Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on ASUS N5105I-IM-A – A Jasper Lake mini-ITX motherboard with Celeron N5105 SoC

ASUS N5105I-IM-A – A Jasper Lake mini-ITX motherboard with Celeron N5105 SoC

ASUS N5105I-IM-A

ASUS has unveiled, or rather inadvertently leaked, what may be the first Jasper Lake mini-ITX motherboard. following Intel Jasper Lake processors launch last January and a few mini PCs and  2-in-1s were introduced in recent months. ASUS N5105I-IM-A mini-ITX industrial motherboard is equipped with an Intel Celeron N5105 quad-core Jasper Lake processor with two SO-DIMM slots, VGA, HDMI, LVDS, PCIe 3.0/2.0 x1, mini PCIe, eight USB interfaces, six serial interfaces, as well as 12V DC input and output. ASUS N5105I-IM-A specifications: SoC – Intel Celeron N5105 quad-core processor @ 2.0GHz / 2.9GHz (Turbo) with Intel UHD graphics 605; 10W TDP System Memory – 2x SO-DIMM sockets Storage – 2x SATA ports Video Output HDMI 2.0 DisplayPort LVDS colay with eDP VGA Triple independent display support Audio – 3.5mm Line In and Line Out jacks; 3W amplifier; integrated buzzer Networking – Gigabit Ethernet port USB – 4x USB 3.2 Type-A ports, […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on ECS LIVA M300-W industrial mini PC is powered by Rockchip RK3399K SoC

ECS LIVA M300-W industrial mini PC is powered by Rockchip RK3399K SoC

ECS LIVA M300-W industrial mini PC

Elitegroup Computer Systems (ECS) is mostly known for its x86 motherboards and mini PCs, but earlier with year, ECS LIVA Q1A Arm mini PC was introduced with either Rockchip RK3288 or RK3399 SoC, and support for Linux and Android operating systems. But the Taiwanese company has now unveiled a new Arm-based industrial-grade mini PC with LIVA M300-W powered by Rockchip RK3399K processor that allows for either higher 2.0 GHz frequency at commercial temperature range, or the usual 1.8 GHz frequency in a wider (-20°C to +85°C) temperature range. ECS LIVA M300-W specifications: SoC – Rockchip RK3399K hexa-core processor with two Cortex-A72 up to 1.8GHz/2.0GHz, four Cortex-A53 up to 1.4GHz, Arm Mali-T860MP4 GPU System Memory – 2GB/4GB DDR3L Storage – 32GB or 64 GB eMMC flash, internal Micro SD slot Video Output 1x HDMI 2.0 port up to 4Kp60, CEC support 1x DisplayPort 1.2 port up to 4Kp60 Audio – 1x […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Rockchip PX30 3.5-inch SBC Targets Automotive Infotainment, Retail PoS, and Digital Signage

Rockchip PX30 3.5-inch SBC Targets Automotive Infotainment, Retail PoS, and Digital Signage

Rockchip PX30 SBC

While Rockchip RK3326 quad-core Cortex-A35 processor is found in ODROID-GO Advance portable game console, it was brought to my attention that there weren’t any RK3326 SoM nor SBC on the market. But Rockchip PX30, with virtually the same design, only adding support for dual VOP (dual independent display support), is already found on several system-on-modules including ADLINK LEC-PX30 SMARC module and ARBOR SOM-RP301. It turns out there’s also a Rockchip PX30 SBC courtesy of Shenzhen based TechVision “3.5’SBC-PX30-TVI3329A“. Specifications: SoC – Rockchip PX30 quad-core Arm Cortex A35 processor @ 1.5GHz with Mali-G31 MP2 GPU Memory – 2 GB DDR3L Storage – 8GB, 16GB, 32GB or 64 GB eMMC flash, MicroSD card slot Video Output & Display Interfaces HDMI output via RK618 chip Dual-channel LVDS via RK618 2x eDP Ports 1x MIPI DSI Port shared with eDP 2 LED Backlight header Support for USB touch panel 2x independent displays support Audio […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on AMD Ryzen Embedded V1605B/V1807B SBC Offers Four GbE Interfaces, Four Video Outputs

AMD Ryzen Embedded V1605B/V1807B SBC Offers Four GbE Interfaces, Four Video Outputs

Axiomtek CAPA13R

We’ve written about several AMD Ryzen Embedded V1000 SBCs and many of them fully leverage the processor multimedia capabilities with support for four 4K displays, but  Axiomtek CAPA13R 3.5″ Embedded SBC adds an extra twist by also offering four Gigabit Ethernet ports. The board is equipped with either Ryzen Embedded V1807B or V1605B, up to 16GB RAM, and offers two M.2 sockets for storage and connectivity. Four independent display support is achieved through a mix of three types of video output including two HDMI ports, one DisplayPort, and one LVDS connector. Axiomtek CAPA13R V1605B/V1807B SBC specifications: SoC – AMD Ryzen Embedded V1807B ( 35-54W) or V1605B (12-25W) quad-core processor with Radeon Vega 8 graphics System Memory – 1 x 260-pin SO-DIMM socket for up to 16GB DDR4-2400 (V1605B), 16GB DDR4-3200 (V1807) Storage – SATA 3.0 port (6Gbps),  support for M.2 SATA/NVMe SSD in 22x42mm or 30x42mm form factor (Key B […]

