SCADA News - CNX Software - Embedded Systems News

February 28, 2024February 27, 2024 by Debashis Das - No Comments

Inventia MT-058 cellular IoT telemetry module is powered by Nordic Semi nRF9160 SiP

MT 058 – battery powered telemetry module

A few days back, Inventia introduced the MT-058 cellular IoT telemetry module built around Nordic Semiconductor’s nRF9160 System in Package (SiP) module with support for LTE-M/NB-IoT connectivity with GNSS. The device is designed for low-power, battery-operated industrial applications such as water metering and environmental monitoring. The module is IP68-rated and offers a combination of digital and analog inputs. It also comes with a battery that can last up to 5 years and there is also support for external sensor attachment for data logging applications. MT-058 Cellular IoT telemetry module specification: Nordic nRF9160 SiP with 64 MHz Arm Cortex-M33 application processor with 1 MB flash, and 256 KB RAM Connectivity – LTE Cat M1 and NB-IoT SIM card options – Standard 2FF SIM card slot, with an option for a soldered Machine Identification Module (MIM). Antenna – SMA connector for attaching an external antenna. Inputs – 5 inputs for counters, up […]

December 21, 2022 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

EdgeBox-ESP-100 – An ESP32-S3 industrial controller with RS485, CAN Bus, DIO, 4G LTE, and more

We’ve previously covered the EdgeBox-RPi4 industrial controller powered by a Raspberry Pi Compute Module 4 and plenty of I/Os such as RS485, RS232, digital inputs and outputs, and connectivity options such as Gigabit Ethernet, WiFi 5, Bluetooth 5, and 4G LTE. But if you don’t quite need the power of a Linux controller, the EdgeBox-ESP-100 industrial edge controller based on an ESP32-S3 dual-core WiFi and Bluetooth microcontroller and offering a similar set of features, albeit with twists, may be an interesting option. EdgeBox-ESP-100 specifications: Microcontroller – Espressif Systems ESP32-S3 dual-core Tensilica LX7 microcontroller @ 240 MHz with AI vector instructions, 512KB RAM Memory – 8MB PSRAM Storage – 16MB Flash Network connectivity 10/100M Ethernet RJ45 port 2.4 GHz WiFi 4 and Bluetooth 5.0 LE via ESP32-S3 4G LTE cellular via SIMCom A7670G LTE Cat 1 module Optional support for LoRa (replaces the A7670G module) Serial & I/Os via terminal blocks […]

December 18, 2022December 18, 2022 by Jean-Luc Aufranc (CNXSoft) - 9 Comments

OpenPLC open-source Programmable Logic Controller Suite works with Arduino, ESP8266/ESP32, Raspberry Pi, etc.

OpenPLC is an open-source, free-to-use Programmable Logic Controller Suite, compliant with the IEC 61131-3 standard, and working with a range of hardware platforms such as Arduino, ESP8266/ESP32, Raspberry Pi SBCs, as well as Windows and Linux machines. When Arduino unveiled the Arduino PLC IDE, we noted the languages defined by the IEC 61131-3 standard were licensed, and the PLC key for the Portenta Machine Control unit sold for $17.60. One reader complained about the high license cost per device, but Massimo Banzi, the co-founder of the Arduino project, replied it was cost-effective for smaller deployments: Actually it’s not that much money compared to the cost of other PLC software (thousands of dollars per seat!). This model helps small companies with not that many devices.. It’s possible to negotiate bulk licenses for companies. But there’s also another option with OpenPLC open-source PLC suite that does not require any license fee. That’s […]

September 22, 2022September 22, 2022 by Jean-Luc Aufranc (CNXSoft) - No Comments

OnLogic IGN800 Industrial Raspberry Pi Edge Gateway runs Ignition Edge software

OnLogic IGN800 is an industrial edge gateway based on the Raspberry Pi CM4 module pre-loaded with the Ignition Edge HMI, SCADA (Supervisory Control And Data Acquisition), MES, and IIoT software platform from Inductive Automation. The hardware is not exactly new, as the Onlogic IGN800 is simply the OnLogic Factor 201 industrial PC introduced earlier this year, but that ships with Ignition Edge in order to provide a cost-effective solution for automation projects. OnLogic IGN800 specifications: SoM – Raspberry Pi CM4 with Broadcom BCM2711 quad-core Arm Cortex-A72 processor @ up to 1.5 GHz, up to 8GB LPDDR4 RAM, up to 32GB eMMC flash Additional storage – Optional M.2 SATA SSD (See Expansion section) Video Output – HDMI port up to 4Kp60 Networking 2x Gigabit Ethernet LAN (Optional PoE PD Input) via Realtek RTL8153 controller Optional WiFi/Bluetooth module on Raspberry Pi CM4 module + 3x antenna holes Optional 4G LTE wireless module […]

