$70 NanoPi M4V2 SBC Gets 4GB LPDDR4 RAM, Power & Recovery Buttons

NanoPi M4V2

FriendlyELEC NanoPi M4 is a Rockchip RK3399 single board computer that follows Raspberry Pi 3 form factor, and was launched in a year ago for $65 with 2GB RAM, and $95 with 4GB RAM. Raspberry Pi 4 introduction brought some more competition, and helped the prices drop to $50 and $75 respectively. But now the company has launched a revision 2 of the board, NanoPi M4V2 that replaces LPDDR3 memory with faster LPDDR4 memory, adds power & recovery buttons, and the audio jack now also support microphone input. It’s only available with 4GB LPDDR4 memory, and the price is lower at $70. The rest of the specifications are mostly identical: SoC – Rockchip RK3399 big.LITTLE hexa-core processor with 2x Arm Cortex-A72 @ up to 2.0GHz, 4x Cortex-A53 @ up to 1.5GHz, a Mali-T864 GPU with support OpenGL ES1.1/2.0/3.0/3.1, OpenVG1.1, OpenCL, DX11, and AFBC, and a VPU with 4K VP9 and 4K 10-bit H265/H264 6decoding System Memory – Dual-channel 4GB LPDDR4 […]

NanoPi M4 SBC Metal Case Comes with an NVMe SSD Adapter and Cooling Fan

NanoPi M4 Metal Case

There are several single board computers that come with NVMe SSD either directly like on ODROID-H2 SBC or indirectly via an expansion board such as M2X extender board for Khadas VIM3.  But if you’d like an enclosure for your system it either further adds to the cost, or you need to develop the case yourself. If you’d like an SBC that takes an NVMe SSD in a fairly compact enclosure and at a affordable price (under $100 excluding the SSD),  NanoPi M4 metal case kit looks to be a good option and sells for $28 with SSD adapter and fan, or just $26 if you already own the SSD adapter. As a reminder, NanoPi M4 is a Rockchip RK3399 SBC that mostly follows Raspberry Pi form factor comes with 2GB or 4GB RAM with price starting at $50. See NanoPi M4 specifications for more details. One selling point of this board is that Rockchip RK3399’s PCIe signal are exposed through […]

TensorFlow Lite for Microcontrollers Benchmarked on Linux SBCs

TensorFlow Lite microcontrollers benchmark linux SBC

Dimitris Tassopoulos (Dimtass) decided to learn more about machine learning for embedded systems now that the technology is more mature, and wrote a series of five posts documenting his experience with low-end hardware such as STM32 Bluepill board, Arduino UNO, or ESP8266-12E module starting with simple NN examples, before moving to TensorFlow Lite for microcontrollers. Dimitris recently followed up his latest “stupid project” (that’s the name of his blog, not being demeaning here :)) by running and benchmarking TensorFlow Lite for microcontrollers on various Linux SBC. But why? you might ask. Dimitris tried to build tflite C++ API designed for Linux, but found it was hard to build, and no pre-built binary are available except for x86_64. He had no such issues with tflite-micro API, even though it’s really meant for baremetal MCU platforms. Let’s get straight to the results which also include a Ryzen platform, probably a laptop, for reference: SBC Average for 1000 runs  (ms) Ryzen 2700X (this […]

Linux 5.2 Release – Main Changes, Arm, MIPS & RISC-V Architectures

Linux 5.2 Changelog

Linus Torvalds announced the release of Linux 5.2 last Sunday: So I was somewhat pre-disposed towards making an rc8, simply because of my travels and being entirely off the internet for a few days last week, and with spotty internet for a few days before that [*]. But there really doesn’t seem to be any reason for another rc, since it’s been very quiet. Yes, I had a few pull requests since rc7, but they were all small, and I had many more that are for the upcoming merge window. Part of it may be due to the July 4th week, of course, but whatever – I’ll take the quiet week as a good sign. So despite a fairly late core revert, I don’t see any real reason for another week of rc, and so we have a v5.2 with the normal release timing. There’s no particular area that stands out there – the changes are sosmall that the appended […]