Posted on by Stephen Vicinanza - 1 Comment on Boardcon Idea3288 Android SBC is Made for Digital Signage, Smart PoS, and Vending Machines

Boardcon Idea3288 Android SBC is Made for Digital Signage, Smart PoS, and Vending Machines

Boardcon Announces the Idea3288 SBC Boardcon Idea3288 targets the commercial market with a variety of applications for its latest SBC, utilizing a Rockchip 3288 CPU module. The company says the Idea3288 is customizable for whatever commercial application that can be had, such as digital displays, vending machines, intelligent POS, automotive, IoT, and even access control systems. Idea SoC RK3288 and Interfaces The SBC is comprised of a Rockchip RK3288 quad-core Arm Cortex A17 processor with a Mali-T764 GPU, 2GB RAM, and 8GB eMMC flash. The interfaces include GbE, mDP, HDMI, 3x USB2.0 Host ports, one USB OTG port, audio, battery, MIPI DSI/CSI, UARTs, RS485, CAN, POE, Micro SD, PCI-e (for 4G modem), M.2 slot (for SSD), SIM slot, and more. The SBC is made up of a carrier board and a CPU module The SBC runs Android 7.1.2 operating system and is built to handle 4K video playback. The Idea3288 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 20 Comments on Espressif ESP32-S2 Secure WiFi MCU Comes with an Xtensa LX7 Core @ 240 MHz

Espressif ESP32-S2 Secure WiFi MCU Comes with an Xtensa LX7 Core @ 240 MHz

ESP32-S2

Espressif Systems has unveiled a new ESP32 WiFi MCU based on Cadence (previously Tensilica) Xtensa LX7 core instead of the usual Xtensa LX6 core(s). ESP32-S2 is powered by a single Xtensa LX7 core clocked at 240 MHz, supports Wi-Fi HT40 @ 2.4 GHz, and provides up to 43 GPIOs. Espressif ESP32-S2 specifications: CPU – Cadence Xtensa single-core 32-bit LX7 microcontroller @ up to 240 MHz, and ultra-low-power co-processor System Memory – 320 kB SRAM, external SPIRAM support up to 128 MB in total, 16 KB RTC memory Storage –  128 kB ROM, up to 1 GB of external flash support Connectivity Wi-Fi 802.11 b/g/n 1×1 transmit and receive with HT40 support with data rate up to 150 Mbps Support for TCP/IP networking, ESP-MESH networking, TLS 1.0, 1.1 and 1.2 and other networking protocols over Wi-Fi Support Time-of-Flight (TOF) measurements with normal Wi-Fi packets I/O & peripherals 43x programmable GPIOs 14x […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on Alipay Dragonfly F1 PoS Enables Payments with Face Recognition

Alipay Dragonfly F1 PoS Enables Payments with Face Recognition

Alipay Dragonfly F1

We’re being told the traditional way of paying for purchases – cash – is going away, so we’ll soon have to rely exclusively on electronics payment means such as debit cards, credit cards, contactless stored value smart cards, smartphones, our own face, etc… Wait? I could pay by just showing up my face? Apparently yes, as Alipay recently installed 12 Dragonfly POS (Point-of-Sales) devices with biometric technology at Hong Kong airport. The systems started operating at the airport on April 2nd, but similar devices were allegedly deployed in more than 300 cities in mainland China previously. I’m not entirely sure of the exact model operating at Hong Kong airport, but a quick web search reveals Alipay Dragonfly F1 matches the description. Hardware specifications: Processor – Quad-core Arm Cortex A53 processor @ 1.3GHz System Memory – 2GB RAM Storage – 8GB FLASH Display – 10.1″ TFT touch screen display with 1280×800 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on SAPPHIRE FS-FP5R 5×5 AMD Ryzen R1606G/R1505G Motherboard Comes with Three DisplayPort++ Outputs

SAPPHIRE FS-FP5R 5×5 AMD Ryzen R1606G/R1505G Motherboard Comes with Three DisplayPort++ Outputs

AMD FS-FP5R 5x5 motherboard

AMD Ryzen Embedded R1000 dual core/quad thread processors launched a few days ago, and we’ve seen a few products based on the new processor including Atari VCS gaming console, and ASRock iBox-R1000 mini PC as well as the corresponding 4″ NUC-R1000 motherboard. Sapphire FS-FP5R 5×5 is another motherboard based on AMD Ryzen R1606G or R1505G processor with support for three independent display connected over DisplayPort++, and targeting for small form factor embedded applications such as electronic gaming machines, medical imaging, interactive digital signage, thin clients, PoS (Point-of-Sale) terminals and more. Sapphire FS-FP5R 5×5 specifications: SoC (one or the other) AMD Ryzen Embedded R1505G dual core/quad core processor @ with Radeon Vega 3 graphics; 12 to 25W TDP AMD Ryzen Embedded R1606G dual core/quad core processor @ with Radeon Vega 3 graphics; 12 to 25W TDP System Memory – 2x DDR4 ECC/Non-ECC SO-DIMMs; Dual Channel speed up to DDR4-2400 Storage – […]
