Kontron Unveils SMARC Starterkit for ARM Systems-on-Module

You may have previously heard about ULP-COM (Ultra Low Power CoM), a standard for systems and computers on module. The standard has been ratified by the Standardization Group for Embedded Technologies (SGET) in February 2013, and renamed to SMARC (Smart Mobility ARChitecture). This standard is specifically designed for low power designed, and is currently only used with ARM SoC. Kontron was involved in the design of this standard, released several ULP-COM, now SMARC, compatible CoM based on TI, Freescale and Nvidia SoC, and yesterday the company just announced SMARC Starterkit will all hardware and software components needed to get started with evaluation and development. This starter kit comes in a carrying case with the following items: SMARC Evaluation Carrier Board 7″ Display PM070W4 (WVGA – 800×480) Touch USB Kit ETP04USBR Mounting Kit Adapter and Cables: 1x Kontron LVDS Jili30 Adapter incl. cable 1x DSUB9 1x micro USB USB A Storage […]

Rhombus Tech EOMA-68 CPU Card Prototype

Do you remember Rhombus Tech AllWinner A10 EOMA-PCMCIA CPU card that targets a BOM cost of $15 US, that was announced at the end of last year? Well, after much wait, the first prototype is now available. This CPU module is based on AllWinner A10 Cortex A8 processor, with 1GB RAM, a NAND Flash, one USB OTG port, microSD slot, HDMI, PMIC, an Ethernet PHY (at the back), an expansion header, and the EOMA-68 connector giving access to peripherals signals (SATA, Ethernet, RGB/TTL, I2C etc…). It can act as a Linux/Android stand-alone computer or be connected to a baseboard. One of the first project will be a laptop for the Chinese market. AllWinner A10 SoC may be a little underpowered to be used in laptop compared to the latest ARM processors, but since EOMA-PCMCIA is a standard, pin-to-pin compatible modules will eventually be designed and manufactured with different/faster (ARM) processors. […]

Kontron Unveils ULP-COM-sA3874i Module Powered by TI Sitara AM3874

Kontron introduced ULP-COM-sA3874i, another family of computer-on-module based on ULP-COM standards, based on Texas Instruments Sitara AM3874 Cortex A8 processors that aims to drive down system costs for ultra-low power SFF (small form factor) solutions in military, industrial automation/HMI, digital signage and medical markets. Here are the technical specifications of this module family: CPU – Texas Instruments Sitara AM3874 Cortex A8 @ 800 MHz Main Memory – On-board 1 or 2 GB DDR3 depending on model. Flash – Onboard Up to 32GB NAND FLASH build option Graphics – Single Channel 18bit,24bit (18bit compatible) LVDS, and HDMI with dual independent displays support. Ethernet – 10/100/1000 MBit Ethernet USB – 2x USB 2.0, USB OTG SATA – 1x SATA Interface Interfaces – GPIO, I²C, 4x I²S, 2x CAN, 2x SPI, 4x UART Camera input – 10bit parallel interface PCI Express / PCI support – 1x PCI Express x1 Lanes Power Supply – […]

Kontron ULP-COM-sAMX6i – Freescale i.MX6 Solo, Dual and Quad Computers on Module

Freescale i.MX6 series was first announced in January 2011, and there have been delays due to problem with the silicon, but now the i.MX6 processors are finally in mass production, and lots of different products are using this SoC. The latest product I found is ULP-COM-sAMX6i by Kontron which is a series of computers on module based on ULP-COM (Ultra Low Power) standard featuring Freescale i.MX6 solo, dual and quad processors. Those commercial and industrial grade modules target markets such as transportation, medical and military. Here are the technical specifications of the modules: CPU – Freescale i.MX 6 Single, Dual and Quad Core ARM Cortex-A9 @ 800 MHz (Industrial grade), 1 GHz and 1.2 GHz System Memory – Up to 2 GB DDR3 Storage – Optional onBoard NAND/eMMC up to 64GB Graphics / Video – Dual Display, HD 1080p Decode/Encode and 2D/3D acceleration Video Output Resolution Parallel LCD 18/24 bit […]
