Posted on by Tomisin Olujinmi - 3 Comments on RK3568-based MYC-LR3568 system-on-module comes with up to 8GB RAM, 32GB storage for cost-sensitive Edge AI applications

RK3568-based MYC-LR3568 system-on-module comes with up to 8GB RAM, 32GB storage for cost-sensitive Edge AI applications

MYIR MYD-LR3568 development board

MYIR Tech has announced the release of the Rockchip RK3568-based MYC-LR3568 Edge AI system-on-module (SoM) offered in a compact 381-pin expansion LGA package design. It features up to 8GB LPDDR4 RAM, 32GB eMMC flash storage, a power management integrated circuit, and various connectivity options. The base configuration of the MYC-LR3568 system-on-module offers only 2GB RAM and 16GB storage but the module supports up to 8GB RAM and 32GB eMMC storage. It supports several video codecs, including 4K 60fps H.265/H.264/VP9 decoding and 1080P 60fps H.265/H.264 encoding, for high-quality video playback and recording. The MYC-LR3568 SoM works with Debian and Linux operating systems. It is designed for cost-sensitive industrial applications including but not limited to IoT gateways, NVR storage, industrial control, human-machine interface (HMI), cloud terminals, and facial recognition systems. MYIR Tech’s MYC-LR3568 specifications: SoC – Rockchip RK3568 (B2 or J variant) CPU RK3568B2 – Quad-core processor with four Cortex-A55 cores @ 2.0 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Allwinner T527 digital signage and Smart Display board offers HDMI, eDP, MIPI DSI, and LVDS display interfaces

Allwinner T527 digital signage and Smart Display board offers HDMI, eDP, MIPI DSI, and LVDS display interfaces

Allwinner T527 digital signage board

MYiR Tech’s MYD-LT527-SX is a board designed for digital signage and Smart Display applications based on the MYC-LT527 Allwinner T527 system-on-module from the company and offering a range of display interfaces namely HDMI, eDP, MIPI DSI and dual-channel LVDS. The digital signage board builds upon MYiR Tech’s MYD-LT527 development board with a larger design featuring many of the same ports (dual GbE, USB 3.0, audio jack, HDMI output), and plenty of connectors for expansion including additional USB 2.0 interfaces, speaker and microphone, RS232, RS485, CAN Bus, and more. MYiR Tech’s MYD-LT527-SX specifications: SoM – MYC-LT527 system-on-module with SoC – Allwinner T527 CPU Octa-core Arm Cortex-A55 processor with four cores @ 1.80 GHz and four cores @ 1.42GHz E906 RISC-V core up to 200 MHz DSP – 600MHz HIFI4 Audio DSP GPU – Arm Mali-G57 MC1 GPU System Memory – 2GB LPDDR4 Storage – 16GB eMMC flash, 32Kbit EEPROM 381-pad LGA […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on MYiR Tech launches AMD XC7A100T Artix-7 FPGA system-on-module and development board with PCIe, SFP+ cages, dual GbE

MYiR Tech launches AMD XC7A100T Artix-7 FPGA system-on-module and development board with PCIe, SFP+ cages, dual GbE

AMD XC7A100T FPGA development board

MYIR MYC-J7A100T is a System-On-Module (SoM) powered by an AMD/Xilinx Artix-7 XC7A100T FPGA with up to 101,440 logic cells, 512MB DDR3 memory, 32MB QSPI FLASH, 32KB EEPROM, DC-DC power management, and other integral circuits in a compact 69.6 x 40mm form factor. The module exposes up to 178 FPGA I/Os, four pairs of GTP high-speed transceiver interfaces, and a JTAG interface through its 260-pin edge connector. MYiR also provides a development board for the MYC-J7A100T module which looks like a PCIe 2.0 card and comes with SFP+ cages, HDMI input and output ports, dual GbE, and a GPIO expansion header. MYIR MYC-J7A100T system-on-module Specifications: FPGA – AMD/Xilinx XC7A100T Artix-7 FPGA (XC7A100T-2FGG484I) with 101,440 logic cells 4,860 Kb of Block RAM 240 DSP slices 8 GTP transceivers capable of reaching speeds up to 6.6Gb/s PCIe Gen2 x4  interface Up to 300x single-ended I/Os System Memory – 512MB DDR3 Storage – 32MB […]

Posted on by Tomisin Olujinmi - 3 Comments on New NXP i.MX 93-based system-on-modules launched by MYiR, Variscite, and Compulab

New NXP i.MX 93-based system-on-modules launched by MYiR, Variscite, and Compulab

MYIR MYD-LMX9X development board

We have covered announcements about early NXP i.MX 93-based system-on-modules such as the ADLINK OSM-IMX93 and Ka-Ro Electronics’ QS93, as well as products integrating the higher-end NXP i.MX 95 processor such as the Toradex Titan Evaluation kit. Three additional NXP i.MX 93 SoMs from Variscite, Dart, and Compulab are now available. Targeted at industrial, IoT, and automotive applications, the NXP i.MX 93 features a 64-bit dual-core Arm Cortex-A55 application processor running at up to 1.7GHz and a Cortex-M33 co-processor running at up to 250MHz. It integrates an Arm Ethos-U65 microNPU, providing up to 0.5TOPS of computing power, and supports EdgeLock secure enclave, NXP’s hardware-based security subsystem. The heterogeneous multicore processing architecture allows the device to run Linux on the main core and a real-time operating system on the Cortex-M33 core. The processor is designed for cost-effective and energy-efficient machine learning applications. It supports LVDS, MIPI-DS, and parallel RGB display protocols […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 5 Comments on Remi Pi is a compact, low-cost SBC powered by a Renesas RZ/G2L Cortex-A55/M33 SoC

