September 5, 2016September 6, 2016 by Jean-Luc Aufranc (CNXSoft) - 28 Comments

You Can Now Buy ESP3212 ESP32 WiFi + Bluetooth Module for $6.95

After the official launch of ESP32 processor for less than $3, it did not take long before ESP32 modules hit the market, and Seeed Studio has already listed ESP3212, one of the first modules based on Espressif ESP32 Bluetooth LE + WiFi SoC, for $6.95 with shipping scheduled to start on September 23, 2016. ESP3212 module specifications: SoC – Espressif ESP32 dual core Xtensa LX6 processor @ up to 240 MHz with 448 KB flash, 520 KB SRAM, 16 KB SRAM in RTC, WiFi and Bluetooth LE connectivity Storage – 4MB Winbond SPI flash Connectivity 802.11 b/g/n/e/i WiFi (HT40) up to 150 Mbps Bluetooth 4.2 BR/EDR and BLE 3 dBi PCB antenna Headers – 22x GPIOs (multiplexed with ADC, Touch, DAC, SPI, UART, CAN, ETH, IR, PWM, and I2S), 1x UART, Sense VP/Sense VN, EN pin. 3.3V and GND Power Supply – 3.0 – 3.6V Dimensions – 24 x 16 […]

July 19, 2016July 19, 2016 by Jean-Luc Aufranc (CNXSoft) - 8 Comments

Setting a VoIP SIP user agent with Embedded Linux

This is a guest post by Leonardo Graboski Veiga, working for Toradex. Introduction This article’s main goals are: to cross-compile the PJSIP libraries and the PJSUA API reference implementation; deploy it to the target system; give an overview about the SIP protocol; and explore the reference implementation features, regarding audio only. For this purpose, a Computer on Module (CoM) from Toradex was chosen in the following configuration: Colibri iMX6DL* + Colibri Evaluation Board. The evaluation board and CoM are displayed in Figures 1 and 2, respectively. VOIP or Voice over IP, is a term designed to refer to a set of methods and technologies targeted for the implementation of telephony services over the Internet. For the purpose of this article, the scope will be limited to the use of a reference implementation built upon the SIP communication handling protocol by means of the PJSIP libraries and PJSUA2 API. If […]

July 18, 2016July 18, 2016 by Jean-Luc Aufranc (CNXSoft) - 10 Comments

ArduCAM has designed a Tiny Coin-Sized Raspberry Pi Compatible Module

Now you can design your own custom hardware and leverage Raspberry Pi software, by integrating Raspberry Pi Compute module (and soon Raspberry Pi 3 Compute module) into your custom designed baseboard. But if you’d like something more compact, and even more compact than a Raspberry Pi Zero or RPi Compute module, ArduCAM has been developing a 24x24mm Raspberry Pi compatible system-on-module powered by Broadcom BCM2835 processor. ArduCAM has also designed a small adapter board “UC-343 Rev. A” for the module with the following specifications: SoC – Broadcom BCM2835 ARM11 Processor @ 700 MHz (or 1GHz?) with Videocore IV GPU System Memory – 256MB/512MB LPDDR2 Storage – micro SD card slot USB – 2x micro USB ports including one for power only Camera – 1x MIPI CSI connector supporting 5MP or 8MP Pi cameras (dual camera support) Expansion – AV output header 16-pin and 8-pin headers (unpopulated) with GPIOs, 2x I2C, […]

July 13, 2016July 13, 2016 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

sModule SBC-x6818 Development Kit based on Samsung S5P6818 Processor Includes a 7″ Touchscreen

For some reasons, Samsung S5P4418 and S5P6818 quad and eight Cortex A53 core processors – likely made by Nexell – have been quite popular with embedded systems companies based in China. So after Graperain, Boardcon, and FriendlyARM, there’s at least one another company offering solutions with either processor, as sModule, a subsidiary of CoreWind, has now launched systems-on-module, single board computers, and development kits with the 64-bit ARM SoCs. In this post, I’ll cover one of their development kit including their CORE6818 CPU module, a baseboard, and an optional 7″ capacitive touch display.. sModule SBC-x6818 development kit specifications: CORE6818 CPU module SoC – Samsung S5P6818 octa-core ARM Cortex A53 processor @ 1.4 to 1.6 GHz with Mali-400MP 3D GPU System Memory – 1GB DDR3 (2GB optional) Storage – 8GB eMMC Flash (4 & 16GB optional) Ethernet – Realtek RTL8211E Gigabit Ethernet transceiver 180-pin “interface” to baseboard Power Supply – 3.7 […]

