just the minimum number of useful ports namely a couple of USB ports (3.1 and 2.0) on one side, a micro SD card slot on another and finally an HDMI (2.0) and gigabit Ethernet at the rear. The resultant micro PC is beautifully small consisting of a 70mm (2.76″) square case by 33.4mm (1.31”) tall which can […]

ECS Introduces GLKD-I DC Powered Gemini Lake Motherboard Family

Except for the odd industrial motherboard, most Gemini Lake motherboards launched so far rely on an ATX connector and power supply, but if you prefer a DC powered Gemini Lake motherboard, ECS now provides several options thanks to their GLKD-I series mini-ITX motherboards equipped with Gemini Lake processor. ECS GLKD-I motherboard specifications: SoC – Intel Gemini Lake processor with Intel UHD graphics; 10W TDP (Celeron J4005, J4105 or Pentium J5005) System Memory – 1x DDR4 SO-DIMM socket up to 8GB RAM; supports DDR4 2400 non-ECC, un-buffered SDRAM Memory Storage – 2x SATA III ports, 1x M.2 slot for SSD, 128 MB SPI Flash ROM for AMI BIOS Video Output – HDMI port, optional D-Sub/VGA port, optional DisplayPort, optional eDP header Audio Realtek ALC662 6-Channel HD audio CODEC 16/20/24-bit PCM format for 5.1 channel audio solution Line Out/Line In/Mic In jacks Front panel MIC/Speaker out header Connectivity – Gigabit Ethernet via […]

ECS LIVA Z2, LIVA Q2 & LIVA One SoC Gemini Lake Mini PCs Introduced at CES 2018

ECS (Elitegroup Computer Systems) was another company introducing their Gemini Lake mini PC at CES 2018, or as they call them “ultra-compact form-factor” (UCFF)  PCs. They had three models with two upgrade from Apollo Lake systems: LIVA Z2 & LIVA Q2, and another system called “LIVA One SoC” which instead offers an entry-level version of their barebone LIVA One mini PC based on Core i3/i5/i7 processors. ECS LIVA Z2 LIVA Z2 specifications: SoC – Intel Gemini Lake processor System Memory – 2x DDR4 SO-DIMM slots Storage – 32 or 64GB eMMC flash, 1x 2.5″ SSD/HDD bay Video Output – HDMI 2.0 and HDMI 1.4 ports (dual HDMI) Audio Output – Via HDMI, 3.5mm audio jack, digital microphone Connectivity – Gigabit Ethernet, 802.11ac WiFi, Bluetooth 4.2 USB – 3x USB 3.0 ports, 2x USB 2.0 ports, 1x USB 3.0 type C port Misc – Power button, Kensington lock Power Supply – 19V/3.42A […]

ECS LIVA Q Could Be The World’s Smallest 4K mini PC

Taiwan based ECS announced several Apollo Lake mini PCs in the past such as Liva Z /ZE based on Intel Celeron N3350/N3450 or Pentium N4200 processor. The company has now launched a new Apollo Lake model. LIVE Q is powered by either Intel Pentium  N4200 quad core processor, or Intel Celeron N3350 dual core processor, fitted with 2 to 4GB RAM, and the company claims it’s the world’s smallest “4K pocket computer”. ECS LIVA Q specifications: SoC Intel Apollo Lake Pentium N4200 quad core processor @ 1.1 / 2.5 GHz with 18EU Intel HD graphics; 6W TDP Intel Apollo Lake Celeron N3350 dual core processor @ 1.1 / 2.4 GHz with 12EU Intel HD graphics; 6W TDP Memory – 2GB/4GB LPDDR4 Storage – 32 or 64GB eMMC flash, micro SD slot up to 128GB Video Output – HDMI 2.0 up to 4K @ 60 Hz Connectivity – Gigabit Ethernet, Intel […]

ECS Liva Z / ZE Apollo Lake mini PCs Showcased at CES 2017

We first heard about ECS Liva Z mini PCs based on Intel Apollo Lake processors at Computex 2016, but at the time there was very little information about the platforms. Since then Intel has officially launched Apollo Lake processor, and ECS is now at CES 2017 where they showcased ECS Liva Z and Liva ZE mini PCs powered by Intel Celeron N3350, N3450 or N4200 processor. Both models are pretty similar, but Liva ZE adds a 2.5″ SATA bay, a digital microphone input, and four RS232 COM ports. LIVA Z LIVA ZE CPU Intel Apollo Lake SoC (Intel Celeron Processor N3350 / N3450 / N4200) (6W TDP) PCH Integrated Graphics Intel HD Graphics 500 / 505 Memory 2x DDR3L SO-DIMM Slots Storage 1x eMMC 32G/64G 1x M.2 2242 SATA III 1x eMMC 32G/64G 1x M.2 2242 SATA III 1x 2.5″ SATA III Wi-Fi Intel AC3165 1×1 802.11ac + BT 4.0 […]

ECS previews Intel Apollo Lake based Liva-Z mini PC at Computex 2016

If anything is clear from having walked around this year’s Computex, then it is that the mini PC is here to stay. Beyond plenty of socketed boards using Intel’s new STX form factor from just about every vendor, there are also plenty of other mini PC’s on display. One that caught our eye at the show was ECS’ new Liva, tentatively named the Z. The following specifications were revealed by ECS: SoC – Intel Apollo Lake System Memory –  2x DDR3L SO-DIMM’s Storage – 32GB/64GB eMMC flash + 1x M.2 2280 for SSD (unclear if it supports PCIe drives) Video Output – Mini DisplayPort, HDMI (no revisions mentioned) Audio – DisplayPort, HDMI and 3.5mm headphone jack Connectivity – 2x Gigabit Ethernet, 802.11ac WiFi and Bluetooth 4.0 USB – 1x USB 3.0 Type-C, 3x USB 3.0 ports Power Supply – 19V/2.1A It’s so far the only Intel Apollo Lake system we’ve […]
