nano-itx News - CNX Software - Embedded Systems News

October 25, 2024October 25, 2024 by Sayantan Nandy - 1 Comment

Portwell WEBS-21J0-ASL – A rugged embedded system with Intel Atom x7000RE Nano-ITX motherboard and Hailo-8 AI accelerator

Portwell’s WEBS-21J0-ASL is a fanless, rugged embedded system with a Nano-ITX motherboard powered by an Intel Atom x7000RE Series processor and optimized for industrial IoT applications. It features two 2.5Gbps Ethernet ports, dual 4K display support (DP/HDMI), and a serial port as well as M.2 E and B Key sockets for wireless and storage expansion. Designed for harsh environments, the WEBS-21J0-ASL operates in temperatures ranging from -20°C to 60°C. The system is equipped with DDR4 SO-DIMM memory (up to 16GB and 10Gbps USB 3.2 Gen 2 ports. It has passed vibration and shock tests for durability in rugged applications making it suitable for a wide range of industrial and automation systems. The WEBS-21J0-ASL also supports optional integration with the Hailo-8 AI acceleration module delivering up to 26 TOPS of AI performance for applications requiring advanced AI capabilities. This makes it an ideal solution for robotics, medical equipment, outdoor gateways, and […]

May 6, 2024May 5, 2024 by Debashis Das - No Comments

Nano-ITX motherboard is powered by Intel Atom x7000RE Series “Amston Lake” SoC

NANO 6064 ASL An Intel Atom x7000RE Series SoC based NANO ITX Board with Triple Display, 2.5GbE LAN, USB 3.2 Gen2, M.2, SATA III

Portwell NANO-6064-ASL is an Intel Atom “Amston Lake” x7000RE-powered Nano-ITX motherboard. The board looks very similar to the Portwell Nano-6062 and features an operating temperature of -40°C to 85°C. The motherboard can support a max of 16GB DDR4 memory and features triple display output, dual 2.5Gbps Ethernet, USB, M.2, SATA, GPIO, and more, and takes power from a 12V external power input. Previously, we’ve written about a range of Nano-ITX boards and SoMs with Amston Lake SoCs, including the ASRock SBC-262M-WT, conga-SA8 SMARC modules, ADLINK Atom x7000RE & x7000C COM Express and SMARC 2.1 modules and others. If you’re looking for similar options, feel free to check out those articles. Portwell NANO-6064-ASL Specifications SoC (one or the other) Amstom Lake Intel Atom x7211RE dual-core processor with 6MB cache, 16EU Intel UHD graphics; 6W TDP Intel Atom x7213RE dual-core processor with 6MB cache, 16EU Intel UHD graphics; 9W TDP Intel Atom x7433RE […]

January 26, 2022January 31, 2022 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

PiGear Nano – A Nano-ITX Raspberry Pi CM4 carrier board with 7-30V DC input

PiGear Nano is an Nano-ITX carrier board for Raspberry Pi CM4 (Compute Module 4) designed for industrial applications with a -30°C to +80°C temperature range, 7 to 30V DC input, as well as RS232, RS485, and CAN bus interfaces. The board also features one Gigabit Ethernet port, one HDMI port, MIPI DSI and CSI display & camera interface, M.2 SSD storage, eight USB 3.0 ports, mini PCIe and SIM card sockets for 4G LTE cellular connectivity, and various digital input and output interfaces. Pigear Nano specifications: Supported SoM – Raspberry Pi CM4 and CM4 Lite modules Storage – 1x NVMe SSD M.2 socket, 1x MicroSD card slot for Compute Module 4 Lite only Display I/F – 1x HDMI Type-A connector, 1x MIPI DSI interface x 1 Camera I/F – 1x MIPI CSI interface Networking 1x Gigabit Ethernet RJ45 port Optional 4G LTE/GPRS via mini PCIe socket plus SIM card slot […]

April 27, 2017 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

Intrinsyc Introduces Open-Q 2100 SoM and Devkit Powered by Qualcomm Snapdragon Wear 2100 SoC for Wearables

Qualcomm unveiled Snapdragon Wear 2100 SoC for wearables early last year, and since then a few smartwatches powered by the processor – such as LG Watch Style and Watch Sport – have been launched, and Intrinsyc has now unveiled one of the first module based on the processor with Open-Q 2100 system-on-module, and a corresponding Nano-ITX baseboard. Open-Q 2100 SoM specifications: SoC – Qualcomm Snapdragon Wear 2100 (APQ8009W) quad core ARM Cortex A7 processor @ up to 1.094 GHz with Adreno 304 GPU System Memory – 512 MB LPDDR3 Storage – 4GB eMMC flash Connectivity – 802.11 b/g/n WiFi (WCN2320), Bluetooth 4.1 LE, Gen 8C GNSS (GPS/GLONASS) with on-board u.FL connector (WGR7640) Audio – Integrated Codec/PMIC (PM8916-1) with optional support for Fluence HD, Snapdragon Voice Activation, and Snapdragon Voice+ 2x 100-pin board-to-board connectors with USB 2.0, I2S, GPIO, MIPI DSI up to 720p @ 60 Hz, 2-lane MIPI CSI, SDC2/microSD […]

