I’ve previously written about Intel’s (relatively) new NUC 9 range of mini PCs and now I am following up with my experiences of having bought one. Whilst I’ll cover some performance metrics from both Windows and Ubuntu I’ll also discuss the benefits and drawbacks of using either OS together with a comparison of gaming, thermals, and power usage as well as a brief look at overclocking potential and implications together with highlighting the issues encountered. NUC9i9QNX Hardware Overview The model I purchased and will be reviewing here is the NUC9i9QNX from Intel’s Ghost Canyon lineup and is formally known as the Intel NUC 9 Extreme Kit – NUC9i9QNX. It contains a “Compute Element” with an i9-9980HK which is an eight-core 16-thread 2.40 GHz processor boosting to 5.00 GHz with Intel’s UHD Graphics 630. The full specifications of the NUC9i9QNX include: The NUC9i9QNX is sold as a kit which essentially means […]

We’ve already reviewed ODYSSEY-X86J4105 SBC with Windows 10. When combined with Re_Computer enclosure it’s a typical Intel Gemini Lake mini PC but with a twist: Arduino and Raspberry Pi header. The latter works fine in Windows, but at the time, the Raspberry Pi header does not. So Linux is our only option. I’ve now had time to install and test Ubuntu 20.04 on ODYSSEY-X86J4105 single board computer. I did not install Ubuntu on the internal eMMC flash where Windows 10 resides, but instead on a 128GB M.2 SATA SSD. I’ll first run some usual command to check system information, then run benchmarks, and check whether all features are working before focusing the review on the Arduino and Raspberry Pi headers. ODYSSEY-X86J4105 Ubuntu 20.04 System Info We can check some of the information from the system in the terminal:

jaufranc@CNX-ODYSSEY:~$ lsb_release -a
No LSB modules are available.
Distributor ID:	Ubuntu
Description:	Ubuntu 20.04.1 LTS
Release:	20.04
Codename:	focal
jaufranc@CNX-ODYSSEY:~$ uname -a
Linux CNX-ODYSSEY 5.4.0-42-generic #46-Ubuntu SMP Fri Jul 10 00:24:02 UTC 2020 x86_64 x86_64 x86_64 GNU/Linux
jaufranc@CNX-ODYSSEY:~$ inxi -Fc0
System:
  Host: CNX-ODYSSEY Kernel: 5.4.0-42-generic x86_64 bits: 64 Console: tty 0
  Distro: Ubuntu 20.04.1 LTS (Focal Fossa)
Machine:
  Type: Desktop Mobo: WeiBu model: WTGLKC1R120
  v: SD-BS-CJ41G-M-101-B 12/09/2019 18:14:02
  serial: <superuser/root required> UEFI: American Megatrends
  v: SD-BS-CJ41G-M-101-B date: 12/09/2019
CPU:
  Topology: Quad Core model: Intel Celeron J4105 bits: 64 type: MCP
  L2 cache: 4096 KiB
  Speed: 998 MHz min/max: 800/2500 MHz Core speeds (MHz): 1: 1013 2: 1069
  3: 1023 4: 1065
Graphics:
  Device-1: Intel UHD Graphics 605 driver: i915 v: kernel
  Display: server: X.org 1.20.8 driver: i915 tty: 80x24
  Message: Advanced graphics data unavailable in console. Try -G --display
Audio:
  Device-1: Intel driver: snd_hda_intel
  Sound Server: ALSA v: k5.4.0-42-generic
Network:
  Device-1: Intel driver: iwlwifi
  IF: wlo2 state: down mac: 24:41:8c:a0:0e:42
  Device-2: Intel I211 Gigabit Network driver: igb
  IF: enp2s0 state: up speed: 1000 Mbps duplex: full mac: 00:e0:4c:01:15:56
  Device-3: Intel I211 Gigabit Network driver: igb
  IF: enp3s0 state: down mac: 00:e0:4c:01:15:57
Drives:
  Local Storage: total: 177.48 GiB used: 7.89 GiB (4.4%)
  ID-1: /dev/mmcblk0 model: DA4064 size: 58.24 GiB
