$10 Digistump Oak ESP8266EX Board is Arduino Compatible, Connects to the Cloud, and More (Crowdfunding)

A few years ago, I wondered why adding Wi-Fi to Arduino had to be rather expensive ($40+), and why there weren’t any low cost and small form factor Wi-Fi boards for embedded applications. But we’re now in 2015, embedded is “dead” giving rise to IoT, and I’m left wondering how it’s possible to make IoT Wi-Fi modules that cheap, and whether people will ever stop churning out cheap Wi-Fi boards, as I’m flooded with such news weekly… So when I saw yet another ESP8266 board on Kickstarter I was about to dismiss it, but since it was made by Digistump, that has an active community with their other products like DigiSpark Pro or DigiX, I decided to have a closer look. Digistump Oak hardware specifications: MCU – Espressif ESP8266EX 32-bit microprocessor @ 80MHz (overclockable up to 160MHz)  with 1MB ROM (~300KB available for user code), 64KB RAM, 512 bytes EEPROM […]

Crowdfunding Report for 2014 on CNX Software Blog

Following up on my 2013 Crowdfunding Report, I’ve gone through all 55 Kickstarter and Indiegogo crowdunding projects featured on CNX Software between December 2013 and November 2014 (inclusive) to see how well they fared. The table below sort projects chronologically as they were published on this very blog. Date Project Crowdfunding Site Funded? Pledged amount / Goal Expected Delivery Actual Delivery Comments 2. Dec. 2013 Micro Python Kickstarter Yes 97,803 GBP / 15,000 GBP 03/2014 04/2014 Available @ https://micropython.org/store/#/store 5. Dec. 2013 Plugaway Kickstarter Yes $162,835 AUD / $50,000 AUD 04/2014 – People upset because of lack of updates. Project might be dead, and backers lost their money 6. Dec. 2013 AIRTAME Indiegogo Yes $1,268,332 / $160,000 05/2014 12/2014 People have started received the beta versions, after a massive 8-month delay 7. Dec. 2013 Crystal Board Kickstarter No $14,574 / $200,000 04/2014 – The project appears to be dead 10. […]

$14 Digispark Pro is a Tiny Arduino Ready Board Supporting over 25 Shields (Crowdfunding)

Digispark Pro is yet another small Arduino compatible board, but it costs only $14, and over 25 small form factor shields for Wi-Fi, BLE, mesh networking, etc.. are available for the platform. Let’s get straight into the hardware specs: MCU – AVR MCU @ 16 Mhz  with 16KB Flash Memory (14.5K+ after bootloader) I/Os 14 I/O pins (2 shared with USB) I2C, true SPI, UART, LIN, and USI ADC on 10 pins 3 PWM Channels (which can be assigned to a selection of pins) USB – Micro USB for debugging, communication and power Misc – One button usable as reset, program, or user button, Power and Test/Status LEDs,  user accessible solder jumpers to disable LEDs, and other features for lower power consumption Power – 5V via micro USB, or External Source – 5v or 6-16v (automatic selection). On-board 500ma 5V regulator Dimensions – 26.7mm x 18.3mm The board is compatible […]

$59 Digitstump DigiX is an Arduino Due Compatible Board with Wi-Fi and Mesh Networking

The DigiX, by Digistump, is hobbyist board with an Atmel SAM3 Cortex M3 MCU @ 84 MHz, embedded low power Wi-Fi (b/g/n) and mesh networking,audio output, USB on the go support, and the company claims it is 100% compatible with anything that works with the Arduino Due, with some extra I/Os for a total of 99 I/O pins. The hardware specifications go as follows: MCU – Atmel AT91SAM3X8E 32-bit ARM Cortex M3 Processor @ 84 Mhz with 96KB SRAM, 512KB Flash Connectivity On-board 802.11b/g/n WiFi Module (FCC/CE Approved) On-board nRF24L01+ wireless module (removable) – 2.4Ghz band 99 I/O Pins including 12 PWM, 12 Analog Input, 2 Analog Output (DAC), CAN bus, 4x UARTs, 2x I2C, SPI, JTAG, DMA and more. Audio – 3.5mm stereo jack USB – micro USB OTG port Misc – On-board RTC, user LED Power Supply – 3.3V, 3.4-5.5V (LiPo Ready), 5V, or 6-16V input (on-board buck regulator) (Max?) Power […]
