Rockchip RK3588 8K TV Box Triples as 5G & WiFi 6 Router, Home Automation Gateway

Rockchip RK3588 octa-core Cortex-A76/A55 processor was only expected in the second half of 2020 for IoT and vision/AI applications, but at least one company is working on a 3-in-1 product based on Rockchip high-end processor with a “5G AIoT 8K TV box” that also works as a 5G and WiFi 6, and with features such as Zigbee can also act as a home automation gateway. “5G AIoT Android TV Box” preliminary specifications: Main SoC – Rockchip 3588 octa-core processor with 4x Cortex-A76 and 4x Cortex-A55 cores in dynamIQ configuration, Arm “Natt” GPU (i.e. NOT Mali-G31 MP2), NPU 2.0, 8K H.265/AV1 video decoder, 4K video encoder System Memory – 4GB DDR4 Storage – 32GB eMMC flash, MicroSD card slot up to 64GB?! Video Output – HDMI 2.1 up to 8K resolutions Audio – SPDIF audio output, HDMI audio Connectivity 802.11 b/g/n/ac/ax WiFi 6 and Bluetooth 5.1 via Qualcomm QCA6391 WiSoC 1x Gigabit Ethernet port, 1x Fast Ethernet port connected to RK3588 […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

Amlogic S922X Digital Signage Board Comes with HDMI, LVDS, V-by-One, and eDP Video Interfaces

Thanks to its 4K video playback and output capability and high-speed interfaces such as PCIe, USB 3.0 and Gigabit Ethernet, Amlogic S922X is a suitable processor for 4K digital signage players. One way is to get a TV box optimized for signage applications such as Rikomagic MK25, but if you want to integrate a board into your own display, XYT-6689 SBC may be an interesting option with LVDS, V-by-One and eDP (embedded DisplayPort) display interfaces, as well as many other features. XYT-6689 S922X digital signage board specifications: SoC – Amlogic S922X hexa-core big.LITTLE processor with 4x Arm Cortex A73 cores @ up to 2.0 GHz, 2x Arm Cortex A53 cores, Arm Mali-G52MP6 (6EE) GPU; 12nm manufacturing process System Memory – 2GB or 4GB LPDDR4 Storage – 16GB to 64GB eMMC flash, microSD card slot up to 128 GB; maybe SATA (unsoldered “laptop” SATA interface on the backside of the board) Video Output & Display Interface HDMI 2.1 up to 4K […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

Onenuts Nut 9 TV Box Runs Android TV, Doubles as a Smart Speaker

Onenuts Nut 9 Android TV Box

We’ve previously covered HF10 2-in-1 Android speaker and TV box that looks more like a speaker than a TV box, and since we’ve posted about it several years got improved to work as a smart speaker supporting Amazon Alexa. If you’re a distributor looking for something with the same functionalities, but in a more compact TV box form factor, Shenzhen Tomato got you covered with their Onenuts Nut 9 TV box that works as a traditional TV box running Android TV 7.1, as well as a smart speaker with support Google Assistant even when the TV is off thanks to a built-in microphone and a speaker placed on the bottom of the enclosure. Onenuts Nut 9 specifications: SoC – Amlogic S905X Arm Cortex-A53 processor up to 1.5GHz with penta-core Mali-450MP GPU up to 750Mhz+ System Memory – 2GB DDR3 Storage – 16GB eMMC flash, micro SD card slot Video Output – HDMI 2.0a up to 4K (3840 X 2160) @ 60Hz […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

An Interview with a TV Box Manufacturer: Shenzhen Tomato

Shenzhen Tomato Logo

I’ve been interviewing Jojo Zhou, Sales Manager at Shenzhen Tomato Technology, a TV box manufacturer, over email to learn a bit more about the TV box market, and various challenges encountered by manufacturers. CNXSoft: We’ve already covered several products sold by Shenzhen Tomato on CNX Software, but for readers who may not know the company yet, could you provide a short description of the company? Jojo Zhou: With over 8-years of experience, Shenzhen Tomato Technology Co., Ltd has become one of the leading OEM/ODM manufacturers specialized in developing Android TV Box, IPTV Set Top Box, Android Media Player, Hybrid Set Top Box and media solution. ODM and OEM is our main advantage, including hardware design and software customize (such as driver porting, kernel modification, etc). We have a first-class R&D team of 30 energetic engineers with rich experience to focus on that. A strict and complete quality control system is built to ensure each product has been strictly inspected before […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

