Orange Pi OS – An Android-based desktop OS with Windows 11’s look and feel

Orange Pi OS Android Windows 11 interface

The manufacturer of Orange Pi boards, Shenzhen Xunlong Software, has formally announced the release of Orange Pi OS based on Android with a Windows 11-styled desktop that we are told can also be switched to macOS look and feel, and offering features typically found in desktop operating systems such as multi-window support. I understand the current release of the operating system works on Orange Pi 800 keyboard PC and the Orange Pi 5 SBC should also be supported once soon. We’re told Orange Pi OS is based on Android 12, but that may be an error since I’m not aware of an Android 12 SDK for the Rockchip RK3399 processor. The company plans to release an Arch Linux Arm version named Orange Pi OS (Arch) as well as an Open Harmony variant called Orange Pi OS (OH) next year. Orange Pi OS highlights: Design similar to Windows 11 with a […]

Orange Pi 4 SBC gets 10.1-inch LCD touchscreen

Orange Pi 4 LCD touchscreen

Shenzhen Xunlong Software has released a 10.1-inch LCD touchscreen for the company’s Orange Pi 4 single board computer powered by a Rockchip RK3399 hexa-core Cortex-A72/A53 processor. The MIPI DSI display is based on Ilitek ILI9881c panel controller supported in mainline Linux, offers 1280×800 resolution, and besides working with the original Orange Pi 4, it’s also compatible with Orange Pi 4B (with AI accelerator) and the more recent Orange Pi 4 LTS SBC launched earlier this year. 10.1-inch LCD touchscreen specifications: Display Controller – Ilitek ILI9881C (See PDF datasheet) 10.1-inch panel size 1280×800 resolution @ up to 60Hz, with 16.7 million colors Luminance – 250 cd/m2 (or nit) Backlight – 27x white LEDs Brightness control with PWM 10-point multi touchscreen Host interface – MIPI DSI Dimensions Active area – 216.58 x 135.36 mm Outline dimensions – 228.6 x 143 x 2.7 mm Weight – TBD Temperature Range – Operating – 0 […]

$55+ Orange Pi 4 LTS SBC features YT8531C Ethernet PHY, CDW 20U5622-00 wireless module

Orange Pi 4G LTS

Orange Pi 4 LTS is a cost-optimized (and availability-optimized) variant of the Rockchip RK3399 powered Orange Pi 4 single board computer that was introduced in 2019 with 4GB RAM for $49.90 and up. Shenzhen Xunlong Software mainly kept the same design with the cost savings involving a choice of 3GB or 4GB RAM, and the replacement of Realtek Ethernet PHY and Ampak wireless module with the equivalent MotorComm YT8531C Ethernet chip and CdTech wireless module with WiFi and Bluetooth 5.0 connectivity. Orange Pi 4 LTS specifications with changes highlighted in bold: SoC – Rockchip K3399 hexa-core big.LITTLE processor with two Arm Cortex A72 cores @ up to 1.8 GHz, four Cortex A53 cores, and an ARM Mali-T860 MP4 GPU System Memory – 3GB or 4GB LPDDR4 Storage – MicroSD card socket, optional 16 GB eMMC flash Video Output/Display Interface HDMI 2.0 up to 4K @ 60 Hz LCD connector for […]

$35 Orange Pi 3 LTS SBC comes with 2GB RAM, 8GB flash, AW859A WiFi 5 and Bluetooth 5.0 module

Orange Pi 3 LTS

Orange Pi 3 LTS is a cost-down, more compact version of Orange Pi 3 SBC launched in 2019 with Allwinner H6 quad-core Cortex-A53 processor, Gigabit Ethernet, four USB 3.0 ports, and mPCIe socket with a PCIe x1 Gen2 lane. AFAICR, the latter never really worked well due to a botched implementation in the SoC. The new slimmed-down Orange Pi 3 LTS is sized like a business card, loses the mostly useless mPCIe socket from the original board, comes with 2GB LPDDR3 RAM (no more 1GB RAM option),  a lower number of USB ports, USB Type-C power input, and an Allwinner AW859A WiFi and Bluetooth module replaces the Ampak AP6256 module from the original board. Orange Pi 3 LTS specifications: SoC – Allwinner H6 quad-core Cortex A53 processor clocked at up to 1.8 GHz with Arm Mali-T720MP2 GPU supporting OpenGL ES 3.1/3.0/2.0/1.1, DirectX 11 System Memory – 2GB LPDDR3 (before 1GB […]

