DM&P Vortex86EX2 Dual Core Processor Targets Dual OS Systems, Support ISA & PCI Interfaces

Most people will probably think about Intel and AMD when asked about x86 processors, at least those who understand the question… But there are also other companies such as Zhaoxin (based on VIA Technologies designs) and DM&P. Last time I wrote about the latter was in 2015 with the introduction of DM&P Vortex86DX3 dual-core x86 SoC for embedded systems and the corresponding evaluation board. The company is still making new x86 processors, and I’ve just been information the company unveiled Vortex86EX2 dual-core processor last year with master and slave cores suitable for running two operating systems at the same time without the need for virtualization, nor hypervisor. The new processor still supports ISA & PCI interfaces for legacy expansion cards and targets real-time industrial or automation applications. DM&P Vortex86EX2 specifications: Processor Cores Master @ 600MHz max with Build-in FPU L1/L2 Cache for user interface Slave @ 400MHz max with Build-in FPU, L1 Cache for real-time control GPU – N/A, external […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

August 2, 2018 by Jean-Luc Aufranc (CNXSoft) - No Comments

Lanner NVA-3000 Machine Vision Computer is Equipped with 8 PoE+ Ports

Lanner Electronics, a company headquartered in Taiwan, and specializing in network appliances and rugged industrial computers, has recently introduced NVA-3000 embedded computer powered by Intel Pentium N4200 or Atom x7-E3950 “Apollo Lake” processor, and targeting video surveillance & machine vision applications with 8 PoE+ ports. Lanner NVA-3000 specifications: SoC Model NVA-3000A – Intel Pentium N4200 quad core Apollo Lake processor @ 1.10 / 2.50 Hz with 18 EU Intel HD graphics 505; 6W TDP Model NVA-3000B – Intel Atom x7-E3950 quad core Apollo Lake processor @ 1.60 / 2.00 GHz with 18 EU Intel HD graphics 505; 12W TDP System Memory – 4GB LPDDR4 2400MHz via 1x SO-DIMM slot Storage 32Mbit SPI Flash for BIOS, 2x SATA ports, 1x 3.5″ SATA/SSD drive bay, eMMC flash Model NVA-3000A – 8GB capacity Model NVA-3000B – 64GB capacity Network Connectivity Ethernet controller – Intel I210IT, I210IS, Marvell 88E6390 Ethernet Switch, 88E1512 PHY 2x Gigabit Ethernet (RJ45) + 8x RJ45 PoE+ ports USB – […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

March 12, 2018March 12, 2018 by Jean-Luc Aufranc (CNXSoft) - No Comments

Diamond Systems Zeta is a Miniature SBC Based on Bay Trail/Apollo Lake COM Express Mini Modules

Diamond Systems, a Silicon valley based company providing embedded computing solutions for transportation, energy, aerospace, defense, manufacturing, medical and research market, has recently introduced Zeta single board computer comprised of a baseboard, a choice of COM Express Mini type 10 modules based on Intel Bay Trail or Apollo Lake processor, and a heatspreader for cooling. The company explains the small size and high feature density of the solution make it particularly suitable for mobile applications. The SBC also supports a wide range 6-36VDC input voltage, and works in -40 to +85°C temperature range. Zeta SBC specifications: COM’s Processor and System Memory Intel Atom Bay Trail E3825 dual core processor @ 1.33GHz with 2GB RAM Intel Atom Apollo Lake E3940 quad core processor @ 1.6GHz with 4GB RAM Intel Pentium Apollo Lake N4200 quad core processor @ 1.1GHz (burstable to 2.5GHz) with 8GB RAM Storage – 1x mSATA socket , 1x micro SD card socket Video Output – VGA header, LVDS […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

August 11, 2016August 13, 2016 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

VersaLogic Osprey is an Industrial & Military Grade Intel Bay Trail Single Board Computer

Versalogic Osprey “Embedded Processing Unit” (EPU) is a single board computer powered by Intel Bay Trail-I CPU modules with 2 to 4GB RAM, up to 8GB flash, dual Gigabit Ethernet, two mini PCIe slots, working at industrial temperatures (-40 to 85°C), and compliant with MIL-STD-202G military standard for shocks and vibrations. VersaLogic Osprey VL-EPU-3311 specifications: SoC Intel Atom E3845 quad core processor @ 1.91GHz with Intel HD graphics or Intel Atom E3827 dual core processor @ 1.75GHz with Intel HD graphics or Intel Atom E3815 single core processor @ 1.46GHz with Intel HD graphics System Memory – 2GB or 4GB DDR3L (soldered) Storage 8GB eMMC flash with E3845 model; 4GB eMMC flash with E3827 model; no flash for E3815 model MicroSD slot SATA 2.0 port with latching connector mSATA via mini-PCIe slot Display Single-channel 18/24-bit LVDS up to 1024×768 @ 60Hz Dual mini-DisplayPort++ with HDMI and audio support up to 2560×1600 Connectivity – 2x Gigabit Ethernet ports with latching connector, […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

May 30, 2016May 30, 2016 by Jean-Luc Aufranc (CNXSoft) - No Comments

Axiomtek NA343R 1U Rackmount Network Appliance is Powered by an Intel Celeron N3160 Braswell Processor

