WisGate Connect Raspberry Pi CM4 gateway supports 2.5GbE, WiFi 6, BLE, LoRaWAN, 4G, 5G, and more

Wisgate Connect

RAKwireless has just introduced the WisGate Connect gateway based on Raspberry Pi CM4 system-on-module with support for Gigabit and 2.5Gbps Ethernet plus various optional wireless connectivity option that can be added through Mini PCIe or M.2 sockets as well as expansion through WisBlock IO connectors. Wireless options include LoRaWAN, 4G LTE, 5G, WiFi 6, Zigbee, WiFi HaLoW, and more, while WisBlock modules enable features such as methane sensor, motor current sensor, temperature sensor, pressure control, and valve control among many others. WisGate Connect (RAK7391) specifications: SoM – Raspberry Pi CM4 with Broadcom BCM2711 quad-core Cortex-A72 processor @ 1.5GHz, 1 to 8Gb DDR4, optional 8 to 32GB eMMC flash, optional WiFi 5 and Bluetooth 5.0 LE Storage – MicroSD card socket for CM4 Lite modules only Video Output – HDMI 2.0 up to 4Kp60, 22-pin MIPI DSI connector Camera I/F – 2x 22-pin MIPI CSI connectors Networking Wired – Gigabit Ethernet […]

RAKwireless introduces WisBlock modular power supply, IP65 enclosures, and more sensor modules

Wisblock power modules

RAKwireless Wisblock modular IoT prototyping system will get new modules about once every quarter and the latest Wisblock Summer 2022 event brings some RAK190xx base boards and power modules to support various power sources from solar panels to PoE, two IP65-rated “Unify” enclosures, as well as four new Wisblock sensor modules. Wisblock RAK190XX base boards and power modules The company has launched three base boards designed to take one of the five Wisblock power modules: RAK19009 – A small (47×30 mm) base board with only 2 sensor slots. RAK19010  – The “standard” base board with 4 sensor slots and 1 I/O slot RAK19011 – Version of the Dual IO base board with a power slot RAK19012 – WisBlock power module with USB, battery, and solar panel supply RAK19013 – WisBlock power module for rechargeable batteries and solar panel supply without the USB, for applications where you do not want to […]

Arduino “launches” WisGate Edge LoRaWAN gateways in collaboration with RAKwireless

Arduino LoRaWAN Gateways

Arduino was already involved in LoRaWAN with its MKR WAN 1300 board, but now the company has started offering Arduino-branded Wisgate Edge Pro and Wisgate Edge Lite 2 LoRaWAN gateways for respectively outdoor and indoor environments as part of the Arduino Pro family. If the names of the gateways seem familiar, it’s because Arduino collaborated with Rakwireless, and is simply using their existing LoRaWAN gateways. As I understand it RAKwireless will provide the hardware and technical support, while Arduino will sell the gateways and other LoRaWAN hardware through its existing customer base, more acting as a distributor. Arduino WisGate Edge Lite 2 indoor gateway specifications: SoC – MediaTek MT7628 MIPS processor @ 580 MHz System Memory – 128MB DDR2 Storage OS on flash SD card for setup and diagnostics, backup, and data logging Connectivity 10/100M Ethernet RJ45 port 2.4 WiFi (802.11b/g/n) with -95 dBm RX sensitivity, 20dBm Tx power; internal […]

How to use a ToF laser ranging sensor with Arduino and Wisblock

RAK12014 ToF module Wisblock

Laser ranging has many applications in production and life, such as ranging, positioning, obstacle avoidance, and so on. Time-of-Flight (ToF) ranging, as a type of laser ranging technology, is often used for real-time object detection in robots, autonomous vehicles, and traffic management because of its accuracy, fast response, and low power consumption. The face detection function of mobile phones also uses this technology. This article will introduce the WisBlock RAK12014 ToF laser ranging sensor module, and use the WisBlock development board to demonstrate how the module works. What is a ToF laser ranging sensor module? A ToF laser ranging sensor module uses laser pulses to measure the distance between itself and a target object. The WisBlock RAK12014 ToF laser ranging sensor module is based on STMicro VL53L0X, the smallest ToF ranging sensor in the world. The WisBlock RAK12014 provides accurate distance measurement and can measure distances up to 2 meters. […]

RAKwireless adds more Wisduo and Wisblock modules, launches WisToolBox configuration tool for IoT devices