NanoPi M4 RK3399 SBC Price Drops to $50 and Up

NanoPi M4

The launch of Raspberry Pi 4 SBC has generated lots of interest, especially with the extra performance and low $35 price tag that has made most alternatives suddenly less interesting. However, Raspberry Pi 4 benchmarks show it’s not quite the fastest board around, and for example, Rockchip RK3399 platforms are still quite faster, sometimes as much as twice as fast. They do cost much more though, often more than twice, and so far one of the cheapest RK3399 boards was NanoPi M4 going for $65. FriendlyELEC has now decided, certainly in response to Raspberry Pi 4 offering, to lower the price to $50 for the 2GB RAM version which compares to $45 with Raspberry Pi 4 2GB, as well as $75 for the 4GB RAM version (was $95). NanoPi M4 specifications: SoC – Rockchip RK3399 big.LITTLE hexa-core processor with 2x Arm Cortex-A72 @ up to 2.0GHz, 4x Cortex-A53 @ up to 1.5GHz, a Mali-T864 GPU with support OpenGL ES1.1/2.0/3.0/3.1, OpenVG1.1, […]

Design your own NAS with $25 4x SATA HAT for NanoPi M4 Board

4x SATA HAT NanoPi M4

NanoPi M4 is one of the many Rockchip RK3399 boards available on the market today. The SBC follows Raspberry Pi form factor, comes with 2 to 4 GB RAM, four USB 3.0 ports, Gigabit Etherent, HDMI 2.0, etc.. and exposes the 2-lane PCIe interface from the Rockchip processor not through a typical PCIe slot or mini PCIe slot, but instead through a 2.54mm pitch header. I feel like an odd choice at first glance, but it now makes complete sense, as the company has launched a 4x SATA HAT for NanoPi M4 board that leverages the header with PCIe 2x signals. 4x SATA HAT for NanoPi M4 key features and specifications: PCIe to SATA Chipset – Marvell 88SE9215 four-port 6Gbps SATA I/O controller USB – 2x 4-pin USB 2.0 host connectors Expansion – NanoPi M4 40-pin header exposed Misc Power key, unpopulated power key jumper Power LED, 4x SATA LEDs Heat dissipation – 2x PCB nuts for mounting a heatsink […]

NanoPi M4 Raspberry Pi Inspired RK3399 Board Launched for $65 and Up

NanoPi M4 Heatsink

As expected, FriendlyELEC has now launched NanoPi M4 board, a lower cost version of NanoPC-T4 Rockchip RK3399 SBC, and mostly following Raspberry Pi form factor. How much you may ask? That would be $65 plus shipping for the 2GBRAM version, and $95 for the 4GB RAM version, which means it sells in the same ballpark as RockPro64 board. NanoPi M4 board specifications: SoC – Rockchip RK3399 big.LITTLE hexa-core processor with  2x Arm Cortex-A72 @ up to 2.0GHz, 4x Cortex-A53 @ up to 1.5GHz, a Mali-T864 GPU with support OpenGL ES1.1/2.0/3.0/3.1, OpenVG1.1, OpenCL, DX11, and AFBC, and a VPU with 4K VP9 and 4K 10-bit H265/H264 6decoding System Memory – Dual-channel 4GB LPDDR3-1866, or dual-channel 2GB DDR3-1866 Storage – eMMC module socket, micro SD card slot Video Output HDMI 2.0a up to 4K @ 60 Hz with HDCP 1.4/2.2 support 4-Lane MIPI-DSI connector Audio – 3.5mm headphone jack, HDMI digital audio output, microphone header Camera – one or two 4-lane MIPI-CSI […]

MuxPi Board Relies on NanoPi NEO to Enable Remote Testing of Development Boards

MuxPi Remote Testing Board

Product development often occurs in different location over the world, there may be one team in Asia, and another in Europe and the US. At the beginning, the number of working samples for a board may be limited,  so the project manager may have to decide who gets the boards since those may not be available to all teams. So it would be great if somehow there was a way to do remote testing of boards, so maybe the team in Asia could setup the testbed, used it during there time, and once they are back home, the US team can take over remotely to carry on their own development work on the hardware. That’s exactly what MuxPi board is all about. The solution provide remote access via the Ethernet port of a NanoPi NEO board, and connects to the DUT (Device under Test) via HDMI, Ethernet, USB and other interfaces. The (micro) SD card is muxed to either boot […]