June 29, 2016July 5, 2016 by Jean-Luc Aufranc (CNXSoft) - 8 Comments

Boardcon MINI6818 CPU Module Features Samsung S5P6818 Octa-core Processor

Update: a defect has been found, so the board is not for sale anymore. Samsung S5P6818 octa-core Cortex A53 processor has already been found in several single board computers and development boards including Graperain G6818 SBC and NanoPi M3 board, but so far I had not seen it implemented into a system-on-module to be used in custom designs, and that’s just was Boardcon did with their MINI6818 CPU module. Boardcon MINI6818 SoM specifications: SoC – Samsung S5P6818 octa-core ARM Cortex A53 processor @ 1.4GHz with Mali-400MP 3D GPU System Memory – 1GB DDR3 Storage – 4GB eMMC Flash 2x 100-pin board-to-board connectors with 1.27 pitch: 5x UART, I2C, SPI 1x USB2.0 Host, 1x USB HSIC Host, 1x USB2.0 OTG, LCD (TFT/LVDS/MIPI) Gigabit Ethernet I2S, CIF (not sure what it is), Audio HDMI GPIOs ADC PWM HSMMC/SD Power – 5V; AXP228 PMIC Dimensions – 70 x 58 mm (8-layer PCB) The […]

June 23, 2016June 23, 2016 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

Forlinx i.MX6UL Linux Single Board Computer Supports ESAM Embedded Security Control Module

Forlinx Embedded has introduced i.MX6UL single board computer (SBC) based on NXP i.MX 6Ultralite Cortex A7 processor with 512 MB RAM, 8GB storage, that includes two Ethernet interface, an LCD interface, a CAN bus, as well as ESAM (Embedded System Access Module) support via either a SIM card like slot, or a 8-pin DIP chip compatible with ISO7816 standard, and typically used in the financial, telecommunications, transportation sectors for authentication and secure data transfer. Forlinx I.MX6UL board specifications: System-on-module: SoC – NXP i.MX 6Ultralite ARM Cortex A7 processor @ up to 528 MHz with 2D graphics GPU System Memory – 512 MB LvDDR3 memory Storage – 8GB eMMC flash (but hardware manual says 1GB eMMC flash, but also mentioned MTFC8GACAAAM-1M WT so it must 8GB after all…) 2x 80-pin board to board connectors with signals for 2x CAN bus, 2x USB device, 2x SDIO, 2x 10/100M Ethernet, 24-bit RGB, 4x […]

May 3, 2016 by Jean-Luc Aufranc (CNXSoft) - No Comments

Orbitty is a $175 Carrier Board for Nvidia Jetson TX1 System-on-Module

Connect Tech had already launched Astro carrier board for Nvidia Tegra X1 based Jetson TX1 CPU module, which they also integrated into Rosie Military Grade Embedded mini PC. Since them the Canadian company had also introduced a low cost “Elroy” carrier board , and more recently, a third cheaper baseboard called Orbitty selling for $175 and up, and including Gigabit Ethernet, USB 3.0 & 2.0 ports, HDMI, and more. Orbitty (ASG003) carrier board specifications: Compatibility – Nvidia Jetson TX1 system-on-module Storage – micro SD slot Video & Audio Output – 1x HDMI Connectivity – Gigabit Ethernet (RJ45) USB – 1x USB 3.0 port, 1x micro USB 2.0 OTG port Expansion Header – 20-pin header with 2x 3.3V UART, I2C, 4x GPIO, etc… Power Supply – 9 to 19V DC via terminal block Dimensions – 87 x 50mm Operating Temperature – -40°C to +85°C The carrier board targets robotics and unmanned […]

April 28, 2016 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Inforce 6601 micro SoM Snapdragon 820 System-on-Module Embeds WiFi, Bluetooth and GPS

We’ve already seem Intrinsyc’s Snapdragon 820 development board and module, but there’s now an alternative thanks to Inforce Computing 6601 micro SoM which is pin-to-pin compatible to the company’s earlier Inforce 6401 and Inforce 6501 Micro SOMs, also based on Qualcomm Snapdragon processors, and works with the same SYS6501 carrier board. Inforce Computing 6601 Micro SoM specifications: SoC – Qualcomm Snapdragon 820 (APQ8096) quad core ARMv8 processor with two “Gold” cores up to 2.2 GHz, two “Silver” cores up to 1.6 GHz, Adreno 530 GPU with support for OpenGL ES 3.2, OpenCL 2.0, and Vulkan, as well as Hexagon 680 DSP up to 825 MHz System Memory – 4GB LPDDR4 @ 1866 MHz Storage – 64GB UFS 2.0 gear 3 flash up to 5.83Gbps, 1x micro SD card 3.0 interface for support for to HS400, optional eMMC 5.1 flash. Connectivity – Bluetooth 4.1 & 2×2 dual band 802.11 b/g/n/ac Wi-Fi […]
