Posted on by Debashis Das - No Comments on AAEON PICO-ASL4 industrial Pico-ITX SBC ships with Intel Atom x7000RE, up to 16GB DDR5, 2.5GbE LAN

AAEON PICO-ASL4 industrial Pico-ITX SBC ships with Intel Atom x7000RE, up to 16GB DDR5, 2.5GbE LAN

AAEON PICO ASL4 Rev.B Intel Atom x7000RE Pico ITX SBC

AAEON PICO-ASL4 is a fanless, latency-sensitive Pico-ITX single board computer (SBC) built around the Intel Atom x7000RE-series “Amston Lake” SoCs and configurable with up to 16GB of DDR5 memory. The SBC supports dual display outputs via HDMI and LVDS/eDP and features four serial ports: two RS232/422/485 and two RS232. For networking, it provides dual Ethernet connectivity with Intel i226 2.5GbE and Realtek RTL8111H 1GbE controllers, both supporting TSN and TCN. Additionally, it offers a variety of expansion options, including a full-sized mSATA/mPCIe slot and an M.2 2230 E-Key socket for WiFi and Bluetooth. For further connectivity, there are four USB 2.0 ports, two USB 3.2 Gen 2 ports, as well as GPIO and SMBus/I2C headers. AAEON PICO-ASL4 (Rev.B) specifications SoC – Intel Amston Lake (one or the other) Intel Atom x7433RE, 4 cores, 1.5GHz, 9W TDP Intel Atom x7835RE, 8 cores, 1.3GHz, 12W TDP System Memory – Up to 16GB DDR5 […]

Posted on by Debashis Das - 1 Comment on DFI RPP051 Pico-ITX SBC features 13th Gen Intel Core embedded SoC from Processor U300E to Intel Core i7-1365UE

DFI RPP051 Pico-ITX SBC features 13th Gen Intel Core embedded SoC from Processor U300E to Intel Core i7-1365UE

DFI RPP051 Pico ITX SBC

DFI RPP051 is a 2.5-inch Pico-ITX SBC built around 13th Gen Intel Core processors ranging from the dual-core Intel Processor U300E to the 10-core Intel Core i7-1365UE. It supports up to 32GB DDR5 SO-DIMM memory and accommodates M.2 NVMe and SATA storage devices. Connectivity options include a 2.5GbE LAN port, DP++ and eDP display interfaces, USB 3.2 Gen 2 and USB 2.0 ports, RS-232/422/485 interfaces, along with I2C and GPIO for expansion. The DFI RPP051 first came to our attention while covering the AAEON PICO-RAP4 which is also an SBC with a Pico-ITX form factor, we have also written about many x86 and Arm Pico-ITX boards including AAEON PICO-MTU4, the AAEON RICO-3568, the GIGAIPC PICO-N97A and many other feel free to check them out if you are looking for compact and powerful SBCs. DFI RPP051 Pico-ITX SBC Specification 13th gen Raptor Lake SoC (one or the other) Intel Core i7-1365UE 10C/12T […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on PICO-APL3 Apollo Lake Pico-ITX Board Comes with an Optional TPM 2.0 Module

PICO-APL3 Apollo Lake Pico-ITX Board Comes with an Optional TPM 2.0 Module

AAEON has launched another industrial Pico-ITX board powered by Intel Celeron/Pentium Apollo Lake processors with their PICO-APL3 Pico-ITX single board computer featuring either Celeron N3350 or Pentium N4200 processor together with 2 to 4GB soldered DDR3L memory, and 16 to 64 GB eMMC flash. The company explains that one of key differences against other similar board is the option for a TPM module / hardware security that would allow applications such as payment processing for retailers or on the go. AAEON PICO-APL3 board specifications: SoC Intel Celeron N3350 dual core Apollo Lake processor @ up to 1.10/2.40GHz with 12EU Intel HD Graphics 500; 6W TDP Intel Pentium N4200 quad core Apollo Lake processor @ up to 1.10/2.50GHz with 18 EU Intel HD Graphics 505; 6W TDP System Memory – 2GB DDR3L on-board (Option to 4GB) Storage – 16GB eMMC flash (32/64 GB as option), 1x SATA III port (5V/12V power), […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 12 Comments on Secure96 is a 96Boards Mezzanine Expansion Board To Experiment with Hardware Based Security

Secure96 is a 96Boards Mezzanine Expansion Board To Experiment with Hardware Based Security

With the Internet of things booming and taking a more important role in our lives, security will become more and more critical. So far, it has often been an afterthought with modems & routers frequently shipping with default username and password, and getting security right is really hard, as shown by the recent CLKSCREW attack that somehow leverages DVFS to break ARM TrustZone security, and that “is not a software bug, nor a hardware bug, it’s a fundamental part of the energy management design”, so most ARM platforms are vulnerable. Optimal security normally combines software and hardware, so having a platform to experiment with different HW security solutions would be useful, and that’s what Secure96 Mezzanine board for 96Boards aims for. Secure96 expansion board specifications: Security ICs Microchip Atmel ATSHA204A SHA-based CryptoAuthentication crypto element device Microchip Atmel ATECC508A crypto device with ECDH (Elliptic Curve Diffie–Hellman) key agreement Infineon SLB 9670 TPM […]
