Snapdragon 778G 5G SoC to power “high-tier” smartphones with up to 16GB LPDDR5

There used to be “premium mid-range” smartphones, but Qualcomm now calls those “high-tier” smartphones in the recent announcement of Snapdragon 778G 5G processor succeeding Snapdragon 765G/768G 5G mobile platforms.

The octa-core Cortex-A78/A55 SoC features a Snapdragon X53 5G Modem supporting up to 3.7 Gbps downlink, support FHD+ display up to 144 Hz, up to 16GB LP-DDR5 memory, and packs 12 TOPS of AI processing power.

Snapdragon 778G 5G

Snapdragon 778G (SM7325) specifications:

  • CPU – Eight Kryo 670 CPU cores including 4x Arm Cortex-A78 @ 2.4GHz and 4x Arm Cortex-A55 @ 1.8GHz
  • GPU – Adreno 642L with Vulkan 1.1, Snapdragon Elite Gaming features, H.265 and VP9 video decode, HDR10+, HDR10, HLG
  • DSP – Hexagon 770 Processor with fused AI Accelerator architecture, Hexagon Tensor Accelerator, Hexagon Vector eXtensions, Hexagon Scalar Accelerator
  • 2nd generation Qualcomm Sensing Hub
  • Memory – Up to 16 GB LP-DDR5 memory up to 3200 MHz
  • Display
    • On-Device Display – up to FHD+ @ 144 Hz
    • External Display – up to 4K UHD @ 60 Hz with 10-bit color depth, Rec. 2020 color gamut, HDR10, and HDR10+ support
  • Camera
    • Qualcomm Spectra 570L Image Signal Processor
    • Triple 14-bit ISPs
    • Up to 22 MP triple camera @ 30 FPS with Zero Shutter Lag
    • Up to 36+22 MP dual camera @ 30 FPS with Zero Shutter Lag
    • Up to 64 MP single camera @ 30 FPS with Zero Shutter Lag
    • Slow-mo video capture at 720p @ 480 FPS
    • HDR –  HDR10+, HDR10, HLG
    • HEIF: HEIC photo capture, HEVC video capture
  • Audio
    • Hexagon Voice Assistant Accelerator for hardware-accelerated voice signal processing
    • Qualcomm Aqstic audio codec up to WCD9385
    • Qualcomm Aqstic smart speaker amplifier up to WSA8815
  • Connectivity
    • 5G Modem-RF System
      • Snapdragon X53 5G Modem-RF System
      • Multimode support: 5G NR, LTE including CBRS, WCDMA, HSPA, TD-SCDMA, CDMA 1x, EV-DO, GSM/EDGE
      • 5G mmWave and sub-6 GHz, standalone (SA) and non-standalone (NSA) modes, FDD, TDD
      • 5G mmWave: 400 MHz bandwidth, 2×2 MIMO
      • 5G Sub-6 GHz: 100 MHz bandwidth, 4×4 MIMO
      • Downlink: Up to 3.7 Gbps
      • Global 5G multi-SIM
    • Wi-Fi & Bluetooth
      • Qualcomm FastConnect 6700 Subsystem supporting WiFi 6E, WiFI 6 (802.11ax), WiFI 5 802.11ac Wave 2, 802.11a/b/g, 802.11n up to 2.9 Gbps
      • Bluetooth 5.2 with Qualcomm TrueWireless Technology, aptX Adaptive, Bluetooth LE audio (one to many broadcast)
    • Location – GPS, Glonass, BeiDou, Galileo, QZSS, NAVic capable
    • Near Field Communications (NFC)
  • USB – USB 3.1 Type-C with support for DisplayPort alt-mode
  • Security
    • Platform Security Foundations, Trusted Execution Environment & Service
    • Qualcomm wireless edge services (WES) and premium security features
    • Qualcomm 3D Sonic Sensor and Qualcomm 3D Sonic Max (fingerprint sensor)
    • Qualcomm Type-1 Hypervisor
  • Charging – Quick Charge 4+ technology
  • Manufacturing – 6 nm Process Technology

Qualcomm claims a 40% performance boost both for the  CPU and GPU over Snapdragon 768G. But as noted by XDA developers, Snapdragon 778G is quite similar to the Snapdragon 780G announced a couple of months ago but with all Cortex-A78 cores clocked at 2.4 GHz instead of 1x @ 2.4 GHz + 3 @ 2.2 GHz, and 5G downlink peaks at 3.7 Gbps instead of just 3.3 Gbps, plus 5G mmWave is supported, and LPDDR5 memory is supported instead of just LPDDR4.

Snapdragon 778G powered 5G phones are expected in Q2 2021, which should mean next month, from companies such as HONOR,iQOO, Motorola. OPPO,  realme, and Xiaomi. More information may be found on the product page.

Share this:
FacebookTwitterHacker NewsSlashdotRedditLinkedInPinterestFlipboardMeWeLineEmailShare

Support CNX Software! Donate via cryptocurrencies, become a Patron on Patreon, or purchase goods on Amazon or Aliexpress

ROCK Pi 4C Plus

5 Replies to “Snapdragon 778G 5G SoC to power “high-tier” smartphones with up to 16GB LPDDR5”

  1. It’s funny to see huge improvements on mobile chipsets while I don’t see any clear solution from Google to make Android more hybrid mobile/desktop.

    It’s true Google is working in a kind of desktop mode, but my idea is something that can change the interface completely when docked into some “gadget” that acts like a dock station, with TV-out port, USB’s for mouse and keyboard and other stuff. Android would swap into something very similar to Windows or Linux, like unloading the mobile GUI and loading a different GUI made for desktop from scratch, like it were KDE or Gnome, plus with total compatibility with Linux applications and even windows ones through emulation.

    I don’t think that idea is so complicated for a company of the size of Google 🙂

    1. You can put Linux on there. See Andronix.

      Samsung does it a little better with DeX, but I assume there are still problems, some of them carried on from vanilla Android.

      Google has been working on FUCHSIA for years, possibly with intentions of having it run on all previously Android smartphones and Chromebooks, with a seamless experience on different platforms and better security updates. But the smartphone brands are likely to resist giving Google more control.

      At some point, a better desktop experience will just have to happen. Smartphone-as-a-desktop is too convenient, and the hardware has come a long way since Ubuntu Edge’s failed kickstarter. Such as 16-18 GB of LPDDR5 RAM on phones when none of them need it (yet).

      1. You left nothing to say. Very insightful.

        Fuchsia is already shipped v.1.0 with something like google home security device..? Maybe google will put some restrictions for fuchsia kernel even though open sourced.

        Such phone could be a great “server” by the way..