Many Braswell mini PCs have been launched in the last year, and usually we’d see 1U rack used by processor specifically designed for server such as Intel Xeon or Atom Avoton, but thanks to Axiomtek NA343R , we’ve not got a 1U rackmount server powered by Intel Celeron N3160 processor part of the Braswell family. Axiomtek NA343R rack server system specifications: SoC – Intel Celeron N3160 quad-core processor @ 1.6 GHz / 2.24 GHz (Burst frequency) with Intel HD graphics 400 with 12EU (4W SDP / 6W TDP) System Memory – 1x SO-DIMM DDR3L-1600 for up to 8GB RAM Storage – 1x CFast, 1x 2.5″ SATA HDD. optional 3.5″ SATA HDD Video Output – Optional VGA port Connectivity – 6x Gigabit Ethernet via Intel i211 Ethernet controller, one group of LAN bypass function. USB – 2x USB 3.0 ports Misc – Power switch, status LEDs, 1x RJ45 console port, watchdog timer,two fans Power Supply – Open frame 65W Operating Temperature […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

March 11, 2016 by Jean-Luc Aufranc (CNXSoft) - No Comments

Axiomtek ICO310 Din-rail Industrial IoT Gateway Supports Power over Ethernet (PoE)

Axiomtek ICO310 is a din-rail IIoT (Industrial IoT) embedded platform powered by Intel Celeron Braswell processors supporting up to 8GB RAM, PoE, and featuring two Gigabit LAN ports, RS-232/422/485 ports, USB 2.0 & USB 3.0 ports, one VGA port, and one DIO interface. It also support mSATA and SATA drives, and wireless module via mPCIe interfaces. Target applications include smart energy, smart factory automation, facility monitoring systems and more. Axiomtek ICO310 Specifications: SoC Intel Celeron N3060 dual core processor @ 1.6GHz / 2.48 GHz (Turbo) with Intel HD graphics 400 with 12EU @ 320/600 MHz OR Intel Celeron N3160 quad core processor @ 1.6GHz / 2.24 GHz (Turbo) with Intel HD graphics 400 with 12EU @ 320/640 MHz System Memory – 204-pin SO-DIMM DDR3L-1600 socket up to 8 GB Storage – 1 x mSATA, 1x SATA SSD (or HDD) Video Output – VGA Connectivity 2x 10/100/1000Mbps Ethernet, including 1x PoE PD compliant with 802.3at standard (LAN 1) 2x full size mini […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

February 26, 2016 by Jean-Luc Aufranc (CNXSoft) - No Comments

Intel Celeron N3060 based Industrial Fanless Touch Panel Computer Supports SATA Drives

Axiomtek GOT5103W-845 is a new IP65 industrial touch panel PC with a 10.1″ display, an Intel Celeron N3060 dual core processor, up to 8GB RAM, dual Gigabit Ethernet, USB 3.0, and support for half-slim SATA and mSATA SSD drives. Specifications: SoC – Intel Celeron N3060 dual core processor @ 1.6GHz / 2.48 GHz (Turbo) with Intel HD graphics 400 with 12EU @ 320/600 MHz System Memory – 1 x 204-pin SO-DIMM DDR3L-1600 up to 8 GB Storage – 1x mSATA, 1x optional half-slim SATA SSD Display – 10.1″ WXGA TFT LCD with LED and projected capacitive touch screen; 350 nits; 1280 x 800 resolution Video Output – 1x HDMI port Audio – 1x Line Out, HDMI, 2x speakers Connectivity – 2x 10/100/1000Mbps (Intel i211AT), optional WLAN antenna USB – 2x USB 2.0, 2 x USB 3.0 COM ports – 1 x RS-232; 1 x RS-232/422/485 Expansion for storage, Wifi, GPRS/GSM, or 3G/4G 1x Full-size PCI Express Mini Card with mSATA […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

February 16, 2016February 16, 2016 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

DAB Embedded OpenWrt Router Board Combines Atmel SAMA5D3 SoC and Altera MAX 10 FPGA

DAB Embedded, a Belgian engineering company specialized in research and development of electronic products, has designed DAB-OWT-SAM5 router board powered by Atmel SAMA5D36 Cortex-A5 processor and Altera MAX 10 FPGA, which runs OpenWrt or Windows Embedded Compact 7, and targets IoT applications. DAB-OWT-SAM5 board specifications: SoC – Atmel SAMA5D36 ARM Cortex-A5 processor @ 536MHz with Floating-Point Unit. FPGA – Altera MAX 10 FPGA with integrated ADC (Exact part number not disclosed) System Memory – Up to 512MB DDR2 Storage – Up to 2GB NAND flash, 1Mbit SPI flash, micro SD slot Connectivity – 2x Fast Ethernet ports, 802.11 b/g/n WiFi (Direct, station mode, and soft-AP) via Atmel ATWILC1000B module Display Interface – LVDS connected to FPGA USB – 1x USB 2.0 host, 1x USB 2.0 device Expansion Connectors Wired interfaces – RS232, CAN 2.0 A/B, KNX, RS-485/422, etc… Wireless connectivity – Zigbee, Z-Wave, KNX RF, etc… Power Supply – 5V DC power supply, external Li+ battery Dimensions – N/A The company […]
