Posted on by Jean-Luc Aufranc (CNXSoft) - 13 Comments on Shelly Motion sensor to feature Silicon Labs WiFi chip with Bluetooth-like power consumption

Shelly Motion sensor to feature Silicon Labs WiFi chip with Bluetooth-like power consumption

[Update: The information from Shelly about a new “Cortana M3” processor is incorrect, we’ve been contacted by Silicon Labs, and there’s no Cortana M3 microcontroller from the company, Shelly is just using one of the company’s Cortex-M3 based WiFi solutions (SoC or module). The article remains unchanged] WiFi is one of the most convenient ways to connect IoT devices as it’s omnipresent, low-cost, and the range is ideal for the typical smart home. That’s all good until you start to power the device with a tiny battery, as WiFi consumes much more power than Zigbee, Z-Wave, or Bluetooth. Over five years ago, Rockchip RKi6000 WiFi SoC promised Bluetooth 4.0 LE power consumption numbers allowing coin-cell powered WiFi devices, and there were some demos the following year, but I’ve yet to see a consumer device based on the solution. This brings me to the main topic of this post: Shelly Motion, a soon-to-be-launched smart motion sensor said to be powered by […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on Tiny USB WiFi Camera Supports Motion and AI Human Detection

Tiny USB WiFi Camera Supports Motion and AI Human Detection

USB WiFi Camera

When I first saw U21 HD camera it reminded me of SOOCOO G1 is action camera with a flexible stick, since the camera also comes with a flexible hose which allows you to orient it as you please. But it’s a different bear, as U21 is a surveillance camera powered over USB and featuring WiFi connectivity. I can’t see any motion detection, so it may have some dose of “AI” since it claims to support motion and human detection so you only get relevant alerts. It is currently sold (pre-orders) on Banggood for $33.65 including shipping with order starting to be processed on October 30th. U21 USB WIFI camera key features and specifications: MCU / WiSoC – No information (yet) Storage – MicroSD card slot up to 128GB for up to one month of recording (8GB = 2 days); Cloud storage via third party (paid) Camera – 14mm lens, HD resolution Alerts – Motion detection, AI human detection (provided and […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 8 Comments on A95X Max Plus S922X TV Box Targets Gaming with Wii-like Motion Sensing Remote & Bluetooth Gamepad

A95X Max Plus S922X TV Box Targets Gaming with Wii-like Motion Sensing Remote & Bluetooth Gamepad

Amlogic S922X Android Gaming Console TV Box

Unless a new processor is out, we don’t cover most TV boxes as they mostly provide the same features with little differentiation between products. But the manufacturer of A95X Max Plus TV box has decided to leverage the excellent gaming performance of Amlogic S922X processor, by bundling the device with a Wii-like motion-sensing remote control and a Bluetooth gamepad. The mechanical design is quite different from competing products as well. A95X Max Plus TV box specifications: SoC – Amlogic S922X hexa-core big.LITTLE processor with 4x Arm Cortex A73 cores, 2x Arm Cortex A53 cores, Arm Mali-G52MP GPU; 12nm process System Memory – 4GB LPDDR4 RAM Storage – 64GB eMMC flash, microSD card slot Video Output – HDMI 2.1 up to 4K @ 75 Hz, AV port (composite) Video – AVE-10 engine with 4K UHD H.265/VP9/AVS2 video decoding up to 60 fps, Dolby Vision, Advanced HDR10, HDR10+, HLG, and PRIME HDR high-dynamic range support Audio – Digital audio via HDMI, stereo […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Microsoft Introduces Project Kinect for Azure

Microsoft Introduces Project Kinect for Azure

Kinect started as as motion sensing input device for Xbox 360 & One game consoles with an integrated webcam, infrared projector, and a microphone array, which enabled it to detect depth, motion, and voice from gamers. But it also become popular with maker projects due to price and capabilities, and was even found to be a worthy microphone array for voice commands. The third generation of Kinect went into Hololense mixed reality headset, and Microsoft has just unveiled the fourth generation Kinect with Project Kinect for Azure. AFAIK, the company did not provide the full technical details about the new Kinect, but we know it comes with an RGB camera, a 360-degree mic array, an accelerometer, and a time-of-flight (ToF) depth-sensor, and the company did offer some details about the latter : Number of pixels: 1024×1024 resolution Highest Figure of Merit (highest modulation frequency and modulation contrast resulting in low power consumption with overall system power of 225-950mw) Automatic per […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on SocioNext MN87900 is a Really Tiny 24 GHz Radio Wave Radar Module for the Internet of Things

