Rockchip RK3568 SBC takes up to four AHD cameras, two SATA drives

RK3568 analog camera board

Boardcon EM3568-AV CAM SBC is powered by a Rockchip RK3568 SoC and comes with four AHD (analog high-definition) camera connectors and two SATA 3.0 ports to store video data on hard drives. The SBC is also equipped with up to 8GB RAM, up to 128GB eMMC flash, supports MIPI DSI, LVDS, and eDP displays, and features a video composite output, two Gigabit Ethernet ports, WIFi 4 connectivity, an optional 4G LTE module, a few USB ports, and several connectors for expansion. Boardcon EM3568-AV CAM specifications: SoC – Rockchip RK3568 CPU – Quad-core Cortex-A55 processor @ up to 2.0 GHz GPU – Arm Mali-G52 2EE GPU with support for OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1 AI accelerator – 1 TOPS NPU (probably rounded up from 0.8 TOPS) VPU – 4Kp60 H.265/H.264/VP9 video decoding, and 1080p60 H.265/H.264 video encoding System Memory – 2GB (up to 8GB) Storage 8GB eMMC flash (up […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on Amlogic T962E2 quad-core Cortex-A55 TV box board supports 4K HDMI input & output

Amlogic T962E2 quad-core Cortex-A55 TV box board supports 4K HDMI input & output

Amlogic T962E2 TV box board

Amlogic T962E2 is an upgrade to the Amlogic T962E quad-core Cortex-A53 SoC we first found in the Alfawise H96 Mini TV box with both HDMI output and HDMI input ports. The new processor offers similar features but comes with more efficient Cortex-A55 cores, a Mali-G31 MP2 supporting modern Vulkan and OpenGL ES 3.2 APIs, and some other improvements including 4K AV1 video playback. While mostly designed for Smart TVs, I found the Amlogic T962E processor in a TV box board with up to 4GB RAM, 32GB eMMC flash, HDMI 2.1 output, HDMI 2.1 input, Gigabit Ethernet, a wireless module, and allegedly running either Android 8, Android 9, or Android TV. TV box boards specifications: SoC – Amlogic T962E2 quad-core Arm Cortex-A55 processor @ up to 2.0 GHz with Arm Mali-G31 MP2 GPU support OpenGL ES 3.2, Vulkan 1.1 and OpenCL 2.0, 1.2 TOPS AI accelerator, 2x HiFi4 DSP System Memory […]

Posted on by Karl Johnson - 4 Comments on Reolink RLC-523WA & RLC-823A Review – Smart security cameras tested with Blue Iris

Reolink RLC-523WA & RLC-823A Review – Smart security cameras tested with Blue Iris

Reolink RLC-523WA 5MP camera review

Hello, Karl here with a security camera review. I’ll start out by thanking Reolink for sending over two cameras to review: RLC-523WA (WiFi) & RLC-823A (PoE). I already had a couple of cameras from Reolink that my buddy had recommended a long time ago. And had a positive experience so I agreed to review these higher-end models. My setup with Blue Iris, unRAID I have been running unRAID for quite a while now to simplify my server requirements. I was running several small SBC’s and a standalone NAS drive and consolidated them onto my main rig. AMD has pushed desktop core counts with their Ryzen CPUs and I have cores to spare. I started with a 3700x giving 2 cores to applications leaving me with 6 cores for my VM’s but recently upgraded to a 3900x. I now give 3 to applications and 9 cores for my VM’s. I started […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 9 Comments on $23 N6110E NVR supports AI features, 10TB SATA drive, up to 10 video channels

$23 N6110E NVR supports AI features, 10TB SATA drive, up to 10 video channels

N6110E SigmaStar SSR621Q network video recorder

Network video recorders (NRV) typically cost a couple of hundred dollars, but in the past, we noted a low-cost, entry-level NVR with a single Ethernet port may sell for under $50. But now, I’ve been made aware that $20 Linux-based NVR’s had shown up on Aliexpress either based on XM8536D processor, or SigmaStar SSR621Q dual-core Cortex-A7 processor.  I’ll look at the N6110E model with the latter that sells for $22.99 plus shipping as it includes an enclosure and is said to support up to 10 channels, as well as AI features such as face & human body detection, “auto tracking” (vehicle tracking?), and mixed-traffic detection. N6110E NVR specifications: SoC – SigmaStar SSR621Q processor/DSP with two Cortex-A7 cores, 256MB DDR3 RAM according to linux-chenxing Video decoding – H.265 , H.264 up to 1x 8MP @ 30 fps, 1x 5MP @ 30 fps, 2x 4MP @ 30fps, 4x 3MP @ 20 fps, […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 5 Comments on Firefly unveils Core-3568J AI Core Rockchip RK3568 system-on-module & devkit