  ID-2: /dev/sda model: MINIX SSD 128GB KHSA186335N size: 119.24 GiB
Partition:
  ID-1: / size: 116.87 GiB used: 7.82 GiB (6.7%) fs: ext4 dev: /dev/sda1
Sensors:
  System Temperatures: cpu: 42.0 C mobo: N/A
  Fan Speeds (RPM): N/A
Info:
  Processes: 207 Uptime: 9m Memory: 7.62 GiB used: 576.2 MiB (7.4%)
  Init: systemd runlevel: 5 Shell: bash inxi: 3.0.38
jaufranc@CNX-ODYSSEY:~$ df -h
Filesystem      Size  Used Avail Use% Mounted on
udev            3.8G     0  3.8G   0% /dev
tmpfs           780M  1.8M  779M   1% /run
/dev/sda1       117G  7.9G  104G   8% /
tmpfs           3.9G     0  3.9G   0% /dev/shm
tmpfs           5.0M  4.0K  5.0M   1% /run/lock
tmpfs           3.9G     0  3.9G   0% /sys/fs/cgroup
/dev/loop1       55M   55M     0 100% /snap/core18/1705
/dev/loop0      241M  241M     0 100% /snap/gnome-3-34-1804/24
/dev/loop2       28M   28M     0 100% /snap/snapd/7264
/dev/loop3       63M   63M     0 100% /snap/gtk-common-themes/1506
/dev/loop4       50M   50M     0 100% /snap/snap-store/433
/dev/mmcblk0p1   96M   76M   21M  79% /boot/efi
tmpfs           780M   24K  780M   1% /run/user/125
tmpfs           780M  8.0K  780M   1% /run/user/1000
jaufranc@CNX-ODYSSEY:~$ lsblk -a
NAME         MAJ:MIN RM   SIZE RO TYPE MOUNTPOINT
loop0          7:0    0 240.8M  1 loop /snap/gnome-3-34-1804/24
loop1          7:1    0    55M  1 loop /snap/core18/1705
loop2          7:2    0  27.1M  1 loop /snap/snapd/7264
loop3          7:3    0  62.1M  1 loop /snap/gtk-common-themes/1506
loop4          7:4    0  49.8M  1 loop /snap/snap-store/433
loop5          7:5    0         0 loop
loop6          7:6    0         0 loop
loop7          7:7    0         0 loop
sda            8:0    0 119.2G  0 disk
└─sda1         8:1    0 119.2G  0 part /
mmcblk0      179:0    0  58.2G  0 disk
├─mmcblk0p1  179:1    0   100M  0 part /boot/efi
├─mmcblk0p2  179:2    0    16M  0 part
├─mmcblk0p3  179:3    0  57.4G  0 part
└─mmcblk0p4  179:4    0   800M  0 part
mmcblk0boot0 179:8    0     4M  1 disk
mmcblk0boot1 179:16   0     4M  1 disk
jaufranc@CNX-ODYSSEY:~$ sudo lshw -C cpu
  *-cpu
       description: CPU
       product: Intel(R) Celeron(R) J4105 CPU @ 1.50GHz
       vendor: Intel Corp.
       physical id: 37
       bus info: cpu@0
       version: Intel(R) Celeron(R) J4105 CPU @ 1.50GHz
       slot: SOCKET 0
       size: 937MHz
       capacity: 2700MHz
       width: 64 bits
       clock: 100MHz
       capabilities: lm fpu fpu_exception wp vme de pse tsc msr pae mce cx8 apic sep mtrr pge mca cmov pat pse36 clflush dts acpi mmx fxsr sse sse2 ss ht tm pbe syscall nx pdpe1gb rdtscp x86-64 constant_tsc art arch_perfmon pebs bts rep_good nopl xtopology nonstop_tsc cpuid aperfmperf tsc_known_freq pni pclmulqdq dtes64 monitor ds_cpl vmx est tm2 ssse3 sdbg cx16 xtpr pdcm sse4_1 sse4_2 x2apic movbe popcnt tsc_deadline_timer aes xsave rdrand lahf_lm 3dnowprefetch cpuid_fault cat_l2 pti cdp_l2 ssbd ibrs ibpb stibp ibrs_enhanced tpr_shadow vnmi flexpriority ept vpid ept_ad fsgsbase tsc_adjust smep erms mpx rdt_a rdseed smap clflushopt intel_pt sha_ni xsaveopt xsavec xgetbv1 xsaves dtherm ida arat pln pts umip rdpid md_clear arch_capabilities cpufreq
       configuration: cores=4 enabledcores=4 threads=4
jaufranc@CNX-ODYSSEY:~$ sudo lshw -C memory
  *-firmware
       description: BIOS
       vendor: American Megatrends Inc.