Onenuts 4G LTE TV Box Comes with Optional Battery and Zigbee Connectivity

4G LTE TV Box Battery SIM Card

In some countries, especially in the Middle Easy and Africa, 4G LTE is a popular way of getting broadband Internet, and in the past we covered several 4G LTE TV boxes running Android such as WeTek Hyperion,  SDMC DV8230-AP LTE, or Geniatech ATV329. Shenzhen Tomato now offers another options with their “Onenuts 4G-LTE Android OTT Set-Top Box” powered by Amlogic S905X processor, and that happens to come with a compartment for optional batteries. Onenuts 4G LTE TV box specifications: SoC – Amlogic S905X quad core Arm Cortex-A53 processor @ 1.5 GHz with penta-core Mali-450 GPU System Memory – 1GB or 2GB Storage –  8GB, 16G, or 32G eMMC flash; micro SD card slot Video Output – HDMI 2.0a up to 4K UHD @ 60 Hz, AV output (composite) Audio – Video – 10-bit H.265 & VP9 Profile 2 4K @ 60fps, H.264 4K @ 30fps, AVS+ & H.264 1080p60 Connectivity 10/100M Ethernet Dual band WiFi 802.11b/g/n and Bluetooth 4.0 4G […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

Realtek RTD1295 based X2 Android TV Stick Comes with HDMI Output, HDMI Input

Realtek RTD1295 processor is found in mid to high end 4K HDR TV boxes with interfaces like SATA, USB 3.0, as well as HDMI input used for PiP or video recording features. Devices equipped with the processor that come to mind include Zidoo X9S or EWEAT R9 Plus TV Box + NAS, both of which are full featured and fairly large devices, running Android 6.0 and OpenWrt. Shenzhen Tomato has unveiled another type of device based on RTD1295 processor: X2 HDMI TV dongle that features both HDMI output & HDMI input ports, and runs Android 6.0 (but not OpenWrt). X2 TV stick specifications: SoC – Realtek RTD1295 quad core Cortex A53 processor @ 1.40 GHz with ARM Mali-T820MP3 GPU System Memory – 1 or 2GB DDR4 Storage – 8 or 16GB eMMC flash + micro SD slot Video & Audio I/O – HDMI 2.0a output, and HDMI 1.4 input Video Codec – 10-bit HEVC/H.265 up to 4K @ 60fps, H.264 […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

ONENUTS Nut 1 TV Box Specifications, Unbagging and Teardown

I first discovered Shenzhen Tomato’s ONENUTS brand through ONENUTS T1 3-in-1 projector, tablet, and mini PC, but the company has now launched a new product with ONENUTS Nut 1 Android TV box powered by Amlogic S912 processor, and the usual 2GB RAM and 16GB storage, but the product stands out a little thanks to its presentation as we’ll see below. ONENUTS Nut 1 Specifications The technical specifications are pretty much standard: SoC – Amlogic S912 octa-core ARM Cortex A53 processor @ up to 1.5 GHz with ARM Mali-820MP3 @ up to 750MHz System Memory – 2GB DDR3 Storage – 16GB eMMC flash + micro SD slot up to 32GB Video Output – HDMI 2.0a up to 4K @ 60Hz with CEC and HDR support, and AV port (composite) Audio Output – HDMI, AV (stereo audio), and optical S/PDIF Connectivity – Gigabit Ethernet, dual band WiFi 802.11 b/g/n/ac, Bluetooth 4.0 USB – 2x USB 2.0 ports including one OTG port Misc […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

ONENUTS T1 Combines Projector, Tablet, and mini PC into one Device

ONENUTS T1 look reminds me of GOLE1 mini PC / tablet combo, and the device also features the same Intel Atom x5-Z8300 processor. However, the 8″ display is quite bigger, and more importantly it includes a mini DLP projector. ONENUTS T1 specifications: SoC – Intel Atom x5-Z8300 “Cherry Trail” quad core processor @ 1.44 GHz / 1.84 GHz with Intel Gen8 HD graphics (2W SDP) System Memory –  2 GB DDR3L Storage – 32 GB eMMC flash + micro SD slot up to 64GB Projector – 0.3″ TI DMD (DLP) + LED technology, 1280×720 resolution, 5.5″ to 81″ screen size, 300 lumens, 500:1 contrast ratio; lifetime: > 20,000 hours Display – 8″ capacitive touchscreen IPS display with 1280×800 resolution (16:10 aspect ratio) Video Output – HDMI 1.4 port Audio I/O – HDMI, 3.5mm headphone jack, built-in speaker Connectivity – 10/100M Ethernet, 802.11 b/g/n/ac Wi-Fi, and Bluetooth 4.0 LE USB – 1x USB 2.0 host port, 1x USB 3.0 port Sensor […]
