Dockcase 7-in-1 USB-C dock features a color information display (Crowdfunding)

Dockcase USB hub with built-in information display

USB-C docks have become somewhat boring, but Dockcase 7-in-1 USB-C dock is a little different with a transparent top cover made of tempered glass and an integrated color display that looks neat and may end up being useful by providing relevant information. The USB-C dock also comes with three 5Gbps USB 3.2 Gen 1 ports, a 4Kp60 capable HDMI 2.0 video output, SD card & microSD card slots, support for 100W USB PD, and a 10 Gbps USB Type-C port for connection to the host. Dockcase 7-in-1 USB-C dock specifications: Display – 1.33-inch color LCD display with 240 x 240 resolution Storage – SD and microSD (UHS-I) card slots HDMI output up to 4Kp60 (3840×2160) USB Input – 10Gbps USB-C port with cable Output – 3x USB 3.2 Gen 1 (5 Gbps) ports Misc – Control button Power Input – 100W (20V/5A) USB PD Dimensions – 122 x 40 x […]

8K 50MP camera module targets NVIDIA Jetson, Raspberry Pi, and RK3588 boards (Crowdfunding)

50MP camera Raspberry Pi 4

RBTS.co’s C50M camera module is equipped with the same 8K 50MP Samsung ISOCELL GN2 image sensor found in the upcoming Google Pixel 8 Pro smartphone but targets the maker market with support for NVIDIA Jetson, Raspberry Pi, and Rockchip RK3588 boards. With high-resolution and quick focusing ability, this camera sensor is designed for drones, machine vision, and industrial automation applications such as automated optical inspection and preventive maintenance, and the large 1.4μm pixels of the Samsung ISOCELL GN2 sensor are said to make the camera work well in low-light conditions. C50M camera module specifications: Effective Resolution – 8,160 x 6,144 (50MP) Pixel Size – 1.4μm (2.8μm with 12.5MP binning) Optical Format – 1/1.12″ sensor Color Filter – Dual Tetrapixel RGB Bayer Pattern Frame Rate – 30fps @ 50MP, 120fps @ 4K and 480fps @ FHD ADC Accuracy – 10-bits Chroma – Tetra Auto Focus – Dual Pixel Pro (PDAF); range: […]

PlanetPC XR1/XR2 Rockchip RK3568/RK3588 Mini PC comes with a touchscreen display for control (Crowdfunding)

Planet XR2 RK3588 mini PC touchscreen display

PlanetPC XR1/XR2 are Arm Linux mini PCs based on Rockchip RK3568 or RK3588 processor respectively with a unique design featuring an integrated touchscreen display for control. Planet Computers has designed several unique computing devices over the years such as the Cosmo Communicator 2-in-1 smartphone and computer or Astro Slide 5G transformer smartphone, and the British company has now come up with a mini PC  preloaded with Ubuntu with a touchscreen screen interface, dual 4K/8K video output, dual Gigabit Ethernet and more. PlanetPC XR1/XR2 specifications: SoC PlanetPC XR1 – Rockchip RK3568 quad-core Cortex-A55 processor up to 2.0 GHz with Arm Mali-G52 2EE, 0.8 TOPS NPU PlanetPC XR2 – Rockchip 3588 octa-core Cortex-A76/A55 processor up to 2.4 GHz with Arm Mali-G610 MP4 GPU, 6 TOPS NPU System Memory & Storage PlanetPC XR1 4GB LPDDR4 32GB eMMC flash Optional 512GB, 1TB, 2TB M.2 NVMe Optional up to 14TB SATA HDD or 2TB SATA […]

Sipeed M1s & M0sense – Low-cost BL808 & BL702 based AI modules (Crowdfunding)

Sipeed M1s & M0Sense

Sipeed has launched the M1s and M0Sense AI modules. Designed for AIoT application, the Sipeed M1s is based on the Bouffalo Lab BL808 32-bit/64-bit RISC-V wireless SoC with WiFi, Bluetooth, and an 802.15.4 radio for Zigbee support, as well as the BLAI-100 (Bouffalo Lab AI engine) NPU for video/audio detection and/or recognition. The Sipeed M0Sense targets TinyML applications with the Bouffa Lab BL702 32-bit microcontroller also offering WiFi, BLE, and Zigbee connectivity. Sipeed M1s AIoT module The Sipeed M1S is an update to the Kendryte K210-powered Sipeed M1 introduced several years ago. Sipeed M1s module specifications: SoC – Bouffalo Lab BL808 with CPU Alibaba T-head C906 64-bit RISC-V (RV64GCV+) core @ 480MHz Alibaba T-head E907 32-bit RISC-V (RV32GCP+) core @ 320MHz 32-bit RISC-V (RV32EMC) core @ 160 MHz Memory – 768KB SRAM and 64MB embedded PSRAM AI accelerator – NPU BLAI-100 (Bouffalo Lab AI engine) for video/audio detection/recognition delivering up […]