Firefly unveils Core-3568J AI Core Rockchip RK3568 system-on-module & devkit

RK3568 devkit

Firefly has unveiled a new 314-pin SO-DIMM system-on-module (SoM) with Core-3568J AI Core powered by Rockchip RK3568 processor and equipped with up to 8GB RAM, 128GB eMMC flash with interfaces including PCIe, SATA, dual Gigabit Ethernet, HDMI 2.0, eDP 1.3, MIPI DSI and more. The company also provides AIO-3568J development kit for the module with all those interfaces plus an M.2 socket for 5G or WiFi 6 connectivity, and PoE support among other features. Core-3568J AI Core system-on-module Specifications: SoC – Rockchip RK3568 quad-core Cortex-A55 processor @ 2.0 GHz with Arm Mali-G52 2EE GPU with support for OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1, 0.8 TOPS NPU for AI acceleration, 4Kp60 H.265/H.264/VP9 video decoding, and 1080p100 H.265/H.264 video encoding System Memory – 2GB, 4GB, or 8GB LPDDR4 ECC RAM up to 1600 MHz Storage – 32GB, 64GB, or 128GB eMMC flash 314-pin SO-DIMM edge connector with: Storage – SATA 3.0 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 46 Comments on Rockchip RK3568 processor to power edge computing and NVR applications

Rockchip RK3568 processor to power edge computing and NVR applications

Rockchip RK3568

We recently reported on the Rockchip developer conference (RKDC) 2020, and especially the upcoming Rockchip RK3588 Cortex-A76/A55 processor that packs a lot of power and features, and is now scheduled to launch in Q3 2021. But as you can imagine there were other products revealed during the conference, including the new Rockchip RK3568, similar to the previously announced RK3566, and designed for edge computing and network video recorder (NVR) applications. There’s also an RK353X processor specifically designed for NVR application that should have similar performance as RK3568, but a lower cost, as well as two UP camera SoC with RV1106 and RV1128. CNX Software managed to obtain the presentation for the RK3568 processor from the conference so we’ll focus on the quad-core Cortex-A55 processor in this post. Rockchip RK3568 specifications: CPU – Quad-core Cortex-A55 processor with NEON and FPU GPU – Mali-G52 EE with support for OpenGL ES 1.1 to […]

Posted on by Stephen Vicinanza - No Comments on Apollo Lake based AAEON VPC-3350S Fanless Industrial In-vehicle NVR Comes with 4 PoE Ports

Apollo Lake based AAEON VPC-3350S Fanless Industrial In-vehicle NVR Comes with 4 PoE Ports

AAEON NVR VPC-3350S Industrial In-Vehicle  The AAEON fanless industrial network video recorder has joined the ranks of such NVR’s as the Solidrun Clearfog GTR A385, which was reported just recently as hitting the market. AAEON VPC-3350S is an in-vehicle industrial NVR that is aimed at mobile AI and IoT in areas such as license plate recognition. Processor Options The VPC-3350S is equipped with an Intel Atom x5-E3940 (formerly known as Apollo Lake) processor that comes standard. There are also options for the Pentium N4200 and the Atom x7-E3950. Configurations The units come in a variety of versions, with industrial, in-vehicle and customizable AI module, running the Intel Movidius Myriad X SoC. Offering more options than any other mobile NVR. Industrial Option The more compact Industrial VPC-3350S offers an I/O complement meant for more machine vision applications, such as license plate recognition. In-Vehicle Option The In-Vehicle option allows for fast set-up […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on SolidRun ClearFog GTR A385 NVR Platforms Feature Up to 8 Gigabit Ethernet PoE Ports

SolidRun ClearFog GTR A385 NVR Platforms Feature Up to 8 Gigabit Ethernet PoE Ports

SolidRun ClearFog GTR A385 NVR

A Networking Video Recorder (NVR) is designed to record and playback videos from multiple IP cameras usually connected over Ethernet, and in many cases powered over Ethernet (PoE). The main purpose is for security applications allowing caretakers to monitor multiple cameras at the same time on a mosaic screen. There are plenty of turnkey NVR solutions on the market, but SoliRun, an embedded systems company known for its modules and single board computers, recently introduced the ClearFog GTR A385 family that supports up to eight PoE/PoE+ Gigabit Ethernet Ports. The ClearFog GTR A385 family currently includes two modules with GTR S4 supporting up to four cameras, and GTR L8 up to eight cameras. Specifications: SoC – Marvell ARMADA A385 dual-core Armv7 (Cortex A9 class) up to 1.3Ghz System Memory – Up to 2GB on-board DDR3L Storage – 8GB eMMC flash (default),  2x 7 pin SATA (optional replacement for 2 x […]
