Adapteva Announces Three Parallella Fanless Boards for Microserver, Desktop, and Embedded Applications

Adapteva’s Parallella low cost open source hardware “supercomputer” is a board powered by Xilinx Zynq-7010/7020 dual core Cortex A9 + FPGA SoC and the company’s Ephipany epiphany coprocessor, that’s had a successful Kickstarter campaign in 2012 as the 16-core version sold for just $99, and is capable of handling applications such as image and video processing, and ray-tracing, and also comes with an OpenCL SDK. The board was fairly difficult to source after the crowdfunding campaign, and one the common complain of backers was the board had to be actively cooled by a fan. The company has fixed both issues by increasing slightly the price, and redesigning the board so that it can be passively cooled by a larger heatsink.

Parallela Desktop Board

Parallella Desktop Board with Heatsink

There are now three versions of the parallela board:

  • Parallella Microserver ($119) – Used as an Ethernet connected headless server
  • Parallella Desktop ($149) – Used as a  personal computer
  • Parallella Embedded ($249) – Used for “leading edge” embedded system

Here are the simplified specs of the boards:

  • SoC
    • Microserver and Desktop – Xilinx Zynq Z7010 dual-Core ARM Cortex A9 with 512KB L2 Shared Cache + Artix-7 FPGA with 28K logic cells
    • Embedded – Xilinx Zynq Z7020 dual-Core ARM Cortex A9 with 512KB L2 Shared Cache + Artix-7 FPGA with 85K logic cells
  • Coprocessor – 16-core Epiphany-III processor
  • System Memory – 1GB DDR3
  • Storage – micro SD slot + 128Mb quad SPI flash
  • Connectivity – 10/100/100M Ethernet
  • Video Output – 1x micro HDMI (Desktop and Embedded only)
  • USB – 1x micro USB host port  (Desktop and Embedded only)
  • Expansion I/O
    • Microserver – N/A
    • Desktop – 2 eLinks (Ephiphany Links) + 24 GPIO pins
    • Embedded – 2 eLinks + 48 GPIO pins
  • Dimensions – 86.36mm x 53.34mm
Parallela Embedded

Parallela Embedded

The board will sell with the heatsink and a power adapter. If you have one of the boards from the Kickstarter campaign,  or boards purchased before the 10th of July, you can’t go fanless by just replacing the fan by the new heatsink, as it won’t fit.

Parallella-16 Desktop computer is available now for $149 on Adapteva shop, and in a couple of days, it will be on Amazon US. The Microserver and Embedded versions will be available in a few weeks. You can read the announcement on the company website, where you’ll also find some interesting projects (videos) that have been done so far by the community of developers.

Digg This
Reddit This
Stumble Now!
Buzz This
Vote on DZone
Share on Facebook
Bookmark this on Delicious
Kick It on DotNetKicks.com
Share on LinkedIn
Bookmark this on Technorati
Post on Twitter

  1. Qermit
    July 15th, 2014 at 21:54 | #1
  2. July 15th, 2014 at 22:41 | #2

    @Qermit
    Thanks! I read the wrong column there….

  3. onebir
    July 16th, 2014 at 18:10 | #3

    But still no 64 core chip :(

  4. Ian Tester
    July 17th, 2014 at 17:57 | #4

    Not available outside of U.S. yet :(
    And 1GB of RAM is a little short.

    What are the “eLinks” used for? Could they be used for adding e.g SATA ports?

  5. No
    July 20th, 2014 at 02:46 | #5

    Ian Tester :
    What are the “eLinks” used for? Could they be used for adding e.g SATA ports?

    No not fast enough. Just useable to connect to FPGAs and other Epiphany chips.