SocioNext MN87900 is a Really Tiny 24 GHz Radio Wave Radar Module for the Internet of Things

In the past, we covered tiny microwave radar modules operating at 5.8 GHz and measuring just 32 x 23 mm. Those modules are normally used to detect motion, distance, and/or direction of movement. Socionext has now introduced MN87900, a single low-power single-chip 24 GHz radio wave IoT sensor solution that even smaller at just 12x7mm with the chip, Tx and Rx antennas, crystal, and 40-pin to solder the module to your board. The solution targets IoT equipments, security systems, smart home appliances, autonomous vehicles and drones, medical devices, and more. SocioNext MN87900 key specifications: Sensor Type – CW, FSKCW, FMCW (moving or stationary) Detection Motion direction – approaching or leaving Motion speed – up to 200 km/h Range – 0.15 to 8 meters 80°@-3dB, expandable to 30 meters  with a radome horn, a metal shield that narrows the field of view. Variable frequency width –  24.15±0.1 GHz Transmission Power – 0.8mW Host Interface – SPI Power supply voltage – 2.5V […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Karl Johnson - 11 Comments on Karl’s Home Automation Project – Part 2: 433 MHz / WiFi MQTT Bridge, Door & PIR Motion Sensors

Karl’s Home Automation Project – Part 2: 433 MHz / WiFi MQTT Bridge, Door & PIR Motion Sensors

Karl here again for part 2 of my home automation project. We will be looking at how to automate your lights based on time of day and motion. In the first part we setup Home Assistant and uploaded firmware to basic Sonoff Wifi switches. Today we will setup a 433 MHz to MQTT bridge and some sensors. 433 MHz Depending on your country 433 MHz is an open frequency to use to communicate with. There are hundreds of different types of devices that use 433 MHz to communicate information. We will be focusing on 2 today from Gearbest: WMS07 motion sensor (left) and WDS07 door/window sensor (2 parts, right). I am not taking the door/window sensor apart, since it is super basic, but I’ve included some photos of the PIR motion detector. 433 MHz Bridge While contemplating how to get presence on a per room basis I ran across this project. It monitors 433 MHz signals and publishes it to […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on Infineon Showcases the Radar Board used in Google’s Project Soli, and Sense2Go Development Kit (Video)

Infineon Showcases the Radar Board used in Google’s Project Soli, and Sense2Go Development Kit (Video)

Google’s Project Soli sensing technology uses a miniature radar to detect touchless gesture interactions, so that you can control devices such as wearables using gestures without having to physical touch the product. The 60 GHz radar technology used in the project has been developed by Infineon, and the company was recently interviewed by Arrow Electronics where they showcased Soli board, as well as another 24 GHz radar development kit called Sense2Go. The Soli board called BGT60TR24 features Infineon XMC4500 ARM Cortex M4 MCU, and a 60 GHz “CRIS20” radar chip designed specially for Project Soli by Infineon, and allowing 20mm resolution, falling to less than one millimeter with Google’s algorithms. The micro USB port will be used for power and programming. This board should be the one included in Project Soli development kit to be shipped to developers this fall. Infineon also have a Sense2Go 24GHz sensor development kit that can detect motion, speed, and direction of movement in applications […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 20 Comments on Tiny Microwave Radar Module Detects Movements Up to 9 Meters Away for $2

Tiny Microwave Radar Module Detects Movements Up to 9 Meters Away for $2

PIR sensors are used to detect motion for example to turn on or off a light bulb when motion is detection. One such sensor is HC-SR501 motion detector, which costs around $1, and is tiny (32 x 24 mm), but not quite thin due to the design that needs to capture infrared light, with an height of around 2 centimeters. If you’d like something almost as cheap, just as small, but much thinner, microwave radar modules could be a good alternative. XYC-WB-DC is one of those modules with the following specs: Operating Frequency – 5.8 GHz Detection angle – 360° Detection range – 6-9 meters Working Voltage – 3.3-20VDC; Standby current –  <3mA; Transmit power – <2mW; Dimensions – 32 x 23 mm Operating temperature range – -20 ~ +80 Centigrade; Potential advantages over PIR sensors include wider detection angle, and lower power consumption, HC-SR501 datasheet reports respectively 120 degrees detection, and 65 mA “power consumption” @ 5V. The range […]