Orange Pi R1 Plus LTS is a cheaper dual GbE SBC with YT8531C Ethernet transceiver

Rockchip RK3328 dual GbE SBC YT8531C PHY

It’s been a while since Shenzhen Xunlong Software released a new Orange Pi board. But the wait is over… sort of, as Orange Pi R1 Plus LTS is a low-cost version of Orange Pi R1 Plus SBC that replaced the Realtek RTL8211E PHY with a YT8531C Ethernet PHY that offers the exact same features but at a lower price. That means the new single board computer is still designed for headless operation, for example  a router or firewall, with a Rockchip RK3328 processor, 1GB RAM, dual Gigabit Ethernet, and a USB 2.0 port. Orange Pi R1 Plus LTS specifications: SoC – Rockchip RK3328 quad-core Cortex-A53 @ 1.5 GHz with Arm Mali-450MP2 System Memory – 1GB LPDDR3 RAM Storage – MicroSD card slot, 16 MB SPI flash Connectivity – 2x Gigabit Ethernet via YT8531C Ethernet PHY and RTL8153B USB 3.0 to Ethernet chip USB – 1x USB 2.0 port, 1x USB-C OTG […]

Giveaway Week 2021 winners announced!

Giveaway Week 2021 winners

Giveaway Week 2021 is now over, and I’m ready to announce the winners. This year, CNX Software was joined by Rakwireless and Shenzhen Xunlong Software, as I did not have enough hardware to send out. I also had planned to give away Crowbits Master Kit, but when I realized the ESP32 module had a battery, I would have had to ask $100 just for shipping, plus having the risk of messing things up, since I’ve never sent devices with batteries with the new regulations. Nevertheless, the void was filled thanks to the generosity of Rakwireless who offered a solar-powered LoRa GPS tracker, and Shenzhen Xunlong Software who proposed an Orange Pi R1 SBC with a plastic enclosure. Let’s go through the list of winners located in four continents with Europe, North America, Asia, and Oceania represented: NanoPi R2S gateway – Jason, CANADA WisBlock Kit 2 LoRa-based GPS Tracker with Solar […]

Giveaway Week – Orange Pi R1S Kit

Orange Pi R1 Plus Black ABS Case

Day 4 of giveaway week will be another product sent directly from the manufacturer, as Shenzhen Xunlong Software agreed to send an Orange Pi R1 Plus kit for free to a randomly selected winner. Just like the FriendlyELEC’s NanoPi R2S we’ve offered earlier this week, Orange Pi R1 Plus comes with a Rockchip RK3328 processor and dual Gigabit Ethernet, as well as 1GB RAM.  The kit also includes a plastic enclosure. While I did not have the opportunity to test the board myself, James Dawson did, and found both Ethernet ports to achieve close to Gigabit Ethernet speed, with the processor delivering decent performance.  Software-size, Shenzhen Xunlong Software provides Ubuntu, Debian, OpenWrt, and even Android images on the resources page, but some people also managed to run the Armbian image for NanoPi R2S or RockPi E boards. To enter the draw simply leave a comment with your country and whatever […]

Orange Pi R1 Plus router SBC features Rockchip RK3328, Dual GbE

Orange Pi R1 Plus

FriendlyELEC NanoPi R2S SBC for headless applications with Rockchip RK3328 processor and dual Gigabit Ethernet ports is getting some competition, as with Orange Pi R1 Plus board, Shenzhen Xunlong Software has updated its Orange Pi R1 board powered by an Allwinner H2+ to RK3328 processor coupled with 1GB RAM, and offering dual Gigabit Ethernet ports, plus one USB port for router applications. Orange Pi R1 Plus board specifications with highlights in bold or stricken through showing differences against R1 board: SoC –Rockchip RK3328 quad-core Cortex-A53 @ 1.5 GHz with Arm Mali-450MP2 System Memory – 1GB DDR4 RAM Storage – MicroSD card slot, 16 MB SPI flash Connectivity – 2x Gigabit Ethernet via RTL8211E transceiver and RTL8153B USB 3.0 to Ethernet chip + 802.11 b/g/n WiFi (Realtek RTL8189ETV) with u.FL antenna connector and external antenna USB – 1x USB 2.0 port, 1x USB-C OTG port Expansion headers Unpopulated 26-pin “Raspberry Pi […]
