PicoCore RT1 System-on-Module Runs FreeRTOS on NXP i.MX RT1050 Crossover Processor

F&S Elektronik Systeme PicoCore RT1 is a System-on-Module powered by NXP i.MX RT1050 crossover processor designed to offer the real-time capabilities of microcontrollers and the performance of application processors thanks to an Arm Cortex-M7 core clocked at up to 600 MHz. The 40×35 mm module is also equipped with 32MB SDRAM, 256MB “high-reliability QSPI NOR flash, and 16KB EEPROM, and offers various interfaces including Ethernet, RGB LCD, and USB via board-to-board connectors. PicoCore RT1 (V1) SoM specifications: SoC – NXP i.MX RT1050 Arm Cortex-M7 processor @ up to 600 MHz with 32KB L2 cache, 2D graphics accelerator System Memory – 32MB SDRAM Storage – 256MB QSPI Flash, 16KB EEPROM; optional NAND flash 2x 80-pin board-to-board connector with Storage – SD Card Display – 16-bit RG interface, analog resistive and PCAP touch via I2C Networking – 1x 10/100M Ethernet Audio – Line-In, Line-Out, microphone, headphone, I2S USB – 1x USB 2.0 host, 1x USB 2.0 OTG Serial – Up to 2x […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

PicoCore MX8MN is a Tiny NXP i.MX 8M Nano Computer-on-Module

The PicoCore MX8MN Nano carries the NXP i.MX 8M Nano F&S Elektronik Systeme has announced the development of the smallest i.MX 8M based CoM yet: the PicoCore MX8MN Nano. Previously we had reported on the Congatec Conga-SMX8 Nano which was a fairly small CoM compliant with SMARC 2.0 standard. The PicoCore MX8MN is based on the NXP i.MX 8M Nano CPU with 1 to 4 Arm Cortex-A53 cores and a Cortex-M7 real-time core. The Nano is set to carry up to 8GB RAM and 32 GB eMMC, with optional WiFI/BT and support for -40º C to 85º C temperature ranges. Similar to Predecessor The PicoCore MX8MN Nano is very similar in structure to the PicoCore MX8MM Mini CoM, but with a different i.MX 8M Mini processor featuring the same Arm Cortex-A53 cores, but the Cortex M4 real-time core is changed to a more powerful Cortex-M7 core in the MX8MN Nano. The MX8MN Nano has no photo on the product page […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

NXP i.MX 7ULP Enters Mass-Production, EVK and Systems-on-Module Announced

Last year, we wrote about F&S Elektronik Systeme PicoCORE MX7 system-on-module (SoM) powered by NXP i.MX 7ULP processor manufactured with a 28nm FD-SOI process, and that was announced a year earlier. The official launch of the module was planned for Q3 2018, but there have been some delays as LinuxGizmos reports NXP has only started mass production of their i.MX7 ULP this June. With the official launch of i.MX 7ULP, the company also introduced the official i.MX 7ULP Evaluation Board (MCIMX7ULP-EVK) as showcased on Element14’s community and several other companies announced i.MX 7ULP systems-on-modules. Benefits of NXP i.MX 7ULP Processor The i.MX7 ULP family of processors is an extremely power-efficient series, that is utilizing lower power for more functions. The SoC is being touted as the most power-efficient processor that can be obtained that also houses a 3D GPU.  Although like the i.MX7, the i.MX 7ULP combines both Cortex-A7 and Cortex-M4 cores but can effectively bring the power states even […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

F&S Elektronik PicoCore MX8MM System-on-Module Features NXP i.MX 8M Mini Processor

FS i.MX 8M Mini SoM

Embedded World 2019 will take place at the end of this month on February 26-28 in Nuremberg, Germany, and we can expect plenty of news related to embedded systems. It’s very likely NXP i.MX 8M Mini processor will officially be launched, and we’ll see several modules and boards announced with the lower cost 14-nm processor. F&S Elektronik Systeme has already been promoting their upcoming PicoCore MX8MM system-on-module based on NXP i.MX 8M in their newsletter ahead of Embedded World, where they’ll showcase their solutions at booth 621 in hall 2. PicoCore MX8MM specifications: SoC – NXP i.MX 8M Mini single, dual, quad core Arm Cortex-A53 @ 1.8 GHz processor, Cortex-M4 real-time core @ 400 MHz, 512KB L2-Cache, 2D/3D GPU System Memory – Up to 8GB LPDDR4 Storage – Up to 512MB SLC NAND flash or up to 32GB eMMC flash Video Decode – 1080p60 HEVC H.265, VP9, H.264, VP8 Connectivity 802.11ac + Bluetooth 5.0 module Atheros AR8035 Gigabit Ethernet transceiver Interfaces […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