March 30, 2017 by Jean-Luc Aufranc (CNXSoft) - 23 Comments

$100 Qotom Q1900G4-M Nano-ITX Board Powered by Intel Celeron J1900 SoC is Equipped with Four Gigabit Ethernet Ports

Qotom Q1900G4-M is a motherboard designed for networking applications thanks to four Gigabit Ethernet ports connected to an Intel Celeron J1900 quad core “Bay Trail” processor. The board supports up to 8GB DDR3 RAM via a SO-DIMM slot, storage through a SATA port and an mSATA connector, and WiFi or cellular connectivity through a mini PCIe slot and SIM card slot. Qotom Q1900G4-M board specifications: SoC – Intel Celeron J1900 quad core “Bay Trail” processor @ 2.0 GHz / 2.41 GHz (Burst) with Intel HD graphics (10W TDP) System Memory – 1x SO-DIMM sockets for up to 8GB DDR3 memory Storage – 1x SATA 3.0 port + power (14 & 15), 1x mini PCIe connector for mSATA SSD (16) Video Output – VGA (5) Connectivity 4x Gigabit Ethernet ports (3) with Wake-on-LAN support SIM card socket (17) USB only mini PCIe connector for WiFi, 3G or 4G (18) USB – 3x […]

November 7, 2016 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Portwell Nano-6062 Nano-ITX Apollo Lake Board is Powered by Intel Atom E3900 Series Processors

We’ve seen a series of announcements of Intel Apollo Lake based boards and modules in the last couple of weeks, with community boards such as UP Squared to ASRock IMB-157 mini-ITX board, and industrial system-on-modules and carrier boards such as the ones offered by Congatec, Seco, and Adlinktech. One more embedded systems company has now unveiled their Apollo Lake solutions with Portwell Nano-6062 Nano-ITX motherboard powered by Intel Atom E3900 “Apollo Lake” SoCs. Portwell Nano-6062 Nano-ITX board support either of the new new Apollo Lake SoCs: SoC Intel Atom x5-E3930 dual core processor @ 1.3 / 1.8 GHz with 2MB L2 cache 1MB, 12 EU Intel Gen 9 HD Graphics (6.5W TDP) Intel Atom x5-E3940 quad core processor @ 1.6 / 1.8 GHz with 2MB L2 cache, 12 EU Intel Gen 9 HD Graphics (9W TDP) Intel Atom x7-E3950 quad core processor @ 1.6 / 2.0 GHz with 2MB L2 […]

March 31, 2015 by Jean-Luc Aufranc (CNXSoft) - No Comments

Baseball Nano-ITX i.MX6 Board Targets Secure Industrial M2M and IoT Products

Calao Systems has introduced a new Freescale i.MX6 single board computer with Baseball embedded platform, targetting network-connected industrial M2M and Internet of Things (IoT) applications requiring a high-level of security achieved with an FIPS 140-2 trusted platform module, and Crypto Authentication chip. The board is comprised of a Nano-ITX based board and a Freescale.iMX6 (Solo, Dual or Quad) SMARC 1.1 module with the following combined specifications: SoC – Freescale iMX6 Solo, Dual or Quad Cortex A9 processor @ up to 1GHz with Vivante GPU System Memory – 2 GB DDR3L, Storage On Module: 8 GB e-MMC, 8 MB SPI Flash, 1x EEPROM with unique S/N and MAC address On Baseboard: 1x Micro-SD socket, 1x Industrial Grade eMMC NANDrive (optional), 1x Industrial Grade SATA Nandrive (optional), Video Output – HDMI Audio Output – HDMI and optical S/PDIF Connectivity – 2x Gigabit Ethernet, 1x SIM card slot USB – 3x USB 2.0 […]

March 19, 2013 by Jean-Luc Aufranc (CNXSoft) - No Comments

iWave Systems Launches RainboW-G12M-Q7 SoMs Powered by TI Sitara AM389x/DM816x Processor

iWave Systems, an embedded systems company based in Bangalore, India, has unveiled new Qseven Modules powered by Texas Instruments Sitara AM389x/DM816x ARM Cortex-A8 microprocessor clocked up to 1.5 GHz. Rainbow-G12M-Q7 modules target applications such as Single-Board computers, network and communication processing, industrial automation, human machine interface (HMI), medical electronic devices, video surveillance systems and interactive Point-of-Service (PoS) kiosks. Here are the modules specifications: CPU – TI AM389x/DM8168 ARM Cortex-A8 based Sitara Processor operating up to 1.5 GHz Memory: 1GB DDR3 SDRAM 128 MB NAND Flash On-Board Micro SD slot 230-pin Qseven Edge Connector: 1x PCIe v2.0 1x HDMI 1.3 2x SATA LVDS channel 1 x USB 2.0 Host | 1x USB 2.0 device I2S Port SD/SDIO SPI & I2C ports Expansion Connector: Gigabit Ethernet HD Video IN/OUT Ports Analog Video OUT Audio IN/OUT ports UART, GPIOs Form factor – Qseven R1.20 compatible (70mm x 70mm) Temperature Range – 0 to […]