Remi Pi is a compact, low-cost SBC powered by a Renesas RZ/G2L Cortex-A55/M33 SoC

Remi Pi SBC

MYiR Tech Remi Pi is a low-cost SBC based on the company’s MYC-YG2LX CPU module featuring a Renesas RZ/G2L Arm Cortex-A55/M33 processor, 1GB RAM,  8GB eMMC flash, and plenty of ports and interfaces. Those include two gigabit Ethernet ports, a wireless module with dual-band WiFi 4 and Bluetooth 4.2 connectivity, HDMI and LVDS display interfaces, MIPI CSI camera input, a 3.5mm audio jack, a few USB ports, and a 40-pin GPIO header compatible with the one on the popular Raspberry Pi SBCs. Remi Pi specifications: System-on-Module – MYiR MYC-YG2L23 module with SoC – Renesas RZ/G2L processor (R9A07G044L23GBG) CPU 1.2 GHz dual-core Arm Cortex-A55 processor 200 MHz Arm Cortex-M33 real-time core GPU – Arm Mali-G31 3D GPU VPU – H.264 decoding/encoding System Memory – 1GB DDR4 Storage – 8GB eMMC flash, 32KB EEPROM PMIC – Renesas RAA215300 power management IC Storage – MicroSD card slot Display interfaces HDMI video output LVDS […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on Allwinner T527 System-on-Module features octa-core Cortex-A55 CPU, 2 TOPS AI accelerator

Allwinner T527 System-on-Module features octa-core Cortex-A55 CPU, 2 TOPS AI accelerator

Allwinner T527 system-on-module

MYiR MYC-LT527 is a compact System-on-Module (SoM) based on Allwinner T527 octa-core Arm Cortex-A55 SoC with a 2 TOPS AI accelerator, up to 4GB RAM, 32GB flash, and a land grid array (LGA) comprised of 381 pads with a range of interfaces for displays and cameras, networking, USB, and PCIe, and more. The company also introduced the MYD-LT527 development board to showcase the capabilities of the Allwinner T527 CPU module suitable for a range of applications such as industrial robots, energy and power management, medical equipment, display and controller machines, edge AI boxes and boards, automotive dashboards, and embedded devices that require media and AI functionalities. MYC-LT527 Allwinner T527 System-on-Module MYC-LT527 specifications: SoC – Allwinner T527 CPU Octa-core Arm Cortex-A55 processor with four cores @ 1.80 GHz and four cores @ 1.42GHz E906 RISC-V core up to 200 MHz DSP – 600MHz HIFI4 Audio DSP GPU – Arm Mali-G57 MC1 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on Renesas RZ/G2UL Arm Cortex-A55/Cortex-M33 industrial system-on-module sells for as low as $17 in volume

Renesas RZ/G2UL Arm Cortex-A55/Cortex-M33 industrial system-on-module sells for as low as $17 in volume

Renesas RZ/G2UL development board

MYiR Tech MYC-YG2UL is a tiny (39x37mm) system-on-module based on the Renesas RZ/G2UL SoC with a 1GHz Arm Cortex-A55 application core and 200MHz real-time Cortex-M33 cores designed for industrial HMIs and gateways, and the company has also launched the MYD-YG2UL development board with the module and interfaces such dual gigabit Ethernet, RS485, RS232, CAN Bus, and more. MYC-YG2UL Renesas RZ/G2UL CPU module Specifications: SoC – Renesas RZ/G2UL (Type-I) CPU – Arm Cortex-A55 processor at up to 1 GHz MCU – Arm Cortex-M33 clocked at up to 200 MHz GPU – 2D graphics (Image Scaling Unit) System Memory – 512MB DDR3L Storage – 4GB eMMC flash, 4KB EEPROM 1.0mm pitch 140-pin castellated holes and 50-pin LGA Display – RGB LCD interface Camera – MIPI CSI interface Networking – 2x RGMII (gigabit Ethernet) USB – 2x USB 2.0 Analog – 2x ADC Other I/Os – 5x SCIF, 2x SCI, 2x CAN FD, 4x […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on SemiDrive D9-Pro (D9360) Arm Cortex-A55/R5 processor powers industrial CPU module for motor control

SemiDrive D9-Pro (D9360) Arm Cortex-A55/R5 processor powers industrial CPU module for motor control

MYD JD9360 SemiDrive D9 Pro Development Board

MYiR MYC-JD9360 is a CPU Module powered by SemiDrive D9-Pro (D9360) processor with six Arm Cortex-A55 application cores, a dual-core lock-step Cortex-R5 real-time core along with a PowerVR GPU, 4Kp30 H.265/H.264 VPU and a 0.8 TOPS NPU, and designed for motion control and industrial applications. The MYC-JD9360 CPU module also comes with 2GB LPDDR4, 16GB eMMC flash, 16MB QSPI Flash, 256Kbit EEPROM, and exposes I/Os such as PCIe 3.0, USB 3.0, CAN FD, and TSN-enabled Gigabit Ethernet through a 314-pin MXM connector. The company also provides the MYD-JD9360 development board to quickly get started with the module and evaluate the solution. MYiR MYC-JD9360 CPU module with SemiDrive D9-Pro SoC Specifications: SoC – SemiDrive D9-Pro (D9360) CPU Application – Hexa-core Arm Cortex-A55 processor @ 1.6 GHz Real-time – Dual-core lock-step Cortex-R5 cores @ 800MHz GPU – Imagination PowerVR 9XM GPU @ 100 GFLOPS VPU – 4Kp30 H.265/VP8/VP9 video decoder, 4Kp30 H.264 […]
