Linux powered STMicro STM32MP1 Solder-down QFN-Style SoM Measures 27x27mm

STM32MP1 Solder-down QSMP SoM

STMicro STM32MP1 Cortex A7/M4 processor was launched last year with support for Linux and Android. Since then we’ve seen a few STM32MP1 SBC‘s, development kit and modules,  with some of the latter really compact with DHCOR STM32MP157 SoM found on Avenger96 board measuring just 29x29mm. Direct Insight has now unveiled QFN-style solder-down QSMP systems-on-module based on STM32MP1 that measure just 27 x 27 x 2.3mm and manufactured in Germany by Ka-Ro Electronics. Direct Insight / Ka-Ro STM32MP1 QSMP modules specifications: SoC QSMP-1510 module – STMicro STM32MP151A single-core Cortex-A7 processor up to 650 Mhz, plus Arm Cortex-M4 real-time core up to 200 MHz QSMP-1530 module – STMicro STM32MP153A dual-core Cortex -A7 processor up to 650 MHz, plus Arm Cortex-M4 real-time core up to 200 MHz QSMP-1570 module – STM32MP157C dual-core Cortex -A7 processor up to 650 MHz, plus Arm Cortex-M4 real-time core up to 200 MHz and Vivante 3D GPU with […]

TRITON-TX8M i.MX8M Mini / Nano Modules & Devkits Support Linux, Windows 10 IoT Core, and (Soon) QNX 7.0

Triton-TX8M Development Board

UK-based Direct Insight has recently unveiled TRITON-TX8M system-on-module (SoM) powered by NXP i.MX 8M Mini or Nano processor, coupled with up to 2048MB DDR3L and a 4GB eMMC flash. The tiny (68 x 26 mm) SODIMM module is pin-compatible with the company’s earlier TRITON-TX i.MX6 / i.MX8 module family, and currently support Linux and Windows 10 IoT Core, with a QNX 7.0 BSP in the works. TRITON-TX8M SoM specifications: SoC TRITON-TX8MM – NXP i.MX8M Mini Quad 4x Arm Cortex-A53 processor @ 1.6 GHz with real-time Cortex-M4F core, Vivante GC NanoUltra 3D GPU + GC320 2D GPU, 1080p VPU TRITON-TX8MN – NXP i.MX8M Nano Dual 2x Arm Cortex-A53 processor @ 1.4 GHz with real-time Cortex-M7 core, Vivante GC7000UL GPU with OpenGLES 3.0, OpenCL and Vulkan support System Memory – 512MB, 1GB, or 2GB RAM Storage – 4GB eMMC flash 200-pin SODIMM200 edge connector with Storage – 2x SD Card/SDIO Display – […]

$200 Direct Insight Triton-TXEK EvalKit for iMX6 Features Freescale i.MX 6Quad Processor

With Wandboard Quad, SABRE Lite, Nitrogen6X, and UDOO, we already have some choices when it comes to low cost Freescale i.MX 6Quad development platforms. Direct Insight, a British company, has developed another called TRITON-TXEK EvalKit for iMX6 that includes the company’s Triton-TX6Q SoM, for 130 GBP (about $200). TRITON-TXEK for iMX6 Specifications: Specifications listed for the Triton-TXEK evaluation kit include: SoC – Freescale i.MX 6Quad quad core Cortex-A9 @ 1GHz with Vivante GC2000 GPU System Memory – 1GB DDR3 Storage – 128MB NAND flash + SD card slot Display – TFT panel via 40-pin LCD flat cable header Connectivity – 10/100M Ethernet USB – USB 2.0 host + mini USB 2.0 host/device Serial – RS232on D-Sub connector Audio – 3.5mm headphone jack Power Supply – 5V Dimensions – Module: 68mm × 31mm, Baseboard: Who knows… Operating temperature – -20 to 70°C Since the only easily accessible display option is the […]

Direct Insight TRITON-TX6Q System-on-Module Powered by Freescale i.MX6Q

Direct Insight, a British company, has recently announced the TRITON-TX6Q, a SODIMM system-on-module based on Freescale’s iMX6Q quad core Cortex-A9 processor running at 1 GHz with 1 to 2GB RAM and 128 MB flash. This module targets embedded applications including medical devices, digital signage, and industrial multimedia products. Here are the TRITON-TX6Q specifications: SoC – Freescale i.MX6Q 4x ARM Cortex-A9 up to  1GHz + Vivante GC2000, GC355 and GC320 graphics co-processors System Memory – 1GB or 2GB 64-bit DDR3 @ 1066MHz Storage – 128MB NAND Flash, 2 SD card receptacles on baseboard Display Connection – LCD controller 24-bit parallel up to 1080p, dual LVDS (optional). Resistive & capactive touch screen support. Connectivity – Ethernet 10/100 BaseT with PHY on module. USB – USB Host + USB OTG Peripherals and Interfaces: Up to 5x UART (RS232) with pin sharing 2x I2C, 1x 1-wire and 2x SPI interfaces SSP (synchronous serial /digital audio): […]