Sipeed MetaSense RGB ToF 3D depth cameras are made for MCUs & ROS Robots (Crowfunding)

Sipeed MetaSense RGB ToF 3D Depth Cameras

We’ve just written about the Arducam ToF camera to add depth sensing to Raspberry Pi, but there are now more choices, as Sipeed has just introduced its MetaSense ToF (Time-of-Flight) camera family for microcontrollers and robots running ROS with two models offering different sets of features and capabilities. The MetaSense A075V USB camera offers 320×240 depth resolution plus an extra RGB sensor, an IMU unit, and a CPU with built-in NPU that makes it ideal for ROS 1/2 robots, while the lower-end MetaSense A010 ToF camera offers up to 100×100 resolution, integrates a 1.14-inch LCD display to visualize depth data in real-time and can be connected to a microcontroller host, or even a Raspberry Pi, through UART or USB. MetaSense A075V specifications: SoC – Unnamed quad-core Arm Cortex-A7 processor @ 1.5 GHz with 0.4 TOPS NPU System Memory – 128 MB RAM Storage – 128MB flash Cameras 800×600 @ 30 […]

GOLE1 Pro mini PC comes with 5.5-inch touch screen display, Gemini Lake processor (Crowdfunding)

GOLE1 was quite a unique mini PC when it launched in 2016 as it included a 5-inch touchscreen display. HIGOLE is now back with the GOLE1 Pro based on a similar design, but a slightly larger 5.5-inch touchscreen display, and much better specs suitable for 2022’s software and entry-level use cases. The Atom x5-Z8300 “Cherry Trail” processor found in the original device gives way to an Intel Celeron N4200 or J4125 Gemini Lake processor, and the GOLE1 Pro mini PC, which the company sometimes also calls “HIGOLE PC 2022”, comes with up to 8GB LPDDR4X, a 128GB SSD, Gigabit Ethernet, WiFI 6 or 5, four USB 3.0 ports, and more. GOLE1 Pro specifications: SoC (one or the other) Intel Celeron J4125 quad-core processor @ 2.00 GHz / 2.70 GHz (Turbo) / 2.4 GHz (Turbo all cores) with 12EU Intel UHD Graphics 600 @ 250 MHz / 750 MHz (Turbo); 10W […]

PIX NII is a pocket-sized mini PC powered by an Intel Pentium N6005 processor (Crowdfunding)

PIX-NII pocket-sized PC

PIX NII pocket-sized mini PC features an Intel Pentium N6005 Jasper Lake processor that should provide a nice upgrade to existing 2.4-inch mini PCs based on Gemini Lake processors such as Larkbox. The tiny computer is slightly larger (2.7×2.6 inch) than the previous 2.4-inch models, but ships with up to 16GB RAM, up to a 1TB NVMe SSD, and offers two 4K-capable HDMI 2.0 ports, Gigabit Ethernet & WiFi 6 connectivity, as well as a few USB 3.2 ports, plus a 3.5mm audio jack. PIX NII specifications: SoC – Intel Pentium N6005 quad-core processor @ 2.0GHz / 3.3GHz (Turbo) with Intel UHD graphics; 10W TDP System Memory – 8GB or 16GB DDR4 RAM Storage SATA or NVMe SSD with 256GB, 512GB, or 1TB capacity (up to 520MB/s with SATA, 1,000MB/s with NVMe) MicroSD card socket Video Output – 2x HDMI 2.0 ports up to 4Kp60 Audio – 3.5mm audio jack, […]

MOREFINE M6 – An ultra-thin Jasper Lake mini PC (Crowdfunding)

MOREFINE M6

We’ve seen a fair amount of Jasper Lake mini PCs, and even reviewed one with Beelink U59. MOREFINE M6 stands out due to its size and thickness, being about the size of two smartphones stacked together. The features are also promising with an Intel Celeron N5105 quad-core processor coupled with up to 16 GB RAM, up to 1TB M.2 NVMe SSD, as well as dual 4K video output through HDMI and USB-C ports, a 2.5GbE ports WiFi 6 & Bluetooth 5.2 connectivity, and three USB 3.1 ports. MOREFINE M6 specifications: SoC – Intel Celeron N5105 quad-core Jasper Lake processor @ 2.0GHz / 2.9GHz (Turbo) with Intel UHD graphics 605; 10W TDP System Memory – 8GB or 16GB LPDDR4 Storage – 512GB or 1TB M.2 NVMe 2280 SSD, or 256GB M.2 SATA SSD Video Output 1x HDMI 2.0 port up to 4Kp60 1x DisplayPort Alt Mode via USB-C port up to […]