April 14, 2022September 22, 2022 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Semtech LR1120 enables global asset tracking with multi-band LoRa, WiFi, and GNSS

Semtech LoRa Edge LR1120 is an ultra-low-power multi-band chip designed for global geolocation and asset tracking applications including direct satellite-connected Internet of Things (IoT) applications in supply chain management and logistics. Not only does the LR1120 features the usual sub-GHz LoRa radio found in most other chips from the company, but also comes with 2.4GHz LoRa and SATCOM S-Band support for satellite, as well as a GNNS radio compatible with GPS and Beidou, and a WiFi radio for indoor positioning (but no WiFi RTT/802.11mc support). Semtech LR1120 key features and specifications: Low-power high-sensitivity LoRa/(G)FSK half-duplex RF transceiver Worldwide ISM frequency bands support in the range 150 – 960MHz (Sub-GHz) and 2.4GHz, as well as 1.9-2.1GHz (S-Band) Low Noise Figure RX front-end High power PA path +22dBm in the Sub-GHz band Up to +11.5dBm in the 2.4GHz band LR-FHSS modulator Integrated PA regulator supply selector to simplify dual power +15/+22dBm with […]

January 29, 2021September 22, 2022 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

UniPi Gate RS485 Linux IoT Gateway features 600 MHz Rockchip RK3328 SoC

Based in the Czech Republic, UniPi Technology design and manufacture programmable logic controllers, gateways, sensors and systems for smart homes, building management systems, industry and automation projects. Their latest product is UniPi Gate G100/G110 Linux IoT gateway with Ethernet and RS485 interfaces. When the company contacted CNX Software about the gateway, they told us the system was based on a quad-core Cortex-A53 processor clocked at 600 MHz. Since we are not aware of such SoC, we asked, and UniPi told us it was Rockchip RK3328. That processor is normally clocked at 1.5 GHz, and it turns out the company purposely underclocked the processor to 600 MHz to extend the temperature range and reduce the heat emitted by the CPU. UniPi Gate G100 & G110 specifications: SoC – Rockchip RK3328 quad-core Cortex-A53 processor @ 600 MHz System Memory – 512MB RAM Storage – 16GB eMMC flash, MicroSD card slot Networking – […]

January 27, 2021September 22, 2022 by Jean-Luc Aufranc (CNXSoft) - No Comments

OnLogic Elkhart Lake fanless mini PC’s are made for IIoT applications

Onlogic Karbon 410 Elkhart-Lake fanless rugged mini pc

Intel Atom x6000E Series, Celeron and Pentium Elkhart Lake IoT Edge processors were introduced in September 2020, and we covered several Elkhart Lake modules and SBC’s. We’ve seen fewer full systems such as the Atom x6425RE based Vecow SPC-6000 Elkhart Lake mini PC for embedded & IoT applications. But OnLogic is more offering four more choices with Helix 300 and Karbon K400 Series of rugged fanless mini PCs, all equipped with Atom, Celeron, or Pentium Elkhart Lake processors, and designed for industrial IoT (IIoT) or Industry 4.0 applications Helix 300 Series Specifications The Helix 300 family is comprised of two models with Helix 310 and Helix 330 share most of the same specifications: SoC – Intel Celeron N6211 dual-core processor or Pentium J6425 quad-core processor System Memory – Up to 32 GB DDR4 RAM Storage – M.2 Storage Video Output – 3x DisplayPort for triple independent display setups Audio – […]

February 20, 2018September 22, 2022 by Jean-Luc Aufranc (CNXSoft) - No Comments

ADL Embedded Solutions ADLEPC-1520 Atom based Industrial Mini PC Supports Stackable I/O Expansion

ADL Embedded Solutions has recently announced ADLEPC-1520 embedded mini PC powered by a dual or quad core Intel Atom Bay Trail-I processor, supporting wide temperature range, and long term 15 years availability for industrial applications and environments. The computer also includes an expansion header with PCIe, SATA, USB, SM-Bus and DisplayPort interfaces, that allows for standard or custom expansion board stackable on top of the main board. ADLEPC-1520 specifications for the main board (ADLE3800SEC): SoC (one or the other) Intel Atom E3845 quad core Bay Trail-I processor @ up to 1.91GHz, with 2MB cache, 10W TDP Intel Atom E3827 dual core Bay Trail-I processor @ up to 1.75 GHz, with 1MB cache, 8W TDP System Memory – Up to 4GB soldered down Storage – 2x M.2 Key B 2242 SATA II SSD slots Video Output – 1x DisplayPort Connectivity – Dual Gigabit Ethernet USB – 1x USB 2.0, 1x USB […]