       physical id: 0
       version: SD-BS-CJ41G-M-101-B
       date: 12/09/2019
       size: 64KiB
       capacity: 4544KiB
       capabilities: pci upgrade shadowing cdboot bootselect socketedrom edd int13floppy1200 int13floppy720 int13floppy2880 int5printscreen int14serial int17printer acpi usb biosbootspecification uefi
  *-memory
       description: System Memory
       physical id: 23
       slot: System board or motherboard
       size: 8GiB
     *-bank:0
          description: DIMM LPDDR4 Synchronous 2133 MHz (0.5 ns)
          product: 123456789012345678
          vendor: ABCD
          physical id: 0
          serial: 1234
          slot: A1_DIMM0
          size: 2GiB
          width: 16 bits
          clock: 2133MHz (0.5ns)
     *-bank:1
          description: DIMM LPDDR4 Synchronous 2133 MHz (0.5 ns)
          product: 123456789012345678
          vendor: ABCD
          physical id: 1
          serial: 1234
          slot: A1_DIMM1
          size: 2GiB
          width: 16 bits
          clock: 2133MHz (0.5ns)
     *-bank:2
          description: DIMM LPDDR4 Synchronous 2133 MHz (0.5 ns)
          product: 123456789012345678
          vendor: ABCD
          physical id: 2
          serial: 1234
          slot: A1_DIMM2
          size: 2GiB
          width: 16 bits
          clock: 2133MHz (0.5ns)
     *-bank:3
          description: DIMM LPDDR4 Synchronous 2133 MHz (0.5 ns)
          product: 123456789012345678
          vendor: ABCD
          physical id: 3
          serial: 1234
          slot: A1_DIMM3
          size: 2GiB
          width: 16 bits
          clock: 2133MHz (0.5ns)
  *-cache:0
       description: L1 cache
       physical id: 35
       slot: CPU Internal L1
       size: 224KiB
       capacity: 224KiB
       capabilities: synchronous internal write-back
       configuration: level=1
  *-cache:1
       description: L2 cache
       physical id: 36
       slot: CPU Internal L2
       size: 4MiB
       capacity: 4MiB
       capabilities: synchronous internal write-back unified
       configuration: level=2
jaufranc@CNX-ODYSSEY:~$ free -mh
              total        used        free      shared  buff/cache   available
Mem:          7.6Gi       493Mi       6.5Gi        42Mi       633Mi       6.9Gi
Swap:         2.0Gi          0B       2.0Gi
jaufranc@CNX-ODYSSEY:~$ sudo lshw -C network
  *-network
       description: Wireless interface
       product: Intel Corporation
       vendor: Intel Corporation
       physical id: c
       bus info: pci@0000:00:0c.0
       logical name: wlo2
       version: 03
       serial: 24:41:8c:a0:0e:42
       width: 64 bits
       clock: 33MHz
       capabilities: pm msi pciexpress msix bus_master cap_list ethernet physical wireless
       configuration: broadcast=yes driver=iwlwifi driverversion=5.4.0-42-generic firmware=46.6bf1df06.0 latency=0 link=no multicast=yes wireless=IEEE 802.11
       resources: irq:44 memory:a1314000-a1317fff
  *-network
       description: Ethernet interface
       product: I211 Gigabit Network Connection
       vendor: Intel Corporation
       physical id: 0
       bus info: pci@0000:02:00.0
       logical name: enp2s0
       version: 03
       serial: 00:e0:4c:01:15:56
       size: 1Gbit/s
       capacity: 1Gbit/s
       width: 32 bits
       clock: 33MHz
       capabilities: pm msi msix pciexpress bus_master cap_list ethernet physical tp 10bt 10bt-fd 100bt 100bt-fd 1000bt-fd autonegotiation
       configuration: autonegotiation=on broadcast=yes driver=igb driverversion=5.6.0-k duplex=full firmware=0. 6-2 ip=192.168.1.13 latency=0 link=yes multicast=yes port=twisted pair speed=1Gbit/s
       resources: irq:22 memory:a1200000-a121ffff ioport:e000(size=32) memory:a1220000-a1223fff
  *-network
       description: Ethernet interface
       product: I211 Gigabit Network Connection
       vendor: Intel Corporation
       physical id: 0
       bus info: pci@0000:03:00.0
       logical name: enp3s0
       version: 03
       serial: 00:e0:4c:01:15:57
       capacity: 1Gbit/s
       width: 32 bits
       clock: 33MHz
       capabilities: pm msi msix pciexpress bus_master cap_list ethernet physical tp 10bt 10bt-fd 100bt 100bt-fd 1000bt-fd autonegotiation
       configuration: autonegotiation=on broadcast=yes driver=igb driverversion=5.6.0-k firmware=0. 6-2 latency=0 link=no multicast=yes port=twisted pair
       resources: irq:23 memory:a1100000-a111ffff ioport:d000(size=32) memory:a1120000-a1123fff
jaufranc@CNX-ODYSSEY:~$ lsusb
Bus 002 Device 001: ID 1d6b:0003 Linux Foundation 3.0 root hub
Bus 001 Device 005: ID 8087:0aaa Intel Corp.
