Low-power Alder Lake-N processors coming to Chromebooks, embedded systems

Intel Alder Lake-N processors succeeding Jasper Lake processors are likely to soon show up in Chromebooks and embedded systems with early clues about the features of the upcoming processors found in the source tree of Coreboot and the Sound Open Firmware (SOF) Project.

The person or team at Coelacanth’s dream has been analyzing the commits related to Alder Lake-N and found some interesting information related to the CPU cores, GPU, media capabilities, and peripherals, plus some reference boards by the Google Chromium team.

Intel Alder Lake-N

Their latest update analyzes a partial boot log in the SOF Project and so far we know that:

  • Alder Lake-N is an Atom-only “Gracemont” processor (no hybrid variant like Alder Lake-S desktop processors) with up to 8 threads/8 cores
  • Alder Lake-N has two 4-core clusters that share the L2 cache
  • The new processors should come with Intel UHD Gen12 graphics just like Alder Lake-P/M mobile processors, but limited to 32 EU (Execution Units)
  • LPDRR5 memory support
  • Gen12 Media means support for 8Kp60 VP9, AV1, H.265, and H.264 video decoding, and 8Kp60 encoding
  • PCIe interfaces – None attached to the CPU, up to 5 ports, up to 9 lanes attached to PCH
  • USB – Up to 2x USB interfaces with Type-C support
  • Alder Lake-N Chromebook board is codenamed Nissa with variants named Nivviks, and Nereid.

Coelacanth’s dream says many of the features are similar to Elkhart Lake and Jasper Lake processors, but the Gracemont cores should provide significantly better performance and the latest Intel UHD Gen12 (Intel Xe) graphics should also provide a boost in 3D graphics performance.

While most Alder Lake processors are so-called “hybrid processors” with both performance and efficiency cores, Alder Lake-N will only come with efficiency cores. Since Jasper Lake processors are limited to four cores, and it’s the same story for Elkhart Lake embedded/IoT processors, the new Atom/Pentium/Celeron processor should perform even better in multi-threaded workloads with up to 8 cores.

Since Intel has not unveiled the new processors yet, it may take several months/quarters before those become available in products.

Via Tom’s Hardware

Share this:
FacebookTwitterHacker NewsSlashdotRedditLinkedInPinterestFlipboardMeWeLineEmailShare

Support CNX Software! Donate via cryptocurrencies, become a Patron on Patreon, or purchase goods on Amazon or Aliexpress

ROCK 5 ITX RK3588 mini-ITX motherboard

14 Replies to “Low-power Alder Lake-N processors coming to Chromebooks, embedded systems”

    1. Pretty sure Gen12 == Xe graphics.

      Intel Xe (stylized as Xe and pronounced as two separate letters), earlier known unofficially as Gen12, is a GPU architecture developed by Intel.

      1. Yes, it’s my understanding too. But sometimes Intel will write “Intel Xe” clearly, and others refer to it as “Intel UHD graphics”.

      2. Pretty sure Gen12 = Castrated Xe.
        and Xe itself can be differentiated to: -> Xe basic, Xe standard, Xe top (as of Iris).

        This is Intel, baby! What do you expect 😀

          1. I don’t really know. My guesss is combination between GPU frequency and execution units.

  1. I think intel can say “thank you” to Arm’s fragmentation here, because when you take an x86 chip, almost everything works out of the box, while with Arm SoCs you still have months of development to bring the platform to a usable state. IMHO there’s still a lot of progress to be made there so that Arm works out of the box regardless of the SoC vendor. Their smartphone-only focus at the moment might not be relevant to the laptop market.

      1. RISC-V will be much worse due to extensions and custom instructions. There will be as many incompatible RISC-V implementations at the binary level as there will be vendors. This will remind us some of the MIPS period of glory when you couldn’t move a binary between two machines without seeing a SIGILL or an endianness issue or anything else.

    1. >Arm works out of the box regardless of the SoC vendor.

      The day that happens some of us here are out of jobs…
      Fortunately even though ARM tries to bring in standards to clean this stuff up the vendors apparently don’t care so the current situation will continue for a while to come.

  2. Alder Lake-N is an Atom-only “Gracemont” processor (no hybrid variant like Alder Lake-S desktop processors) with up to 8 threads/8 cores

    No big cores is definitely not what I wanted to see, when Intel has portrayed 1+4 as capable of going down to around 5-10 Watts.

    On the other hand, going to 8 cores is pretty funny. Watch that improve gaming and other multi-threaded tasks. Hopefully dual-core is gone since it would be a waste to disable 75% of the cores, and maybe 6-core SKUs are possible.