F&S Elektronik ArmStone MXM8 Pico-ITX Board is Equipped with Up to 8GB RAM, NXP i.MX8M Processor

F&S Elektronik Systeme has been working on a new SBC part of their ArmStone family with ArmStone MXM8 single board computer, featuring NXP i.MX 8M quad core Cortex A53 processor, and supporting up to 8GB LPDDR4 RAM. The Pico-ITX board also comes with up to 32GB eMMC flash, integrate Gigabit Ethernet and wireless connectivity, DVI and dual-channel LVDS outputs, USB 3.0, PCIe and more interfaces. The layout is very similar to the company’s ArmStone A53SD pico-ITX board launched last year with a Qualcomm Snapdragon 410E processor. ArmStone MXM8 preliminary specifications: SoC – NXP i.MX 8M Dual or Quad Arm Cortex A53 processor @ up to 1.5 GHz, Arm Cortex-M4 real-time core, and Vivante GC7000Lite GPU with support for OpenGL/Es 3.1, OpenGL 3.0, Vulkan System Memory – Up to 8GB LPDDR4 Storage – Up to 32GB eMMC flash, up to 1GB SLC NAND flash, optional micro SD slot Video Output – Dual channel LVDS connector, analog resistive and PCAP touch via […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

PicoCORE MX7ULP is a Compact Module Based on NXP i.MX 7ULP Ultra Low Power Processor

NXP unveiled another variant of their i.MX 7 Cortex A7 processor last year, and I missed it. NXP i.MX 7ULP offers many of the same features as i.MX 7, but is manufactured using FD-SOI (Fully Depleted Silicon On Insulator) process technology to offer lower power consumption, as low as 15 mW or less in deep sleep, or 17 times less in comparison to i.MX 7 devices, while the dynamic power efficiency is improved by 50 percent on the real time domain (Cortex-M4). I found out about it thanks to an email from F&S Elektronik Systeme about the introduction of their  PicoCORE MX7ULP module – based on i.MX 7ULP processor – at  the Embedded World 2018 conference. PicoCORE MX7ULP CoM specifications: SoC – NXP i.MX 7ULP Arm Cortex-A7 processor @ up to 800 MHz,  with Arm Cortex-M4 real-time core, and 2D/3D graphics accelerator System Memory – Up to 1GB LPDDR3 Storage – Up to 64 MB SPI flash, up to 32GB […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

F&S Elektronik armStone A53SD Pico-ITX SBC Features Qualcomm Snapdragon 410E Processor

F&S Elektronik Systeme GmbH will showcase their solutions at Embedded World 2017 next week, including their latest ARM Cortex A53 modules and boards based on NXP QorIQ LS1012A, and Qualcomm Snapdragon 410E processors. Today, I’ll write about the later with the company’s armStone A53SD pico-ITX single board computer equipped with up to 32GB flash and 8GB memory. armStone A53SD board specifications: Processor – Qualcomm Snapdragon 410E quad core ARM Cortex-A53 processor @ up to 1.2 GHz with Adreno GPU System Memory – Up to 8GB LPDDR3 RAM Storage – Up to 32GB eMMC flash, 1x micro SD card slot Display – 24-bit LVDS, DVI up to 720p, I2C for touch controller Audio – Line In/Out/Mic via header Connectivity – 1x 10/100M Ethernet, WiFi IEEE 802.11a/b/g/n, Bluetooth 2.1+EDR/4.1 LE USB – 3x USB 2.0 host ports, 1x USB 2.0 device port Camera – MIPI-CSI connector Expansion – Unpopulated 66-pin header with 1x CAN 2.0, 2x UART, 1x I2C, 1x SPI, up […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

F&S Elektronik Introduces efus A53LS NXP QorIQ LS1012A System-on-Module for Communication & Networking Applications

NXP QorIQ LS1012A is a single core Cortex A53 communication processor that offers a 64-bit update to LS1021A dual core Cortex A7 processors found in gateways such as NXP LS1021A-IOTA IoT gateway reference design, and F&S Elektronik System has just launched efus A53LS system-on-module powered by the processor with up to 1GB RAM, up to 64SQPI NOR, access to the communication interfaces and peripherals from the processor via an efus compliant edge connector, and long term availability until 2030. efus A53LS COM specifications: Processor – NXP QorIQ Layerscape LS1012A  single core ARM Cortex-A53 @ up to 800MHz System Memory – 512MB DDR3 by default, supports up to 1GB DDR3 RAM Storage – Up to 64MB QSPI NOR flash on-module, I/Os for SATA and SD card on edge connector Connectivity – 2x Realtek RTL8211F(N) Gigabit Ethernet transceiver chips, optional wireless module with dual WiFi IEEE802.11b/g/n/ac and Bluetooth 4.0 LE efus edge connector with 1x SDIO 2x Gigabit Ethernet 1x USB 3.0 […]