Bus 001 Device 006: ID 2886:800b Seeed Studio Seeeduino Zero
Bus 001 Device 004: ID 0bda:0129 Realtek Semiconductor Corp. RTS5129 Card Reader Controller
Bus 001 Device 003: ID 1a2c:0002 China Resource Semico Co., Ltd USB Keykoard
Bus 001 Device 002: ID 04f2:1718 Chicony Electronics Co., Ltd HP USB Optical Mouse
Bus 001 Device 001: ID 1d6b:0002 Linux Foundation 2.0 root hub
jaufranc@CNX-ODYSSEY:~$ lspci
00:00.0 Host bridge: Intel Corporation Gemini Lake Host Bridge (rev 03)
00:00.1 Signal processing controller: Intel Corporation Celeron/Pentium Silver Processor Dynamic Platform and Thermal Framework Processor Participant (rev 03)
00:02.0 VGA compatible controller: Intel Corporation UHD Graphics 605 (rev 03)
00:0c.0 Network controller: Intel Corporation Device 31dc (rev 03)
00:0e.0 Audio device: Intel Corporation Device 3198 (rev 03)
00:0f.0 Communication controller: Intel Corporation Celeron/Pentium Silver Processor Trusted Execution Engine Interface (rev 03)
00:12.0 SATA controller: Intel Corporation Device 31e3 (rev 03)
00:13.0 PCI bridge: Intel Corporation Gemini Lake PCI Express Root Port (rev f3)
00:14.0 PCI bridge: Intel Corporation Gemini Lake PCI Express Root Port (rev f3)
00:14.1 PCI bridge: Intel Corporation Gemini Lake PCI Express Root Port (rev f3)
00:15.0 USB controller: Intel Corporation Device 31a8 (rev 03)
00:17.0 Signal processing controller: Intel Corporation Device 31b4 (rev 03)
00:17.1 Signal processing controller: Intel Corporation Device 31b6 (rev 03)
00:17.2 Signal processing controller: Intel Corporation Device 31b8 (rev 03)
00:18.0 Signal processing controller: Intel Corporation Celeron/Pentium Silver Processor Serial IO UART Host Controller (rev 03)
00:18.1 Signal processing controller: Intel Corporation Celeron/Pentium Silver Processor Serial IO UART Host Controller (rev 03)
00:18.2 Signal processing controller: Intel Corporation Celeron/Pentium Silver Processor Serial IO UART Host Controller (rev 03)
00:18.3 Signal processing controller: Intel Corporation Celeron/Pentium Silver Processor Serial IO UART Host Controller (rev 03)
00:19.0 Signal processing controller: Intel Corporation Celeron/Pentium Silver Processor Serial IO SPI Host Controller (rev 03)
00:1c.0 SD Host controller: Intel Corporation Celeron/Pentium Silver Processor SDA Standard Compliant SD Host Controller (rev 03)
00:1e.0 SD Host controller: Intel Corporation Device 31d0 (rev 03)
00:1f.0 ISA bridge: Intel Corporation Device 31e8 (rev 03)
00:1f.1 SMBus: Intel Corporation Celeron/Pentium Silver Processor Gaussian Mixture Model (rev 03)
02:00.0 Ethernet controller: Intel Corporation I211 Gigabit Network Connection (rev 03)
03:00.0 Ethernet controller: Intel Corporation I211 Gigabit Network Connection (rev 03)
