ARM Based Servers and Servers-on-a-Chip (SoCs) at ARM Techcon 2013

ARM Techcon 2013 took place on October 29 – 31, 2013, in Santa Clara, and several companies announced servers, or chips for server based on ARM technology. None of those are for home used, but for now ARM based servers target enterprise and cloud data. Yet end users may them indirectly when they access social networks such as Facebook, or other online services such as Paypal.

Calxeda ECX-2000 SoC

After their ECX-1000 quad core Cortex A9 Server-on-chip, Calxeda has announced ECX-2000 SoC featuring four Cortex A15 cores. The new SoC provides about twice the performance, 3 times the memory bandwidth, and 4 times the memory capacity (up to 16GB RAM) of the earlier chip.

Calxeda ECX-2000
Calxeda ECX-2000

One of the key advantage of Cortex A15 over Cortex A9 is hardware virtualization that allows support for KVM and Xen hypervisors. ECX-2000 is supported in Canonical Ubuntu Linux 13.10 and can run Havana Openstack.

Other key features include:

  • On-chip Fabric Switch connects SoCs through low-latency 10Gb links
  • On-chip Management Engine provides out-of-band systems management capabilities while simultaneously governing power policies and optimizing network fabric routing
  • Integrated high-performance interfaces such as memory controllers with full ECC support and I/O subsystems for local SATA 2.0 ports and PCIe 2.0 support

ECX-2000 series SoC will be used in efficient data centers, web server farms, mid-tier application servers, content distribution networks, cloud storage, and emerging “Big Data” analytics.

Further information, including a product brief with detailed specs, is available from Calxeda ECX-2000 page. The company is also working on two SoC based on Cortex A57 that will be sampling in Q1 2014 and be mass produced at the end of 2014. One of them will be pin-to-pin compatible with ECX-1000 and ECX-2000, and the other more powerful.

Cavium Demonstration of Project Thunder ARMv8 SoC in Ubuntu 13.10

Cavium_Project_ThunderCavium has recently announced that Cavium’s Thunder ARMv8 processors are supported in Ubuntu 13.10, and both companies hosted private demonstrations of the Ubuntu Server 13.10 running on Cavium’s Thunder software development platform at ARM TechCon 2013. There’s no silicon yet, so this was done in a simulator (the development platform), but Ubuntu 13.10’s ARMv8 developer preview can be accessed now, and developers can start using, developing and testing for Cavium’s Thunder multicore ARMv8 processors before the Silicon is ready.

The company also unveiled that the Thunder developer platform with Ubuntu Server 13.10 will be available in HP’s Moonshot Discovery Lab to offer developers a head-start on porting, developing and testing on future cloud centric servers.

There does not seem to be much information about Project Thunder features and specifications at this time, but it should eventually become available on Project Thunder page.

Dell Microserver powered by Applied Micro XGene ARMv8 SoC

Dell demonstrated a 64-bit ARM server running Fedora 19, and powered by Applied Micro XGene 8-core SoC coupled with Dell Powervault MD1220 attached storage and a PMC SAS/SATA host bus adapter.

A desktop PC stream a movie from the server, and shows usage statistics of the server. You can watch a short demo below.

ARM Servers in Hewlett Packard Moonshot

HP_MoonshotHP had a keynote (About 50 minutes) at ARM Techcon 2013, where Martin Fink, CTO and Director, HP Labs, explained how IT changes over the years, HP solutions, and how ARM based server cartridges used in HP Moonshot can help.

Moonshot platform is composed of low power servers that share management, power, cooling, networking, and storage. Compared to traditional servers, HP claims the platform is capable of consuming up to 89% less energy, takes up to 80% less space, costs 77% less, and is 97% less complex (whatever that means).

There are 3 cartridges based on ARM Technology in HP Discovery Labs:

  • Based on Calxeda EXC-1000 for cloud apps – mobile, social and big Data
  • Based on Texas Instruments Keystone II (ARM Cortex A15 cores + DSPs) for apps such as VoIP, and seismic processing.
  • Based on Applied Micro XGene (8 ARMv8 cores) for 64-bit software support.

Moonshot_Calxeda_TI_Applied_Micro

These ARM based cartridges should be available next year.