RAK3172-SIP and RAK4630 Wisduo modules

RAKwireless have launched several Wisduo wireless modules, a dozen of Wisblock modules for IoT prototyping, updated WisDM, WisGateOS, and RUI3 software, and introduced WisToolBox mobile/desktop configuration tool for IoT devices as part of their spring launch 2022 even entitled “Empowering the Innovators: Making IoT your own”. Three new Wisduo modules RAK3172-SIP WisDuo SIP based on STM32WLE5 Wireless SoC with LoRa connectivity. Compared to the original RAK3172, it offers more IO pins, integrates a TCXO, and comes in a smaller size. The module supports LoRa P2P and complies with Class A, B, & C of LoRaWAN 1.0.3 specifications. Cost: $5.99. WisDuo RAK3272-SiP – That’s a breakout board for the RAK3172-SiP System-in-a-Package module for LoRaWAN and allows easy access to all pins via 2.54mm pitch headers. RAK4630 WisDuo Stamp Module – This module supports both LoRa/LoRaWAN and BLE 5.0, and comes with RUI V3 (RUI3) firmware. It can be deployed as an […]

RAKwireless introduces 16 new WisBlock modules with LoRaWAN, NFC reader, etc…

Wisblock LoRaWAN & NFC Reader wireless modules

RAKwireless will add new modules to its WisBlock IoT modular system every quarter. Last July, WisBlock family welcomed 14 new modules, and in September 2021, RAK11310 Raspberry Pi RP2040 LoRaWAN core was introduced together with a new baseboard and various sensor modules. This time around, the company launched 16 new Wisblock modules with two wireless modules, one adding LoRaWAN to an ESP32 core module, the other acting as an RFID and NFC card reader, as well as six sensor modules, and eight “interface” modules ranging from barcode scanners to keypads. WisBlock Wireless modules RAK13300 WisBlock LPWAN module based on Semtech SX1262 transceiver extends the communication abilities of the RAK11200 ESP32 WiFi & Bluetooth LE module with LoRa / LoRaWAN. RAK13600 WisBlock NFC Reader enables reading and writing of NFC tags like RFID cards and other NFC enabled devices using NXP PN532 chip. WisBlock Sensor modules RAK12013 WisBlock Radar Sensor – […]

Giveaway Week 2021 winners announced!

Giveaway Week 2021 winners

Giveaway Week 2021 is now over, and I’m ready to announce the winners. This year, CNX Software was joined by Rakwireless and Shenzhen Xunlong Software, as I did not have enough hardware to send out. I also had planned to give away Crowbits Master Kit, but when I realized the ESP32 module had a battery, I would have had to ask $100 just for shipping, plus having the risk of messing things up, since I’ve never sent devices with batteries with the new regulations. Nevertheless, the void was filled thanks to the generosity of Rakwireless who offered a solar-powered LoRa GPS tracker, and Shenzhen Xunlong Software who proposed an Orange Pi R1 SBC with a plastic enclosure. Let’s go through the list of winners located in four continents with Europe, North America, Asia, and Oceania represented: NanoPi R2S gateway – Jason, CANADA WisBlock Kit 2 LoRa-based GPS Tracker with Solar […]

RAK introduces Raspberry Pi RP2040 based LoRaWAN core, more Wisblock modules

RAKwireless has just launched the RAK11310 WisBlock LPWAN Module with Raspberry Pi RP2040 MCU and LoRaWAN connectivity, as announced after launching 14 new WisBlock modules for IoT prototyping last July. The RAK11310 module was introduced as part of the “Just Track It RAK Autumn Launch 2021” event together with the smallest WisBlock Base Board so far, as well as 11 new Wisblock modules which bring the total to 47 modules. RAK11310 – Raspberry Pi RP2040, LoRaWAN connectivity RAK11310 specifications: RAK11300 WisDuo LPWAN Module MCU – Raspberry Pi RP2040 dual-core Cortex-M0+ microcontroller @ 133MHz with 246 kB RAM LoRa connectivity SX1262 LoRa transceiver Worldwide frequency coverage RAK11310L – EU433, CN470 RAK11310 – EU868, US915, AU915, KR920, AS923, IN865, RU865 LoRaWAN 1.0.2 protocol stack (supports Class A & C) I/O ports – UART, I2C, GPIO, USB through a “Wisconnector” Debugging – Serial Wire Debug (SWD) interface Supply Voltage – 2.0 V ~ […]
